- Page 1 CONTACTLESS DSES Ref: DSESC USER GUIDE -...
- Page 2 The DSES system is an additional electronic safety system. It does not eliminate the risk of cuts in any circumstances. INFACO cannot be held liable for accidents. Users are warned that INFACO cutting tools must be handled with maximum precautions.
-
Page 3: Table Of Contents
Contents Precautions before use Protection of the environment Kit contents General product view Specifications Operating principle Contactless DSES Recharging the transmitter battery Assembly instructions LED indications... -
Page 4: Precautions Before Use
Observe all country-specific waste disposal rules and regulations. > Power tools must not be disposed of with household refuse. > The device, accessories and packaging must be taken to a recycling centre. > Ask the approved INFACO dealer for up-to-date information on the eco-compatible elimination of waste. -
Page 5: Kit Contents
Kit contents a standard receiver module a USB type C cable (CUSBC) (911CC) or medium (911CCM) a tube of grease (GCONT) a transmitter module (912EP) an instruction manual two screws (V325) (NOT_DSESC_3020) a charger (CHUSB) a USB cable holder... -
Page 6: General Product View
General product view Must be used with a Contactless DSES compatible glove from * INFACO. This glove (hand opposite the pruning shears) is used to carry the transmitter module. glove sold separately. Only the following 3 models are compatible with Contactless DSES. -
Page 7: Specifications
Specifications Transmitter module Receiver module Power supply Lipo 3.7V battery Autonomy Range <1m / 39 inches Configurable zone Recharge USB-C in 1h30 Dimensions L x W x D 32x58x15 mm / 80x96x20 mm / 1”1/4x2”/1/4x2/3 3”x3”3/4x3/4 These specifications are given as an indication only. Under no circumstances may they be considered as contractually binding.They are subject to modification without prior notice in the interests of product development. - Page 8 The receiver is configured to create a virtual safety zone around the cutting head. The transmitter sends a signal to the receiver which it uses to determine the position of the hand from the pruning shears cutting head. If the hand not holding the pruning shears enters the safety zone around the cutting head, the blade opens automatically.
-
Page 9: Contactless Dses
A leather work glove can be worn, for example when pulling wood, as the system does not operate when in contact with the user (see section “ INFACO carrying gloves “, page 12 for possible solutions). - Page 10 Wearing the transmitter in the glove requires systematic visual checks as well as checking the battery charge level when in use. INFACO declines any liability for failures due to the poor condition of the transmitter, the loss of the transmitter during use, insufficient transmitter battery charging and/or non-compliance with the procedures described in this manual.
- Page 11 When using for the first time, we strongly recommend that you seek the assistance of an INFACO dealer. They are authorized to provide all the advice needed for proper use and maintenance.
- Page 12 IMPORTANT: The use of the INFACO carrying glove is mandatory to: • Optimize the safety zone; • Improve hand detection; • Not lose the transmitter during use. INFACO carrying gloves Important reminders: • The use of INFACO carrying gloves is mandatory;...
- Page 13 Contactless DSES is available as an option. The function must be activated by an authorized INFACO dealer when the system is installed on the pruning shears. This kit must be installed by an approved INFACO dealer. Only they can configure the pruning shears to operate with this safety system.
- Page 14 The system must be checked frequently to make sure it is in working order. DSES DSES ACTIVE INACTIVE When powering on, During use, DSES During use, the DSES status check that status LED is off LED is red all the LEDs are in = DSES is active = DSES is inactive, working order...
- Page 15 During use, the DSES can be inactive with the status LED red in 2 possible cases: • Momentary and deliberate stop 0.3 s The DSES is inactive for a single cut and then automatically reactivates: You are not protected during the single cut. •...
- Page 16 Selecting the safety zone size Contactless DSES creates a virtual safety zone around the cutting head. There are 3 safety zone dimensions configured in the pruning shears. The zone should be selected according to the required safety level and the hand size. The "safety zone selection"...
- Page 17 Contactless DSES cover is in good condition and correctly fitted to the pruning shears. To select and/or check a safety zone, you can contact an authorized INFACO dealer, or use the procedure below: Switch the transmitter on by moving it back and forth. Check that the bar...
- Page 18 Press the trigger and keep it pressed. After one second, the DSES configuration mode is activated. The DSES LED flashes, the status LED switches to steady red and the bar graph LEDs indicate which safety zone is currently selected: To select the safety zone, while keeping the trigger pressed, press the "settings"...
- Page 19 When the transmitter enters the Example with level 3 safety zone, the status LED turns green. Release the trigger to confirm the selection. Safety system check It is recommended to frequently check that the safety system is working properly throughout the day: Check that the transmitter is switched on (green LEDs);...
-
Page 20: Recharging The Transmitter Battery
Charge the battery before using the device for the first time or when it has not been used for some time. Only use batteries, chargers and USB type C cables supplied by INFACO and specially designed for the device. The use of an incompatible battery,... - Page 21 Do not short-circuit / Do not replace with incorrect battery type / Do not dispose of in fire / Do not crush battery. Risk of explosion if mishandled. Incorrect charger connection can seriously damage the device. Damage resulting from incorrect use is not covered by the warranty. Charging the transmitter •...
- Page 22 To save energy, disconnect the charger when not in use. As the charger is not fitted with an "on/off" switch, it must be unplugged from the mains power outlet for the power supply to be cut. When the battery is fully charged, the 3 bar graph LEDs are on and steady. Disconnect the charger from the device.
-
Page 23: Assembly Instructions
Assembly instructions To change the blade on your pruning shears, make sure to switch them off and/or disconnect them from the battery, then proceed as follows: CLICK! Using the cross tip on the tool, unscrew the 2 screws and remove the Contactless DSES cover(2);... - Page 24 10. Before refitting the Contactless DSES cover, check that there is contact grease on the area where the contact pads on the Contactless DSES board are located. If that is not the case, use the tube of grease supplied in the DSESC kit to apply grease to the area;...
-
Page 25: Led Indications
LED indications INDICATIONS ON THE PRUNING SHEARS Contact or unlocking problem: • Check that the cover is correctly fitted, that there is no dirt in the contact area and that there is grease. Flashing red DSES • Check that the transmitter module is switched on. DSES inactive: The DSES system may be deactivated. - Page 26 If possible, test the charger on a different module; LEDs off when charging • If possible, test using a different INFACO charger. If the problem persists, contact a dealer Regardless of the circumstances, with or without the Contactless DSES safety system, users must imperatively make sure the hand not holding the pruning shears is always at least at a 20 cm / 8 inch safety distance from the tool blade.
- Page 28 w w w . i n f a c o . c o m EN - User manual CONTACTLESS DSES NOT_DSESC_EN_06_24...
