RuggVMC ruggon VIKING Quick Start Manual

Mobile Data Terminal

Product Introduction

Front View
Camera
(optional)
Speaker
Built-in RFID/ NFC reader
The LEDs on VIKING are status indicators that show the operating status of your system.
LED Status
Power Blink Green
Power Blink Yellow
Power Solid Green
Power Blink Red
Communication Solid Green
Please note power management, I/O configuration, and button settings can be
[鍵入文字] configured in Android Setting System Advanced. No DashON support in
VIKING.
Model: MT7030
VIKING
Quick Start Guide
st
1 internal Microphone
Ambient light sensor
Power
Volume
Power & Communication
LED indicators
Speaker
Function buttons
Description
Power up
Load boot loader
System ready to use
Vehicle battery abnormal
WWAN enabled
Product Introduction
Rear View
Notes: To prevent any damage or injury, make sure the mounting bracket is securely attached.
Bottom View
GNSS
(SMA jack)
USB, RS-232/422/485(COM2)
RS-232(COM1) with 5/12V power output
Optional WWAN Antenna Conn. (SMA jack)
Side View
Reset button
nd
2 internal Microphone
The VIKING supports a standard VESA
version MIS-D, 75, C (75mm distance
quadrate order, M5 thread, deepness
6mm) through the four drill holes on the
back side of the device.
USB Type-C DP Alt Mode
DC-in
Optional Wi-Fi/BT Antenna Conn.
(SMA jack)
DIO / CANbus
LAN
SIM Card Slot
Audio jack
Micro SD Card Slot
P/N: 25-13658-01
