AUTOMATIC FILTRATION SYSTEM
Installation and configuration manual
Klereo Flo
Read carefully and to keep for further consultation (Version 1.0-2020)
1- The contents of this booklet are subject to change without prior notice.
2 - Due to print restrictions, displays in this booklet may differ from those of the
product.
3 - The contents of this booklet cannot be reproduced without the manufacturer's
permission.
Advertisement
Table of Contents
Related Manuals for Klereo Flo
Summary of Contents for Klereo Flo
- Page 1 AUTOMATIC FILTRATION SYSTEM Installation and configuration manual Klereo Flo Read carefully and to keep for further consultation (Version 1.0-2020) 1- The contents of this booklet are subject to change without prior notice. 2 - Due to print restrictions, displays in this booklet may differ from those of the product.
-
Page 2: Table Of Contents
Contents 1. IMPORTANT SAFETY INSTRUCTIONS 2. INTRODUCTION 3. COTENTS KLEREO FLO 4. TECHNICAL SPECIFICATIONS and DIMENSION 5. INSTALLATION 6. SETTING and OPERATION 7. CONNECTION 8. TROUBLEshootING 9. MAINTENANCE 10. GENERAL WARNING 11. TERMS AND CONDITIONS APPLICABLE... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed RISK OF ELECTRIC SHOCK. Make sure your installation is connected to a ground hold. This pump must be installed by a qualified technician. A poor installation can pose a serious danger to pool users or others due to an electric shock and can also damage property. -
Page 4: Introduction
The Klereo Flo variable-speed pump ensures water filtration while saving energy. Klereo Flo allows you to program the speed of traffic according to the need of the basin. This feature can be set on the pump, on your Klereo cabinet if associated with a water treatment... - Page 5 3. CONTENT OF THE KLEREO FLO PACKAGE Basket Display Cover Moteur pump Corps de pompe Support moteur Anneaux déverrouille 2 Joints pour raccords Wire of Klereo 2 Raccords entrée couvercle connections sortie pompe 4. SPECIFICATIONS & DIMENSIONS Size...
-
Page 6: Installation
Performance Curve Références P1/CV* Recommended Max Flow m3/h** Sound level at Sound level at volume 1m dB (A) 10m dB (A) KL71-KFL10 40~55 14.5 38.5 ~ 51.3 18.9 ~ 31.3 KL71-KFL15 50~80 20.5 40.5 ~ 53.6 20.5 ~ 33.6 5. INSTALLATION Location of the pump Place the pump as close to the pool as possible and make suction lines as straight as possible to reduce loss or friction. - Page 7 Piping The piping on the suction side of the pump should be the same size or larger than the output. Discharge Discharge 63 mm 50 mm 63 mm 63 mm Aspiration Aspiration We advise you to install a valve on the pump suction and on the return line so that the pump can be insulated during maintenance Valves and fittings Do not install elbows at 90 degrees directly in the pump entrance.
-
Page 8: Setting And Operation
6. SETTING AND OPERATION Interface Manual mode Manual mode Manual mode On/off Locking/Washing against the current: When the screen is locked, press 3 seconds to unlock it; When the screen is unlocked, press the button for the back-wash mode. High: Increase value (capacity and time) Low: value of decline (capacity and time) Timer : Switching from manual to Timer... - Page 9 Setting the range Display Icon Description Setting the start time Defining capabilities Fixing the end time 4 timer sequence:1 2 3 4 *Any overlap time adjustment will be considered invalid, the device will only work on the basis of the previous valid setting.
-
Page 10: Connection
Pompe de filtration Câble de communication externe* 220 V External communication cable: Cable to connect to Klereo cabinet to manage filtration Filter pump configuration connected with Klereo To benefit from this configuration you need to have the 2.04G software version or more. - Page 11 The filtration pump can be powered in several ways: Via the release [V-VN] on a Kompact box set - M9 Klereo Flo Alimentation électrique 220V Via the Klereo Kompact + M9...
- Page 12 Parameter Configuration Config.pump Step 1: Select the Klereo Flo Bus Communication Bus and then adjust to access the configuration Depending on the configuration of your Kompact + M9 you will be able to indicate to the system if you used a contactor or not.
- Page 13 Step 3: You can choose for each speed, percentage power (%) you want to attribute it to it. Example for a 3 Vitesses filtration pump : Your Klereo pump is now ready to work with your Klereo cabinet. You can adjust the pump speeds based on various parameters.
-
Page 14: Troubleshooting
Ecl&Aux.imp : When the lighting or an odd auxiliary (Aux1, Aux3, Aux On peut affecter une 5...) is on the filtering will switch to the selected speed. Aux.pairs : When a pair auxiliary (Aux2, Aux4, Aux 6...) is running the vitesse à... -
Page 15: Maintenance
ERROR CODE Item Code Description Analysis E001 Abnormal input voltage Not faulty E002 Output over current Not faulty E101 Heat sink over heat Contact your supplier E102 Heat sink sensor error Contact your supplier E103 Master driver board error Contact your supplier E201 Circuit board error... - Page 16 Name NAME Union Collar Flat Key Slip Adapter O-Ring O-Ring Impeller Drain Plug Mechanical Seal O-Ring Seal Plate Pump Body Washer Strainer Basket Hexagon bolt O-Ring Motor Transparent Lid Washer Nut For Lid Hexagon bolt O-Ring Motor Support Plastic Sterips O-Ring Base Diffuser...
- Page 17 Normal wear. Water penetration or exposure to abnormal corrosive conditions or dry operating situations. Insect penetration into the pump causing electrical malfunctions Klereo 5, rue du Chant des Oiseaux 78360 Montesson France Email : contact@klereo.com Tél. : 08 92 690 415 (0,34 € TTC/minute)
