Summary of Contents for Klutch 73167
- Page 1 Electric Rod and Rebar Cutter Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #73167 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Klutch ® product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Grounding .............................. 7 Extension Cords ............................ 8 Main Parts of Rebar Cutter ........................9 Before Each Use ............................ 9 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use The Klutch Electric Rod and Rebar Cutter has a powerful 110V electric motor and provides a 5- second cycle to cut steel rods up to one inch thick. Packaging Contents Rebar Cutter Wrench Set Oil Syringe • •... - Page 5 ⚠WARNING • This product may contain chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm. • Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm.
-
Page 6: Specific Operation Warnings
the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury. Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing •... -
Page 7: Grounding
• Do not operate machine in wet or damp areas or expose it to rain. • Turn power OFF and unplug before servicing. Do not use an extension cord with this product. • • Not for use by or around children. Grounding ⚠WARNING This machine must be grounded while in use to protect the operator from electrical shock. -
Page 8: Extension Cords
Extension Cords ⚠WARNING • USE A PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage, resulting in loss of power and cause overheating. -
Page 9: Main Parts Of Rebar Cutter
Main Parts of Rebar Cutter 1. Housing 2. Cutter Blocks 3. Adjustable Stopper 4. Cylinder 5. Pump Case 6. Oil-Plug 7. Motor 8. Switch 9. Carbon-Brush Caps Before Each Use ⚠WARNING Check to see if the oil level is maintained properly. •... -
Page 10: Operating Instructions
• Wipe or brush off dust and metal pieces. Be sure to check the lower portion of the piston which will easily accumulate dust. This machine is operated through oil pressure. Check the oil level daily. If it is not kept at the proper •... -
Page 11: Maintenance
Maintenance ⚠WARNING Wear gloves to protect hands from metal splinters. Do not use an air-gun. Blasting with air can cause • metal filings and or dust to get into eyes and respiratory system. Hydraulic oil is flammable. Keep away from sparks and naked flame. Do not smoke. •... -
Page 12: Troubleshooting
Troubleshooting Use the following table to troubleshoot problems before contacting service personnel or your local dealer. If the problem continues after troubleshooting, call your local dealer for assistance. Problem Solution Check the power supply. • Plug in the power cord. •... -
Page 13: Parts Diagram
Parts Diagram Page 13 of 20... -
Page 14: Parts List
Parts List Reference Part Number Part Description Quantity QBL-M8x10 Air bag bolt(M8x10) QWS-SM8 Spring Washer(M8) QNT-M8 Air bag nut(M8) RC25-001 Air bag RC25-002 Housing RC25-003 Cutter block QBL-LM8x25 Block bolt QBL-M16X50 Stopper bolt(M16X50) QNT-M16 Adjustable nut(M16) QBL-LM10x30 Socket Head Cap Bolt QWS-SM10 Spring Washer QOS-40x50x6... - Page 15 Reference Part Number Part Description Quantity QSR-R30 Snap ring (R30) QOS-CR17x32x6 Oil seal (17*32*6) RC25-021 Pump case RC25-022 Seal washer RC25-023 Oil plug QWS-SM8 Spring Washer(M8) QBL-LM8x60 Cap bolt (M8*60) QBR-6003 Ball bearing (6003ZZ) RC25-024 Armature assembly RC25-025 Stator coil RC25-026 Tapping screw M5x80 QWS-SM5...
-
Page 16: Replacement Parts
Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. • • Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. •... -
Page 17: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Klutch product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 18 *MEMO* Page 18 of 20...
- Page 19 *MEMO* Page 19 of 20...
- Page 20 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in Korea Page 20 of 20...
