StrongHandTool BUILDPRO TD5-4830Q-F3 Assembly Instruction Manual

48" x 30" rhino cart
Hide thumbs

Advertisement

Quick Links

Download this manual
SETUP INSTRUCTIONS
Tabletop Sizes:
48" x 30"
Tabletop Frame Height:
4"
(800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
- 48" x 30" RHINO CART
Tabletop Flatness:
±0.015" per 24" x 24"
Gross Weight:
490 lb
BUILDPRO
TD5-4830Q-F3
1.
PARTS LIST
2.
ASSEMBLY INSTRUCTION
3.
OPTIONAL ACCESSORIES
4.
RELATED PRODUCTS
5.
MAINTENANCE
6.
SAFETY
7.
LIMITED WARRANTY
Static Loading Capacity:
1,500 lb
®
Welding Tables

Advertisement

loading
Need help?

Need help?

Do you have a question about the BUILDPRO TD5-4830Q-F3 and is the answer not in the manual?

Questions and answers

Related Manuals for StrongHandTool BUILDPRO TD5-4830Q-F3

Summary of Contents for StrongHandTool BUILDPRO TD5-4830Q-F3

  • Page 1 BUILDPRO ® Welding Tables TD5-4830Q-F3 SETUP INSTRUCTIONS - 48" x 30" RHINO CART PARTS LIST ASSEMBLY INSTRUCTION OPTIONAL ACCESSORIES RELATED PRODUCTS MAINTENANCE SAFETY LIMITED WARRANTY Tabletop Sizes: Tabletop Flatness: Static Loading Capacity: 48" x 30" ±0.015" per 24" x 24" 1,500 lb Tabletop Frame Height: Gross Weight:...
  • Page 2 BUILDPRO BUILDPRO PARTS LIST PARTS LIST ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 Carefully unpack all Carefully unpack all Thoroughly read Thoroughly read It is recommended to It is recommended to Contact our customer Contact our customer parts and components parts and components service if any service if any...
  • Page 3 PARTS LIST PARTS LIST BUILDPRO BUILDPRO ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 Hardware Hardware Not shown in picture: Not shown in picture: Attachments: Attachments: Description Description Description Description M10 x 20 M10 x 20 Support Rack Support Rack M10 Nylon Nut M10 Nylon Nut M10 Black-oxide Washer...
  • Page 4 BUILDPRO BUILDPRO ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 OPTION 1 & 2 OPTION 1 & 2 Option 1: Steps 3-10 Option 1: Steps 3-10 Option 2: Steps 11-18 Option 2: Steps 11-18 The yellow square hole plate can be installed on the left or right side The yellow square hole plate can be installed on the left or right side STEP 1 STEP 1...
  • Page 5 ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION BUILDPRO BUILDPRO ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 2 STEP 2 B4 B5 B6 B4 B5 B6 STEP 3 STEP 3 B4 B5 B6 B4 B5 B6 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
  • Page 6 BUILDPRO BUILDPRO ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 4 STEP 4 B4 B5 B6 B4 B5 B6 STEP 5 STEP 5 B1 B2 B1 B2 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
  • Page 7 ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION BUILDPRO BUILDPRO ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 6 STEP 6 B1 B2 B3 B1 B2 B3 STEP 7 STEP 7 B7 B8 B7 B8 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
  • Page 8 BUILDPRO BUILDPRO ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 8 STEP 8 B4 B5 B6 B4 B5 B6 STEP 9 STEP 9 B4 B6 B4 B6 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
  • Page 9 ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION BUILDPRO BUILDPRO ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 10 STEP 10 STEP 11 STEP 11 B4 B5 B6 B4 B5 B6 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
  • Page 10 BUILDPRO BUILDPRO ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 12 STEP 12 B4 B5 B6 B4 B5 B6 STEP 13 STEP 13 B1 B2 B1 B2 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
  • Page 11 ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION BUILDPRO BUILDPRO ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 14 STEP 14 B1 B2 B3 B1 B2 B3 STEP 15 STEP 15 B7 B8 B7 B8 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
  • Page 12 BUILDPRO BUILDPRO ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 16 STEP 16 B4 B5 B6 B4 B5 B6 STEP 17 STEP 17 B4 B6 B4 B6 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
  • Page 13 BUILDPRO BUILDPRO ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION ® ® Welding Tables Welding Tables TD5-4830Q-F3 TD5-4830Q-F3 STEP 18 STEP 18 STEP 19 STEP 19 (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A. (800) 989-5244 | stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.

  • Page 14: Maintenance

    BUILDPRO ® Welding Tables TD5-4830Q-F3 Maintenance Keep the cart clean for optimal performance. Wipe away dust and debris from the tabletop and legs. Safety ALWAYS wear safety goggles, gloves, and other appropriate safety items for protection. Use the cart only for it’s intended purpose. NEVER stand on the cart.
