Eldes ESIM320 User Manual

REMOTE GATE CONTROLLER
USER GUIDE
V1.1
Please read the user guide first, before starting to use
ELDES Configuration Tool (note: this software runs only on Windows OS)!
PRODUCT NAME: REMOTE GATE CONTROLLER
BRAND: ELDES
MODEL: ESIM320-4G G1 / ESIM320-4G Q
EXAMPLES OF USING THE SYSTEM
ESIM320-4G G1 / ESIM320-4G Q
1 x 1 x 2 x
EN CONTENTS OF PACK
EN
INSTALLATION
METALL
1 2
ANT ANT
PIN
MO DE M
F1
AC/DC RELAY1 RELAY2COM
4
****
+1...5
EN NOT INCLUDED
>20 cm
(> 7,874 inch.)
FROM THE POWER LINES
MIN -20
C (-4 F)
O O
MÁX +55
C (131 F)
O O
3
ANT ANT
USB
MO DE M
SIM CARD
SIM STAT
NETW
DEF
F1
AC/DC RELAY1 RELAY2COM
Z3 Z2 Z1
5
Number NR4:+441700XXXX110 is set.
1
EN
Disable PIN code request.
EN
2
Insert the SIM card into the device's SIM card slot holder.
3
Power up the system and wait until LED indicator SIM STAT lights up, indicating SIM card
status. Once the indicator SIM STAT lights OFF, the illuminated indicator NETW lights up,
indicating that the system has successfully connected to the required network.
4
Set the phone number for Admin 1 (NR 1); set date and time; change the default SMS password;
you may also change the system's language. Once the system is configured, it is ready to use.
5
Example of the system's SMS response to the requested command.
For more system configuration, see SMS CONFIGURATION.
Before installing the system, please wire it up using the wiring methods example and connect
both antennas.
EXAMPLE OF WIRING DIAGRAMS
1
2
12...24
AC/DC
Main Unit & Connectors
Antenna SMA type connector (2 antennas in models ESIM320-4G G1 / ESIM320-4G Q)
Mini USB port
SIM card slot / holder
ESIM320-4G G1 Modem frequency Global; ESIM320-4G Q Modem frequency EU
Red LED, indicating SIM card status
Green LED, indicating signal strength
Pins for restoring default settings
0.5A fuse
AC/DC
Power supply terminals
RELAY
Output C1-C2 terminal
1-2
COM
Common terminal
USB
Z1/Z3
SIM CARD Low-level (negative input terminal)
Z2
High-level (postive input terminal)
SIM STAT
NETW
DEF
SIM Start indication
Z3 Z2 Z1
OFF
Steady on
NETW indication
OFF
Flashing every 1 sec.
Flashing several times
per sec.
Steady on
FO
+24V
EN
EN
LED Indicator Functionality
SIM card status
No mains power/ successfully connected to GSM/4G network
SIM card is attempting to connect to the GSM/3G/4G network / SIM card is not
present / PIN code enabled
Signal strength
No GSM/3G/ 4G signal
Poor
Medium
Excellent
Gate automation elements
Fault output; open collector type
Power supply output for powering aux. equipment
