Tool Cart
BuildPro
®
(Part No. TMC8080)
Dimension
Capacity
Net Weight
Part No.
31'' W x 20'' D x 43'' H
220 LBS
79 LBS
TMC8080
(800 x 500 x 1,100 mm)
(100 kg)
(36 kg)
1.562.949.8625 | www.stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
Advertisement
Related Manuals for StrongHandTool BuildPro TMC8080
Summary of Contents for StrongHandTool BuildPro TMC8080
- Page 1 Tool Cart BuildPro ® (Part No. TMC8080) Dimension Capacity Net Weight Part No. 31‘’ W x 20‘’ D x 43‘’ H 220 LBS 79 LBS TMC8080 (800 x 500 x 1,100 mm) (100 kg) (36 kg) 1.562.949.8625 | www.stronghandtools.com | sales@stronghandtools.com | 8750 Pioneer Blvd., Santa Fe Springs, CA 90670 U.S.A.
- Page 2 Part No. TMC8080 ® BuildPro Tool Cart » Carefully unpack all parts and components and compare to the Parts List inventory below. Read all assembly instructions before beginning to assemble your BuildPro Tool Cart. During assembly, do not tighten bolts until all components are properly aligned, then tighten fully. Item Item Tool Organizer Plate...
- Page 3 Assembly Instructions Part No. TMC8080 ® BuildPro Tool Cart » Tools required for assembly : wrenches, phillips screwdriver and pliers. Assemble the Tool Cart frame by attaching the Attach the top shelf (B) to the frame assembly vertical and horizontal support assemblies (D, E) to using Flush Shoulder Screws (Q4) Hex Nuts (R2) the bottom shelf (C) using Flush Shoulder Screws and Washers (S).
- Page 4 Assembly Instructions Part No. TMC8080 ® BuildPro Tool Cart Attach Magnetic Tool Bars (P) to the Bridge Install the top Tool Organizer Plate using Hex Channel (F) using Hex Head Bolts (Q2), Hex Nuts Head Bolts (Q2), Nuts (R2) and Washers (S). (R2) and Washers (S).
