- Page 1 Plasma Cutting Table Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #104820 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Klutch product! ® For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Tools Required For Assembly ......................6 Assembly Instructions .......................... 6 Before Each Use ............................ 7 Operating Instructions .......................... -
Page 4: Intended Use
Intended Use The Klutch Plasma Cutting Table allows you to lay out and cut heavy steel at a comfortable working height. Replaceable slats can be notched during through cuts by the plasma cutter while still fully supporting your workpiece. Sparks and slag are free to drop away from the workpiece through the slats onto an optional shop-made slag tray. - Page 5 WORK AREA SAFETY Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. • Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. Keep children and bystanders away from the work area while operating the tool.
-
Page 6: Specific Operation Warnings
Specific Operation Warnings ⚠WARNING Always wear the proper protective equipment including ANSI Z87.1 compliant eye protection, a • welding helmet, and welding gloves. Do not exceed the rated load capacity of 250 lb. • Never sit or stand on the plasma cutting table. •... -
Page 7: Before Each Use
Before Each Use ⚠WARNING Do not use the Plasma Cutting Table on an unstable surface. Modify the height of the Adjustable Feet if necessary to ensure the Table does not rock or shift during use! 1. Inspect the general condition of the Plasma Cutting Table. Check for loose hardware, misalignment, shifting or rocking of the table, or cracked and broken parts. -
Page 8: After Each Use
• Inspect before each use. Replace damaged Cutting Slats as necessary. • Keep the table clean for optimal performance. Wipe away dust and debris from the tabletop and legs. Use only for the intended purpose. Do not sit or stand on the table. •... -
Page 9: Parts Diagram
Parts Diagram Parts List Part Number Part Description Quantity Tabletop Cutting Slat Table Leg Leg Brace Adjustable Foot M10 Nut M8 x 35mm Bolt M8 Locking Nut Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. •... -
Page 10: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Klutch® product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 11 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 11 of 11...
