Wellclima DOUBLE E.S. Quick Start Manual

!You are viewing the instruction manual for the 2024 model "DOUBLE E.S".
To avoid confusion, please double-check that you have chosen the correct manual.
If you need the manual for the previous model DOUBLE, please access that version.
Please insert 2 alkaline batteries 1,5V type AAA and plug-in the Air Conditioner to the elecric line.
You can choose 3 different ways (A, B or C) to set the remote control.
Direct code storage
A
1.
Connected to www.wellclima.com/en/manuals website, click on Brands and Codes List of
DOUBLE ES model, find the brand of your air conditioner and its codes on the right, these are internal
codes that don't match the AC product code and must be tested with your remote control. If your brand
is not in the list you can send an e-mail to info@wellclima.com.
Press and hold SET button, then press POWER
flashes on bottom of the screen. Press 'TEMP▲' or 'TEMP▼' up to the first code found in Step1
appears, aim the remote to the AC (you can also scroll in descending order or hold down the keys for
faster scrolling), change the code with the arrows until the AC turns on, then press SET to confirm.
Check the button functions. If the device respond correctly the setting is finished, if not, repeat steps 2
and 3 with next code. Enter the correct code in the designated space on the back of the remote and
set the security lock as described in step 1 of "INSTRUCTIONS FOR ADDITIONAL FUNCTIONS".
LOOK OUT! when you find the sign "-" between two codes you have to try all the numbers between
the first and the second one (e.g. LG: 600-609 it means 600, 601, 602....> up to 609).
If none of the codes works or if your brand is not in the list, don't worry, write by sending the informa-
tion of your air conditioner to info@wellclima.com or try searching from the remote control ( B ).
B Code search from the remote control
Point the remote control towards the indoor unit of the air conditioner. Hold down the SET button, then
press and hold the POWER
you will see the code increase.
Release the buttons and the remote will start scanning for codes. For each new code, a power-on
command will be sent to the air conditioner. IMMEDIATELY press a button as soon as the air conditio-
ner turns on. It's very important to be quick, otherwise the remote move to another code. Press the
POWER button to check that the air conditioner turns off and on, then press SET button. If not, you
can use the TEMP button to go back to the previous code and try again until you get the correct code.
If the code stops flashing, reactivate it by following step 2 of the DIRECT CODE STORAGE (A).
Test the other functions of the remote. If everything works well, the setup is complete, otherwise repeat
steps 1 and 2.
Remember to write the code on the back of the remote and set the security lock as described in
section 1 of "INSTRUCTIONS FOR ADDITIONAL FUNCTIONS".
!
Wellclima remote controls have the highest compatibility in the market, which is why the automatic
search may take some time. But don't worry, you can stop it by pressing the SET button and resume it
later.
C>
This is a quick and easy setting, available only for the brands listed in this table:
1. Point the remote control towards the indoor unit of the AC.
2. Press and hold the button indicated in this table for your brand
(e.g. the ▲ button for LG and Samsung) until the air conditioner
turns on with a beep. Release the button immediately, the setup is completed.
3. Test the other buttons on the remote control; if they work, the programming is finished, otherwise
repeat steps 2-3. At the end, as always, activate the security lock, as described in section 1 "ADDI-
TIONAL FUNCTIONS".
DOUBLE E.S.
6 languages on: wellclima.com/manual/double-es
button. Look at the bottom right of the display, after about 6 seconds,
(for some of the major brands only)
MIDEA-COMFEE
WINTAIR
button and release both buttons, the symbol '----'
AUX - AUFIT
FUJITSU-GENERAL
- HEC
ELECTROLUX
TOSHIBA
