Mammoth MOTHMAN FUZZ Assembly Instructions

MOTHMAN FUZZ ASSMEBLY INSTRUCTIONS
Thank you for purchasing the MothMan Fuzz Effect Pedal Kit from Mammoth Electronics!
This is a beginner level kit that and we have made every effort to make the assembly as easy as possible.
RECOMMENDED TOOL AND SUPPLY LIST
Soldering station (with temperature control/regulation)
•
Solder & Flux
•
De-soldering braid or solder sucker
•
Wire strippers
•
Wire cutters
•
Phillips head screwdriver
•
Double-stick foam tape
•
Part
.1uF
1uF
.01uF
47uF
.027uF
1K
3.3K
50KA
50KB
1N914
1N4001
Green LED
MPSA13
1/4" Mono Jack
1/4" Stereo Jack
3PDT Stomp Switch
DC power Jack
Battery Snap
LED Bezel
3PDT Wiring Board
MothMan PCB
Click-Less Module
If you have any questions about building the MothMan Fuzz or need any help with trouble shooting, please send us an
email at sales@mammothelectronics.com
MOTHMAN FUZZ KIT PARTS LIST
Position
C1
C2
C3
C4
C5
R1
R3
R2 Tone
R2 Volume
D1
D2
D3(On/Off Indicator)
Q1
Output Jack
Input Jack
On/Off switch
DC Power Jack
(optional)
On/Off Indicator
On/Off switch
Main PCB
Standalone (Optional)
or give us a call at 405-254-4112.
©2013 MAMMOTH ELECTRONICS, ALL RIGHTS RESERVED
Quantity Mammoth Part #
1
300B-MMK5
1
300B-MMK5
1
300B-MMK5
1 301-GP-16V
1 300-ECQ-V1H
1 110-271-RC
2 110-271-RC
1 200-100-A
1 200-100-B
1 120-1000
1 120-1010
1 4SLED5MMGR
1 100-1011
1 4SJK100M
1 4SJK100S
1 4SFS3PDT-PR
1 4SJK-101DC
1 4SJK-9VSNP-2
1 4SLEDBZ5-1
1 4SBRD-4SFS3PDTLRG
1 Mothman Fuzz PCB
1 Click-Less True Bypass
