Summary of Contents for Reltech GX200
- Page 1 SINGLE ELEMENT CARTRIDGE FILTER Installation and Operation USER MANUAL Models: GX200...
-
Page 2: Table Of Contents
TABLE OF CO N T EN T IMPORTANT SAFETY INSTRUCTIONS ..1. OVERVIEW ..1.1 PRODUCT INFORMATION 1.2 DIMENSIONS 2. INSTALLATION ..3. STARTING THE PUMP AND FILTER SYSTEM ..3.1 BEFORE STARTING THE PUMP 3.2 STARTING PUMP 3.3 OPERATION 4. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS THESE OPERATING INSTRUCTIONS CONTAIN IMPORTANT INFORMATION ON THE SAFE, PROPER, AND ECONOMICAL OPERATION OF THIS SWIMMING POOL APPLIANCE. STRICT OBSERVATION OF THE OPERATING INSTRUCTIONS WILL HELP TO AVOID DANGERS, REDUCE REPAIR COSTS, AND SHUTDOWN TIMES AND INCREASE THE RELIABILITY AND WORKING LIFE OF THE PRODUCT. Failure to follow the instructions in this manual may result in serious adverse health effects or even serious or fatal injury. -
Page 4: Overview
R E A D UN D ER S TA N D AND F O LLO W ALL S A FE T Y AND O P ER AT I O N : Do not operate the filter until you have read and understand clearly all the operating instructions and warning messages for all equipment that is a part of the pool circulating system. -
Page 5: Product Information
AREA Residential Commercial FT² M² GX200 18.58 [ Filter rate for residential use based on 1GPM/ft². Recommend Flow Rate for 2” piping is 90 x 150 GPM ] ≤ ≤ 1 . 2 D I M EN S I O N S Model 17.24... -
Page 6: Starting The Pump And Filter System
3. STARTING THE PUMP AND FILTER SYSTEM 3.1 BEFORE STARTING THE PUMP 1. Use ONLY GX system components: Lock Ring unit doing assembly, metal-reinforced seal. Non-tighten lock ring component may fail in use and cause explosive component separation. Verify that upper and lower filter bodies are properly secured with the filter body locking ring unit. -
Page 7: Operation
3 . 3 O P ER AT I O N Filtration starts as soon as the flow is steady through the filter. As the filter removes dirt from the pool water, the accumulated dirt causes a resistance to flow. As a result, the pressure will rise and the flow will decrease. 1. -
Page 8: Clean Seal Ring And Seal Surface
3. Carefully replace the cartridge over the hubs on the bottom manifold. 4. Place the upper body securely on top of the cartridge. 4 . 4 . 2 CLE A N S E A L RI N G AN D SE A L S UR FACE 1. -
Page 9: Removing The Air Relief Valve
4 . 5 R EM O V I N G T H E A I R R ELI EF VA LV E The filter comes with a preinstalled manual air relief valve. Ser vicing the Air Relief Valve should be carried out by pool professionals only, follow instructions carefully: 1. -
Page 10: Spare Part List
7. SPARE PART LIST Key No. Part No. Description 117068519 Pressure gauge 60psi, plastic casing 550188200 Upper Body ICF200 570818164 Nut D22X15 550058153 Lock Ring 550058196 Latch 11000036 O-ring D306Xd7.5 430178159 Union nut 2" 430308158 Union 2inch/2.5inch ANSI 111040071 O-ring D77Xd62X8 E140401 ICF100-200 Bottom Body E160553... -
Page 11: Terms Of The Warranty
Reltech, serviceable used parts that are equivalent or superior to new parts in performance. This Limited Warranty extends only to products purchased from Reltech authorized reseller. Does not extend to any product that has been damaged or rendered defective. - Page 12 POOL EQUIPMENT RELTECH AUSTRALIA PTY LTD 43-45 KYLTA RD, WEST HEIDELBERG VIC 3081 03 94593838 EM: office@reltech.com.au WEB: www.reltech.com.au www.reltech.com.au...
