CDX-GT23W/GT24/GT24EE
SERVICE MANUAL
Ver. 1.0 2008.07
• The tuner and CD sections have no adjustments.
CD player section
Signal-to-noise ratio: 120 dB
Frequency response: 10 – 20,000 Hz
Wow and fl utter: Below measurable limit
Tuner section
FM
Tuning range:
CDX-GT23W
87.5 – 107.9 MHz
CDX-GT24
87.5 – 108.0 MHz
CDX-GT24EE
FM1/FM2: 87.5 – 108.0 MHz
(at 50 kHz step)
FM3: 65 – 74 MHz
(at 30 kHz step)
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 150 kHz
Usable sensitivity: 10 dBf
Selectivity: 75 dB at 400 kHz
Signal-to-noise ratio: 70 dB (mono)
Separation: 40 dB at 1 kHz
Frequency response: 20 – 15,000 Hz
AM (CDX-GT23W)
Tuning range: 530 – 1,710 kHz
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 25 kHz
Sensitivity: 26 μV
Sony Corporation
9-889-222-01
2008G04-1
Audio&Video Business Group
©
2008.07
Published by Sony Techno Create Corporation
(Photo: CDX-GT23W)
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
SPECIFICATIONS
MW/LW (CDX-GT24/GT24EE)
Tuning range:
MW: 531 – 1602 kHz
LW: 153 – 279 kHz
Antenna (aerial) terminal:
External antenna (aerial) connector
Intermediate frequency: 25 kHz
Sensitivity: MW: 26 μV, LW: 45μV
Power amplifi er section
Outputs: Speaker outputs (sure seal connectors)
Speaker impedance: 4 – 8 ohms
Maximum power output: 45 W × 4 (at 4 ohms)
General
Outputs:
Audio outputs terminal (sub/rear switchable)
(CDX-GT23W only)
Power antenna (aerial) relay control terminal
Power amplifi er control terminal
(CDX-GT23W only)
FM/AM COMPACT DISC PLAYER
FM/MW/LW COMPACT DISC PLAYER
US Model
Canadian Model
CDX-GT23W
Russian Model
CDX-GT24/GT24EE
CDX-GT33W/GT330
MG-101L-188//C
DAX-25A
Inputs:
Antenna (aerial) input terminal
AUX input jack (stereo mini jack)
Tone controls:
Low: ±10 dB at 60 Hz (XPLOD)
Mid: ±10 dB at 1 kHz (XPLOD)
High: ±10 dB at 10 kHz (XPLOD)
Power requirements: 12 V DC car battery
(negative ground (earth))
Power supply voltage: 11 – 16 V
Dimensions: Approx. 178 × 50 × 179 mm
× 2 × 7
1
1
(7
/
/
in.) (w/h/d)
8
8
Mounting dimensions: Approx.
182 × 53 × 162 mm
× 2
× 6
1
1
1
(7
/
/
/
in.) (w/h/d)
4
8
2
Mass: Approx. 1.2 kg (2 lb 11 oz)
Supplied accessories:
Parts for installation and connections (1 set)
Design and specifi cations are subject to change
without notice.
CDX-GT23W
CDX-GT24/GT24EE
