Skydio X10D Maintenance Manual

Hide thumbs Also See for X10D:

Advertisement

Table of Contents

Skydio X10D
Maintenance Manual
WARNING: Please read all documentation provided with your Skydio X10, including but not limited to the
!
X10 Safety Guidelines in the Safety and Operating Guide:
instructions or recommendations in our documentation may void the Skydio Limited Warranty.
www.skydio.com/safety.
Failure to follow any

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X10D and is the answer not in the manual?

Questions and answers

Related Manuals for Skydio X10D

Summary of Contents for Skydio X10D

  • Page 1 Skydio X10D Maintenance Manual WARNING: Please read all documentation provided with your Skydio X10, including but not limited to the www.skydio.com/safety. X10 Safety Guidelines in the Safety and Operating Guide: Failure to follow any instructions or recommendations in our documentation may void the Skydio Limited Warranty.

  • Page 2: General Information

    This manual is designed to provide users with maintenance procedures and schedules to ensure optimal flight behavior. A life-cycle table to record and track flight hours is included. Read the Operator Manual for detailed information about flying your Skydio X10D. Sections divide the manual into major categories of information: • Equipment •...

  • Page 3: Hardware Overview

    A4 Side attachment bay and 50-Watt USB-C port and seal Top attachment bay mounting points (3) A3 Side attachment bay and 50-Watt USB-C port and seal Top attachment bay 50-Watt USB-C port and seal Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.
  • Page 4 Bottom attachment bay mounting points (3) Bottom attachment bay 50-Watt USB-C port and seal Parachute strap connector Arm hinges (4) Bottom navigation cameras (3) Time of flight sensor Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.
  • Page 5 Front landing feet (2) Radiometric thermal camera Narrow color EO camera Telephoto camera Cooling fan outlet USB-C pairing, updating, and charging port Power button Battery charge level indicator light Battery Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.
  • Page 6 Equipment Hardware Overview Micro SD logs memory card slot Micro SD media memory card slot HDMI port and seal Cooling fan USB-C charge port and seal Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.

  • Page 7: Fleet Management

    Fleet Management Updates Fleet management of your Skydio drones includes updates, passwords, data storage, and deleting media as needed. Ensure that your batteries have a full charge to complete the update. Step 1 - Access the files from Skydio Fleet Manager for Offline Drones •...

  • Page 8: Data Storage

    Step 1 -Select the Global Settings icon and the Media menu • Individual thumbnails can be selected to view in full screen • Select single or multiple to export • Select the trashcan to delete Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.
  • Page 9 Fleet Management Passwords You will be prompted to set a password for your X10D system. It is recommended that you occasionally update your password per your organizations guidelines. To change your original password: Step 1 - Select the Global Settings menu and Information Step 2 - Select change password WARNING: The password cannot be recovered or reset.

  • Page 10: Maintenance

    • Do not remove the sensor package or any attachments while the drone is wet CAUTION: Do not stow Skydio X10D while wet. Skydio X10D is IP55 rated and able to fly in light to moderate precipitation. It is expected for water to enter areas of the drone and draining postflight is normal. Sensitive components are protected.
  • Page 11 Maintenance Inspect Propeller Hubs Skydio X10D propellers are designed for up to 250 hours of useful life under normal flight conditions. Useful life may be reduced for vehicles accumulating substantial flight hours in high-stress flight conditions, including: • Sustained flight airspeed above 33 mph (53 km/h) •...
  • Page 12 Maintenance Replace Propellers For optimal performance, Skydio recommends replacing your propellers after 250 hours of flight time or whenever you notice any damage. Step 1 - Remove old or damaged propeller set • Hold onto the motor with one hand and take the propeller hub in the other •...
  • Page 13 Lifespan The lifespan of a Skydio X10D battery is 300 battery cycles. A battery cycle is the depletion of at least 80% of the charge. After this point, you may experience a decline in charging and performance. Battery life is highly dependent on your use case, and Skydio recommends replacing your battery when the flight time has degraded below what is acceptable for your use case.

  • Page 14: Preflight Inspection

    Inspect cooling fan outlet - for debris or blockage Check all USB-C port seals for leaks or damage Ensure that all USB-C port seals are secured Ensure that the sensor stabilizer clip has been removed Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.
  • Page 15 Examine sensor cameras for lens clarity Operator Inspect hours 10 flight Check gimbal motors for movement Operator Inspect hours 10 flight Inspect gimbal isolators for wear or damage Operator Inspect hours Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.
  • Page 16 Factory service to replace cameras and recalibration On fault Skydio Replace and repeat end of line tests or damage On fault Replacement or update sensor Operator Replace or damage Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.
  • Page 17 #A0487 Skydio X10D - Maintenance Manual © 2024 Skydio, Inc. All rights reserved.
