- Page 1 OWNER’S MANUAL SCR-394 WALK-BEHIND FLOOR SCRAPER OPERATION & MAINTENANCE MANUAL SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...
-
Page 2: Warranty Registration Card
First and Last Name Company Name Address City State Zip Code Phone Number Email Machine Information Machine Type Machine Model Serial # Purchase Date (dd/mm/yy) DiamaPro Systems ® 3343 Peachtree Road NE Suite 145 #24 Atlanta, GA 30326 470-977-2323 www.diamaprosystems.com info@diamaprosystems.com... - Page 3 1.3. Owner’s Obligations INTRODUCTION The owner is a person who operates the machine for commercial or eco- nomic use or leaves it to a third person for use/application and during its This manual guarantees the safe and efficient use of the machine. This use carries the legal responsibility for the protection of the user, personnel manual is part of the machine and has to always be kept near the machine or a third person.
- Page 4 1.8. Occupational Safety & Special Risks INSTRUCTION The owner of the machine has to regularly instruct all personnel. For better documentation an instruction protocol with the following The following paragraph explains residual risks which might be present minimum content has to be kept: even if the machine is used correctly.
-
Page 5: Product Information
The powerful motor combined with the revised HYDRAULIC-DIRECT- DRIVE ensures high forces and extremely low noise level. WARNING! Non-stop work; Malpositions, vibrations and machine movementscause pain and fatigue The SCR-394 is self-propelled (forward and reverse) with infinitely adjust- able speed. Make sure: - observe regular breaks Adjustable guide handle in six positions enables ergonomic operation depending on body size or preferred working position. -
Page 6: Technical Specifications
2.2. Technical Specifications... - Page 7 3.3. Storage 3. TRANSPORT Handle angle set in the storage position 3.1. Raising (Handle angle adjustment, see chapter 4.2) Always remove all counterweights and blades before loading or unloading. ATTENTION ! Do not lift the machine by the handle Improper transport can cause damage to the machine and danger of Easy to lift if you can not drive the machine or have no ramp available.
-
Page 8: Operating Lever
4.2. Handle angle 4.4. Operating lever The guide handle is adjustable in six positions and can be individually The angle of the operating lever can be infinitely adjusted to the desired working position. adjusted to the desired working position. Release lever clamp with ring spanner, adjust and tighten again. -
Page 9: Maintenance Schedule
5.3. Removal of floor coverings Maintenance by DiamaPro Systems® annually or after the first 500 hours of operation then every 1000 operating hours - according to VCT tiles the checklist - Inspection of hydraulic hoses and connections Keep blades sharp! Keep your work area clean and clear of debris. - Page 10 6.2. Hydraulic oil (cont.) Resources Hydraulic oil AVIA Fluid RSL 150 or compatible light liquids according to ISO 150 DIN 51524 T2 Capacity 5 Liter Order No 111 800 310 : 5-L container Order No 111 800 305 : 1-L container ATTENTION ! Keep the hydraulic fluid clean and at the specified level.
-
Page 11: Recommended Replacement Parts
RECOMMENDED REPLACEMENT PARTS PART NUMBER DESCRIPTION QTY. DP-SCR-10435 Wheel Motor Fitting, 45 Degree for DiamaPro SCR-394 DP-SCR-10437 Wheel Motor Fitting, 90 Degree for DiamaPro SCR-394 DP-SCR-10425 Adapter for DiamaPro SCR-394 DP-SCR-10442 Pump Drive Belt for DiamaPro SCR-394 DP-SCR-10226 Cutting Head Flange Bearing for DiamaPro SCR-394... -
Page 12: Hydraulic Components
HYDRAULIC COMPONENTS... - Page 13 Return Line for DiamaPro SCR-394 DP-SCR-10434 Suction Line for DiamaPro SCR-394 DP-SCR-10221 Wheel Motor for DiamaPro SCR-394 DP-SCR-10435 Wheel Motor Fitting, 45 Degree for DiamaPro SCR-394 DP-SCR-10437 Wheel Motor Fitting, 90 Degree for DiamaPro SCR-394 DP-SCR-10425 Adapter for DiamaPro SCR-394 DP-SCR-10438...
-
Page 14: Electrical Components
ELECTRICAL COMPONENTS REF. # PART NUMBER DESCRIPTION QTY. DP-SCR-10426 Molded Pigtail for DiamaPro SCR-84 and SCR-394 DP-SCR-10427 Strain Relief for DiamaPro SCR-84 and SCR-394 DP-SCR-10251 On/Off Switch for DiamaPro SCR-84 and SCR-394 DP-SCR-10276 Switch Plate For DiamaPro SCR-394 DP-SCR-10428 Electric Motor for DiamaPro SCR-394... - Page 15 CUTTING HEAD & DRIVE COMPONENTS...
- Page 16 CUTTING HEAD & DRIVE COMPONENTS REF. # PART NUMBER DESCRIPTION QTY. DP-SCR-10224 Eccentric for DiamaPro SCR-394 DP-SCR-10297 Eccentric Retainer and Bolt for DiamaPro SCR-394 DP-SCR-10441 Pump Pulley for DiamaPro SCR-394 DP-SCR-10442 Pump Drive Belt for DiamaPro SCR-394 DP-SCR-10236 Bearing Spacer for DiamaPro SCR-394 DP-SCR-10226...
-
Page 17: Miscellaneous Components
MISCELLANEOUS COMPONENTS REF. # PART NUMBER DESCRIPTION QTY. DP-SCR-10449 Flat Rubber Grip for DiamaPro SCR-84 and SCR-394 DP-SCR-10448 Round Rubber Grip for DiamaPro SCR-84 and SCR-394 DP-SCR-10450 Tank Vent for DiamaPro SCR-394 DP-SCR-10116 Hose Sleeve for DiamaPro SCR-394... -
Page 18: Additional Components
ADDITIONAL COMPONENTS... -
Page 19: Ancillary Parts
Right Saddle Weight for DiamaPro SCR-394 DP-SCR-10270 Left Saddle Weight for DiamaPro SCR-394 DP-SCR-10218 Left Auxiliary Weight for DiamaPro SCR-394 DP-SCR-10227 Right Bent Side Wing for DiamaPro SCR-394 DP-SCR-10228 Left Bent Side Wing for DiamaPro SCR-394 DP-SCR-10236 Bearing Spacer for DiamaPro SCR-394 DP-SCR-10235... - Page 20 DiamaPro Systems ® 3343 Peachtree Road NE Suite 145 #24 Atlanta, GA 30326 470-977-2323...
