- Page 1 OWNER’S MANUAL AS-500 AIR SCRUBBER USER & MAINTENANCE BOOK SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...
- Page 2 Part No. AS-500 Power 110-120 Vac, 1.9 amps Blower 500 CFM Filters: 1st stage 1"Pleated Media, 2nd stage 2.5" Pleated HEPA 18" x 18" Dimensions Width 22" Height 14" Depth 24" Weight 33 lbs. CAUTION: Risk of electric shock. Can cause injury or death. To reduce the risk of electric...
- Page 3 B. Outlet Ducting to be attached to the AS-500 outlet. To attach ducting to the collar, remove the ring from the unit by pressing release tab at the top of the grill. Put the plastic duct end through the inside of the ring. Roll the duct end outward so that it over-laps the outside of the ring.
- Page 4 GFCI duplex outlet. If operating properly the “RESET” button on the GFCI outlet will pop out. A tripped GFCI is indicated by a small LED. The device can only be “RESET” when AS-500 is connected to a wall outlet providing standard voltage. This duplex AC outlet allows the inter-con- nection of other AC powered devices.
- Page 5 AS-500 is running. C. Direct the outlet duct from AS-500 to the room with the open combustion device(s). This will posi- combustion devices must be checked after AS-500 is running to guarantee that they are not back- drafting.
- Page 6 materials are contained and disposed of properly. Air Filters Filter replacement • The operator must judge if that is acceptable. need to be changed. 1. Loosen the eight screws one revolution 2. Rotate all eight clips out of the way.
- Page 8 DiamaPro Systems ® 3343 Peachtree Road NE Suite 145 #24 Atlanta, GA 30326 470-977-2323...
