Instruction Manual
Induction Cooktop
KY-W648CLJPQ
Model:
For residential use only.
Thank you for purchasing this Panasonic product.
Before operating this product, please read the instructions
carefully and keep this manual for future use.
This manual contains images for illustrative purposes
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KY-W648CLJPQ and is the answer not in the manual?

Questions and answers

Summary of Contents for Panasonic KY-W648CLJPQ

  • Page 1 Instruction Manual Induction Cooktop KY-W648CLJPQ Model: For residential use only. Thank you for purchasing this Panasonic product. Before operating this product, please read the instructions carefully and keep this manual for future use. This manual contains images for illustrative purposes...
  • Page 2: Table Of Contents

    Induction Cooktop – Model: KY-W648CLJPQ User Manual INDEX INSTALLATION PRECAUTIONS ............3 OPERATION AND MAINTENANCE ..........4 PRODUCT OVERVIEW ..............6 ABOUT INDUCTION COOKING............7 BEFORE USING YOUR INDUCTION COOKTOP ......7 USING TOUCH CONTROLS ............7 USING THE CORRECT POTS AND PANS ........8 USING THE INDUCTION COOKTOP ..........
  • Page 3: Installation Precautions

    Induction Cooktop – Model: KY-W648CLJPQ User Manual Warning Your safety is important to us. Please read this information before using your cooktop. INSTALLATION PRECAUTIONS • Please read these instructions carefully before installing or using the appliance. Electrical Shock Hazard • Make sure the appliance is not connected to mains power before performing any operation or maintenance.
  • Page 4: Operation And Maintenance

    Induction Cooktop – Model: KY-W648CLJPQ User Manual OPERATION AND MAINTENANCE Electric Shock Hazard • WARNING Do not cook on a broken or cracked cooktop. If the surface of the cooktop breaks or cracks, immediately disconnect the appliance from the mains (circuit breaker) and contact a qualified technician.
  • Page 5 Induction Cooktop – Model: KY-W648CLJPQ User Manual Important Safety Instructions • After use, always turn off the cooking zones and the cooktop as described in this manual (use the touch controls). • WARNING: Cooking fat or oil without supervision of the cooktop can be dangerous and result in smoke or fire.
  • Page 6: Product Overview

    Induction Cooktop – Model: KY-W648CLJPQ User Manual Congratulations on the purchase of your new induction cooktop. We recommend reading this Instruction Manual in full to perfectly understand of how to properly install and operate your cooktop. For installation, please read the installation section. Read all safety instructions before use, and then keep this Instruction Manual/Installation handy for future reference.
  • Page 7: About Induction Cooking

    Induction Cooktop – Model: KY-W648CLJPQ User Manual ABOUT INDUCTION COOKING Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by generating electromagnetic vibrations directly in the container, rather than indirectly heating through the surface of the glass. The glass gets hot only because the container heats up.
  • Page 8: Using The Correct Pots And Pans

    Induction Cooktop – Model: KY-W648CLJPQ User Manual USING THE CORRECT POTS AND PANS • Use only pans with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the bottom of the pan. •...
  • Page 9: Using The Induction Cooktop

    Induction Cooktop – Model: KY-W648CLJPQ User Manual USING THE INDUCTION COOKTOP To start cooking 1. Tap the OFF/ON controller. Once turned on, the cooktop will beep once and all displays will display the "–" or "––" sign, which will indicate that the induction cooktop has gone into preparation mode.
  • Page 10 Induction Cooktop – Model: KY-W648CLJPQ User Manual When you have finished cooking 1a. Turn off the cooking zone by lowering the heating level to "0" or tap the controls " " and " " simultaneously. Make sure the display is displaying "0".
  • Page 11: Locking The Controls

    Induction Cooktop – Model: KY-W648CLJPQ User Manual When you tap the TURBO control, the cooking zone will display the "P" indicator and the power will reach its maximum level. Disable the TURBO function 1a. Tap the "TURBO" controller while the zone power level display is flashing, or the "...
  • Page 12: Protection Against Overheating

    Induction Cooktop – Model: KY-W648CLJPQ User Manual To unlock the controls 1. Tap and hold your finger on the lock controller " " for approximately 5 seconds. 2. The cooktop will be ready to be used. When lock mode is enabled, all controls except the Power control are disabled and locked.
  • Page 13: Using The Timer

    Induction Cooktop – Model: KY-W648CLJPQ User Manual People with pacemakers should consult their doctor before using this device. USING THE TIMER The Timer can be used in two ways: • It can be used as a Kitchen Timer. In this case, the Timer will not turn off the cooking zone at the end of the set time.
  • Page 14 Induction Cooktop – Model: KY-W648CLJPQ User Manual 4. Tap " " and " " simultaneously and the Timer will be canceled. " 00 " will be displayed on the display. 5. When a time is set, a countdown starts immediately.
  • Page 15 Induction Cooktop – Model: KY-W648CLJPQ User Manual 4. When a time is set, a countdown starts immediately. The display will display the remaining time by blinking for 5 seconds. Note: A white dot next to the heating level display will light up indicating which zone has been selected.
  • Page 16: Cooking Guidelines

    Induction Cooktop – Model: KY-W648CLJPQ User Manual COOKING GUIDELINES Be careful when frying and quickly heating oil or fat, especially if you are using the TURBO function. When oil or fat is subjected to too high a temperature, it can spontaneously combust, posing a serious fire risk.
  • Page 17: Heating Settings

    Induction Cooktop – Model: KY-W648CLJPQ User Manual For sautéing 1. Use a flat-based wok or a wide skillet of inductive material • (Use the magnet test if unsure, refer to page 8 on how to test) 2. Have all the ingredients and utensils at hand. Sauté quickly. For large amounts, it is advisable that the sauté...
  • Page 18: Care And Cleaning

    Induction Cooktop – Model: KY-W648CLJPQ User Manual CARE AND CLEANING What? How? Important! • Everyday dirt on Turn off the cooktop. When the power to the cooktop the glass, such as To make cleaning the is off, there will be no...
  • Page 19: Troubleshooting

    Induction Cooktop – Model: KY-W648CLJPQ User Manual TIPS AND SUGGESTIONS Problem Possible causes What to do? The induction No electricity supplied to the Make sure the induction unit. cooktop does not cooktop is connected into the power supply and is active.
  • Page 20: Error Codes

    Induction Cooktop – Model: KY-W648CLJPQ User Manual Problem Possible causes What to do Pots and pans do The induction cooktop does suitable not heat up and do not detect the pot or pan as it induction cooking. See the not appear on the is not suitable for induction.
  • Page 21: Technical Specifications

    Induction Cooktop – Model: KY-W648CLJPQ User Manual TECHNICAL SPECIFICATIONS Cooktop KY-W648CLJPQ Cooking zones 4 Zones Supply voltage 220-240V ~ 50/60 Hz Power 7,000 watts External dimensions product 520 x 590 x 60 Length × Width × Height (mm) Opening dimensions for installation 490 x 560 Length ×...
  • Page 22 Induction Cooktop – Model: KY-W648CLJPQ User Manual Under all circumstances, make sure that the induction cooktop is well ventilated, and that the air inlet and outlet are not blocked. Verify that the location you have chosen has the necessary conditions for the correct installation of the product. As shown in the...
  • Page 23: List Of Accessories

    Induction Cooktop – Model: KY-W648CLJPQ User Manual • The circuit breaker must be of an approved model and provide a contact separation with clearance of 3 mm from all the poles (or in all active conductors [phases] if this is the regulation for connections of the local electrical system).
  • Page 24: Other Precautions

    Induction Cooktop – Model: KY-W648CLJPQ User Manual OTHER PRECAUTIONS 1. The induction cooktop must be installed by a person or a qualified electrical professional. Please NEVER perform the installation yourself. 2. The cooktop should not be installed directly above a dishwasher, refrigerator, freezer, washing machine or clothes dryer, as moisture can damage the electronic components of the cooktop.
  • Page 25: Environmental Responsibility

    • The cable should be checked regularly and replaced only by authorised agents. ENVIRONMENTAL RESPONSIBILITY PANASONIC recommends not to dispose of electronic products and/or their accessories in household waste, on the street, in vacant lots, landfills, streams. For any questions and more information regarding disposal, life cycle and returns, please...
  • Page 26 Panasonic New Zealand Ltd 18 Sir Woolf Fisher Drive East Tamaki Auckland 2013 V.1-230627 NEW ZEALAND PN:16166000A19687...
