Summary of Contents for Candy CSOEC10TG-80
-
Page 3: Table Of Contents
Thank you for choosing this product. WEEE contains both polluting substances (which We are proud to offer the ideal product for can cause negative consequences for the you and the best complete range of home environment) and basic components (which can appliances for your daily routine. -
Page 4: General Safety Rules
1. GENERAL SAFETY in a safe way and understand the hazards involved. RULES Children shall not play with the This appliance is intended to appliance. Cleaning and user be used in household and maintenance shall not be made similar applications such as: by children without supervision. - Page 5 Do not continue to use this The final part of a tumble dryer machine if it appears to be faulty. cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature The tumble dryer is not to be ...
- Page 6 In cases where the dryer is Once the machine is in place installed on top of a washing the feet should be adjusted to machine, a suitable stacking kit ensure that the machine is must be used according to the level.
- Page 7 Do not use adapters, multiple Prevent items from falling or connectors and/or extensions. collecting behind the dryer as these may obstruct the air inlet The plug should be accessible and outlet. disconnection after appliance has been installed. Exhaust must ...
- Page 8 Fabric softeners, or similar Items that have been soiled products, should be used as with substances such as cooking specified by the fabric softener oil, acetone, alcohol, petrol, instructions. kerosene, spot removers, turpentine, waxes and wax Do not dry unwashed items in ...
-
Page 9: Water Containers
2. WATER CONTAINERS ONLY FOR MODELS WITH DRAIN HOSE KIT The water removed from the laundry during If you have the option of drainage the drying cycle is collected in a container. near to the dryer you can use the When the container is full, an indicator light, discharge kit to provide a permanent or on some models a message on the... -
Page 10: Door, Filter And Condenser
3. DOOR, FILTER AND If the laundry is not drying check that the CONDENSER filter is not clogged. Door If you clean filter under water, remember to dry it. Pull on handle to open the door. To restart the appliance, close the door ... - Page 11 To clean the condenser 1. Remove the kickplate. 2. Turn the locking levers anti-clockwise and pull out the condenser. 3. Pull out the condenser unit. 4. Gently remove any dust or fluff with a cloth, then wash the unit by holding it under a running tap turning it so that water flows between the plates, to remove any dust or fluff.
-
Page 12: Practical Hints
4. PRACTICAL HINTS ALWAYS Check that the filter is clean before every Before using the tumble dryer for the first drying cycle. time: Please read this instruction book NEVER thoroughly. Put dripping wet items into the tumble dryer, this may damage the appliance. - Page 13 Cleaning the dryer WARNING The drum, door and load may be very Clean the filter and empty the water hot. container after every drying cycle. Regularly clean the condenser. After each period of use, wipe the inside WARNING of the drum and leave the door open for a Always switch off and remove the plug...
-
Page 14: Remote Control (Wi-Fi)
5. REMOTE CONTROL (WI-FI) This appliance is equipped with Wi-Fi Start the cycle using the app. When the technology that allows you to control it cycle has been completed, turn off the remotely via App. machine by turning the programme selector to the OFF position. -
Page 15: Quick User Guide
6. QUICK USER GUIDE 7. CONTROLS AND PROGRAMMES 1. Open the door and load the drum with laundry. Ensure that garments do not hinder closure of the door. 2. Gently close the door pushing it slowly until you hear the door 'click' shut. 3. - Page 16 To start the selected cycle with the preset WARNING parameters, press START/PAUSE. When the programme is running, the display will Don’t touch the buttons while inserting show the time to elapse. plug because machines calibrates the systems during the first Moreover, if you want to modify the ...
- Page 17 PAUSING THE MACHINE In case of incompatibility, all indicator lights flash quickly for 3 times. Keep the START/PAUSE button pressed for about 2 seconds (the name of the programme and the residual time display MEMO button will flash, showing that the machine is paused).
- Page 18 In case of incompatibility, all indicator Display lights flash quickly for 3 times. The display shows the remaining time for drying, the postponed time in case of delayed start selection other SUPER EASY IRON button notifications setting. During the cycle the option sets alternate ...
- Page 19 - SLOW BLINKING FOR 3 TIMES, THEN Information for Test Laboratory OFF FOR 2 SECONDS: reset of the Wi-Fi network (during the association with the App). EN 61121 - Programme To Use - ON FOR 1 SECOND, THEN OFF FOR 3 - STANDARD DRY COTTON SECONDS: the door is open.
- Page 20 Table of programmes Selectable Options PROGRAMME - - - Full ECO COTTON Full WHITES - - - JEANS - DARKS & COLOURED SYNTHETICS - SHIRTS WOOL - - - DAILY PERFECT 59' DAILY 45' - ...
- Page 21 Attention: felting process of wool is Description of programmes irreversible; please dry exclusively with symbol "ok tumble" on the garment To dry different types of fabrics and colors, the label. This programme is not indicated tumble dryer has specific programs to meet for acrylic clothes.
-
Page 22: Troubleshooting And Warranty
8. TROUBLESHOOTING Has the drying time or the programme been selected? AND WARRANTY Has the machine been switched on again What might be the cause of... after opening the door? Defects you can remedy yourself The dryer is noisy… Before calling Service for technical advice Switch off the dryer and contact Service ... - Page 23 Maximum support page of our web site. Power [mW] Hereby, Candy Hoover Group Srl By placing the mark on this declares that the radio equipment is in product, we are confirming compliance compliance with Directive 2014/53/EU.
- Page 24 Capacity Energy Time Capacity (kg) Class Energy 4,44 5,04 5,64 6,24 6,80 Whites Time Min. Energy 4,18 4,75 5,31 5,88 6,44 Whites Time Min. Energy 3,70 4,20 4,70 5,20 5,70 Cotton Time Min. Energy 2,05 2,31 2,56 2,80 3,00 Cotton ½ Time Min.
