- Page 1 VIKING Mobile Data Terminal User’s Manual v1.1...
-
Page 2: Table Of Contents
Contents CONTENTS ................................2 SAFETY PRECAUTIONS ............................. 4 REGULATORY AND CERTIFICATION ......................6 FCC..........................................6 ..................................7 EXPOSURE WARNING ......................................7 CE M ARKING ........................... 10 ITHIUM ATTERY AFETY TATEMENT CHAPTER 1. PRODUCT INTRODUCTION ....................11 ................................ 11 ARDWARE PECIFICATIONS ...................................... - Page 3 .................................. 27 NTERNAL ICROPHONE ................................27 ROGRAMMABLE UTTONS ..................................27 OWER ANAGEMENT CHAPTER 5. JUMPERS AND CONNECTORS ................... 28 ...................................... 28 OTTOM ........................29 XTERNAL ONNECTORS SSIGNMENTS Power Connector ..................................29 RS-232 Port (COM1) ................................30 USB and RS-232/422/485 Port (COM2) ........................31 Digital I/O and CANbus Port ..............................
-
Page 4: Safety Precautions
Safety Precautions Read these safety instructions carefully. Keep this user’s manual for later reference. Disconnect this equipment from any outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible. - Page 5 f. The equipment has obvious signs of breakage. 15. Do not place heavy objects on the equipment. 16. The unit uses a three-wire ground cable which is equipped with a third pin to ground the unit and prevent electric shock. Do not defeat the purpose of this pin. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.
-
Page 6: Regulatory And Certification
Regulatory and Certification This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. -
Page 7: Rf Exposure Warning
RF exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. - Page 8 RED 2014/53/EU ETSI EN 300 328 ETSI EN 301 893 ETSI EN 300 330 ETSI EN 303 413 ETSI EN 301 489-1 ETSI EN 301 489-3 ETSI EN 301 489-17 ETSI EN 301 489-19 ETSI EN 301 489-52 ETSI EN 301 511 ETSI EN 301 908-1 EN 62311 RF Power Table...
-
Page 10: Lithium Battery Safety Statement
Lithium Battery Safety Statement Lithium battery inside. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type of battery recommended by battery manufacturer. Disposal of a BATTERY into fire or a hot oven, or mechanically crushing or cutting of a BATTERY, that can result in an EXPLOSION;... -
Page 11: Chapter 1. Product Introduction
Chapter 1. Product Introduction VIKING is an in-vehicle terminal with 7” high resolution display and 500nits brightness, and is flexible to support a wide range of wireless connection capability. The device is well-suited for fleet management, asset management, EOBR and ELDs application. It is compliant to ISO 7637-2, SAE J1455 and SAE J1113 and its optimized power system is designed for cold cranking, load dump, transient voltage and ESD. -
Page 12: Environment
Environment Operating temperature: -20°C (-4°F) to 60°C (140°F) In accordance with MIL-STD-810H Method 501.7 High Temperature Procedure II - Operation In accordance with MIL-STD-810H Method 502.7 Low Temperature Procedure II - Operation Storage temperature: -30°C (-22°F) to 70 °C (158°F) ... -
Page 13: I/O Ports
I/O Ports Item Description RS-232 x 1 with 0/5/12V support 0.6/0.3A (COM1) - Data rate Max. 250kbps Serial RS-232 TX, RX/422/485 x 1 (COM2) - RS-232 data rate Max. 250kbps - RS-422/485 data rate Max. 250kbps USB 2.0 type A x 1 USB 2.0 x 1 (COM2) USB 3.1 type C x 1 (DisplayPort Alt Mode supported) Ethernet... -
Page 14: Dimension And Weight
Dimension and Weight VIKING Standard Dimension: 219.98 x 151.98 x 40.80 (mm) / 8.66 x 5.98 x 1.61 (in.) (W x H x D) Weight: 1.25 kg/ 2.76 lbs. Front View Dimension 219.98mm 151.98mm Side View Dimension 40.80mm... -
Page 15: Package List
Package List Before you begin the installation or configuration process, make sure to inspect all the components and accessories. Contact your representative if there are any missing or damaged items. Please verify the delivery of the contents upon receipt VIKING in-vehicle terminal ... -
Page 16: Chapter 2. Hardware Installation
Chapter 2. Hardware Installation This chapter provides information for the installation and removal of SIM card Installing/Removing the SIM card The device provides dual micro SIM slots for cellular and wireless connection. One is accessible from external SIM cover (SIM1) and the other is inside (SIM2). You can either Install SIM card in external or internal SIM slot and this selection can be done via SIM slot assignment in Android setting. - Page 17 4. Remove the cover. 5. Once the service cover is removed, you can see the micro SIM card slot (SIM2). 6. To release the SIM card holder, slightly lift the front edge of the cover on the card holder and slide it backwards. Open the cover. 7.
-
Page 18: External Sim Slot (Sim1)
the SIM card holder. 8. Insert the SIM card into the SIM card holder. 9. Close the cover of the SIM card holder. External SIM slot (SIM1) 1. Shut down the system properly and disconnect the device from all power sources. 2. -
Page 19: Chapter 3. Hardware Mounting
Chapter 3. Hardware Mounting The VIKING supports a standard VESA version MIS-D, 75, C (75mm distance quadrate order, M5 thread, deepness 6mm) through the four drill holes on the back side of the device. Notes: To prevent any damage or injury, make sure the mounting bracket is securely attached. -
Page 20: Chapter 4. Start Up
Chapter 4. Start up Powering the System Installation Instructions Fuses are required in connecting the power cable and battery in series and add 3A fuse in ACC/ignition line to avoid the risks of wire damage and vehicle burning. Notes: 5A for 24VDC power input 10A for 12VDC power input Please refer to the diagram below for VIKING installation. -
Page 21: Connector Power
Connector Power VIKING allows a wide range of DC power input from 9~36V via a 5-pin M12 A-code power cord. There are two options to start up the VIKING, either via car power cable or external power adapter. Here is the 5-pin M12 A-code power cord. Use only power cables verified and supplied by RuggON to meet the specific requirements for voltage, current, low-temperature flexibility, UV resistance, oil resistance, etc. - Page 22 Power source from car power cable 1. The bare wire lead cable allows you to directly wire 12 V or 24 V car power supply. Please follow the wire definition to connect to your power source. Please refer to the installation diagram on page 20 to install the 5A or 10A fuse between the power cable and power source.
-
Page 23: Backup Battery
Power source from external power adapter If your power source is from external power adapter, it means the power source isn’t controlled by AAC/Ignition signal. Please short red (V+) and white (ACC/ Ignition) wires. VIKING will turn on automatically when power is connected. If you use software to power off the system, to turn on the VIKING you need to press and hold down the power button at least for 3 seconds. -
Page 24: Powering Down The System
Powering Down the System When VIKING is connected to vehicle battery When system is on, switch the ignition from on to off to turn off or delay off the system. When system is on, press the power button to turn off the system. To turn on the VIKING you need to press and hold down the power button at least for 3 seconds. -
Page 25: Led Status
LED Status The LEDs on VIKING are status indicators that show the operating status of your system. The status indicators can help pinpoint possible failed hardware components causing specific symptoms. There are two status indicators in the front panel. Refer to the description below. -
Page 26: Adjust The Speaker Volume
Adjust the Speaker Volume VIKING provides the volume control buttons to adjust the speakers’ volume; you can also control the overall level of sound using Android Setting. When you press the top part of the volume button, it makes the volume louder; pressing the bottom part makes the volume lower ... -
Page 27: Internal Microphone
Internal Microphone VIKING is equipped with 2 internal microphones (one at the front and the other at the rear) for better audio reception, so you don’t need an external one. In addition to the built-in speaker and microphones, you can plug external headsets in the audio jack. Programmable Buttons VIKING provides default commands for five programmable buttons. -
Page 28: Chapter 5. Jumpers And Connectors
Chapter 5. Jumpers and Connectors Bottom View DC-in GNSS (SMA Jack) DIO, CAN bus USB, RS-232/422/485 (COM2) RS-232 (COM1) with 5/ 12 V power output... -
Page 29: External Connectors Pin Assignments
External Connectors Pin Assignments Use this section as a reference for the pin assignments of the various ports available on the VIKING. Power Connector Description ACC/ Ignition Note: Please refer to section 1 in Chapter 4 for connecting the external power cable to power source. -
Page 30: Rs-232 Port (Com1)
RS-232 Port (COM1) Signal Description Data carrier detect (input) Receive data (input) Transmit data (output) Data terminal ready (output) Signal/power ground Data set ready (input) Request to send (output) Clear to send (input) 12V/300mA or 5V/600mA... -
Page 31: Usb And Rs-232/422/485 Port (Com2)
USB and RS-232/422/485 Port (COM2) Signal RS-422 TX+ RS-422 RX+ RS-485 TX+ RS-232 TX RS-422 TX- RS-422 RX- RS-485 TX- USB 5V RS-232 RX USB DP USB DM USB 5V We provide Y-cable with DB15 male connector which is the RS232/422/485 and USB converter. - Page 32 RS-232/422/485 and USB Cable This Y-cable with DB15 male connector is the RS232/422/485 and USB converter. The other end of this Y-cable contains one USB type A jack for USB2.0 and one DB9 male connector for RS232/422/485. If you like to use RS232 or RS422 or RS485, please refer to the pin definition below.
-
Page 33: Digital I/O And Canbus Port
Digital I/O and CANbus Port Signal CAN_H ISO_GND CAN_L DIO_OUT1 (5V, Max 5mA) DIO_IN1 (5V, Max 15mA) DIO_IN2 (5V, Max 15mA) DIO_OUT2 (5V, Max 5mA) We provide the DB15 male connector to multiple pins without termination cable. Please contact your local sales representative for ordering information... -
Page 34: Chapter 6. Technical Support
Chapter 6. Technical Support We provide the Partner Zone for technical documents information; please contact your sales representative to authorize the use of the RuggON Partner Zone.
