Crestron FT-PWR-D & FT-PWR-D-LG
FlipTop Power Centers, Dual AC Outlets
Operations & Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT-PWR-D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Crestron FT-PWR-D

Summary of Contents for Crestron FT-PWR-D

  • Page 1 Crestron FT-PWR-D & FT-PWR-D-LG FlipTop Power Centers, Dual AC Outlets Operations & Installation Guide...
  • Page 2 This product conforms to UL STD 962A; certified to CSA STD C22.2 No. 21. As of the date of manufacture, the FT-PWR-D and FT-PWR-D-LG have been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling.

  • Page 3: Table Of Contents

    Crestron FT-PWR-D & FT-PWR-D-LG FlipTop Power Centers Contents FlipTop Power Centers, Dual AC Outlets: FT-PWR-D & FT-PWR-D-LG Introduction ..........................1 Features and Functions ....................1 Applications......................... 2 Specifications ......................3 Physical Description....................4 Setup ............................10 Installation ......................... 10 Hardware Hookup ..................... 16 Operation ..........................

  • Page 5: Fliptop Power Centers, Dual Ac Outlets: Ft-Pwr-D & Ft-Pwr-D-Lg

    AV sources, and a host of other devices. The FT-PWR-D-LG’s larger size helps accommodate larger cables, connectors and mounting surface cutouts. For simplicity within this guide, FT-PWR-D/-LG is used, except where noted. Features and Functions • Stylish flush-mount FlipTop housing •...

  • Page 6: Applications

    For complete connectivity, the FT-PWR-D/-LG includes two AC power receptacles within the FlipTop compartment. Applications The following diagram shows an FT-PWR-D/-LG in a lecture hall application. FT-PWR-D/-LG in a Lecture Hall Application 2 • FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG...

  • Page 7: Specifications

    Crestron FT-PWR-D & FT-PWR-D-LG FlipTop Power Centers Specifications Specifications for the FT-PWR-D/-LG are listed in the following table. FT-PWR-D/-LG Specifications SPECIFICATION DETAILS Environmental Temperature 41º to 104º F (5º to 40º C) Humidity 10% to 90% RH (non-condensing) Black painted metal with black anodized or Enclosure brushed aluminum cover;...

  • Page 8: Physical Description

    Physical Description This section provides information on the connections, controls, and indicators available on your FT-PWR-D/-LG. FT-PWR-D Physical View FT-PWR-D-LG Physical View NOTE: Cables not included. 4 • FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG Operations & Installation Guide – DOC. 6640C...
  • Page 9 (129 mm) 5.71 in (145 mm) 6.75 in (171 mm) FT-PWR-D Overall Dimensions (Front View) FT-PWR-D (Bottom View) 5.16 in (131 mm) 6.25 in (159 mm) FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG • 5 Operations & Installation Guide – DOC. 6640C...
  • Page 10 FT-PWR-D Overall Dimensions (Side View) 2.31 in (59 mm) 4.31 in (110 mm) 5.39 in (137 mm) 4.63 in (118 mm) 5.21 in (132 mm) 6 • FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG Operations & Installation Guide – DOC. 6640C...
  • Page 11 (152 mm) 6.55 in (166 mm) 7.67 in (195 mm) FT-PWR-D-LG Overall Dimensions (Front View) FT-PWR-D-LG (Bottom View) 6.08 in (154 mm) 7.17 in (182 mm) FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG • 7 Operations & Installation Guide – DOC. 6640C...
  • Page 12 FT-PWR-D-LG Overall Dimensions (Side View) 2.64 in (67 mm) 4.75 in (121 mm) 5.76 (146 5.51 in (140 mm) 6.04 in (153 mm) FT-PWR-D/-LG (Front Face View) 8 • FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG Operations & Installation Guide – DOC. 6640C...
  • Page 13 10 Amps (total) @ 120 Volts AC, 50/60 Hz 125V~50/60Hz 10A (1) 9 foot grounded AC line cord; passes through to front panel AC power outlets FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG • 9 Operations & Installation Guide – DOC. 6640C...

  • Page 14: Setup

    Screws, #04-40 x 1/4" (6.4 mm) 2007158 The cable support plate should be installed before mounting the FT-PWR-D/-LG to a surface. The cables are threaded through the cable support plate. 1. Place bushings on the cables you wish to install in the power center (eight bushings supplied).
  • Page 15 Crestron FT-PWR-D & FT-PWR-D-LG FlipTop Power Centers Cable Support Plate Installation When selecting cables for installation in the FT-PWR-D/-LG, cable connector length and strain relief diameter are important considerations. If the connector is too long, it can interfere with cover operation.
  • Page 16 FlipTop box. Surface Mounting The FT-PWR-D/-LG is designed to mount in a horizontal surface, such as a desk top, lectern, or podium. The following diagram illustrates the required opening size to accommodate the FT-PWR-D/-LG. Use the template supplied with the FT-PWR-D or FT-PWR-D-LG (4010018 or 4007478, respectively) to make the cutout.
  • Page 17 Crestron FT-PWR-D & FT-PWR-D-LG FlipTop Power Centers Example of the Cutout Dimensions for the FT-PWR-D-LG (Not Actual Cutout Template) 7 1/4 in (184 mm) 6 1/8 in (156 mm) MAXIMUM RADIUS 1/8 IN (4 MM) NOTE: Be sure to feed the attached power cord and all required cables through the mounting hole before inserting the FT-PWR-D/-LG.
  • Page 18 (two screws per bracket). Refer to the illustration on the following page. 4. Slide the mounting brackets over the #06-32 screws and tighten the #06-32 screws. 14 • FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG Operations & Installation Guide – DOC. 6640C...
  • Page 19 DO NOT OVER-TIGHTEN. CAUTION: Do not over-tighten the #10-32 screws as this may damage the surface and/or the unit. FT-PWR-D (Mounting Brackets Installed) FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG • 15 Operations & Installation Guide – DOC. 6640C...

  • Page 20: Hardware Hookup

    The ratings on the connecting unit's supply input should be considered to prevent overloading the wiring. 16 • FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG Operations & Installation Guide – DOC. 6640C...

  • Page 21: Operation

    AV, communication, data or control cables to be instantly available for connection to your devices. The recessed compartment also contains two three-pronged, grounded AC sockets. FlipTop Power Centers: FT-PWR-D & FT-PWR-D-LG • 17 Operations & Installation Guide – DOC. 6640C...

  • Page 22: Problem Solving

    Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. You can also log onto the online help section of the Crestron website (www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features.

  • Page 23: Return And Warranty Policies

    Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures.
  • Page 24 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 6640C 15 Volvo Drive Rockleigh, NJ 07647 (2019709) Tel: 888.CRESTRON 06.10 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
