- Page 1 CR-IRL IR Remote Control Code Learner OPERATION MANUAL...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. CYP (UK) Ltd assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction ...........6 2. Applications ...........6 3. Package Contents ........6 4. System Requirements ......6 5. Features ..........6 6. Operation Controls and Functions ..7 6.1 Hardware Description ......7 6.2 Software Application & Installation ..8 7. Connection Diagram ......18 8. -
Page 6: Introduction
1. INTRODUCTION The Infrared Learner is a versatile tool for all your control system design needs. This compact yet functional unit can convert your analogue IR commands into digital data and store it for many uses. With the simple software tool the user can store the commands from multiple IR remote controls in a single convenient location such as a laptop for later recall as required. -
Page 7: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Hardware Description IR Blaster Transmits the digital IR signal sent from 60° PC/Laptop to confirm that learning of the 60° received IR signal has been successful. Ensure that the IR Transmitter is in direct line-of-sight of the equipment to be controlled. -
Page 8: Software Application & Installation
Please download the ZIP file from the 'Downloads' tab on the IR Learner product page on the CYP website and save it in a directory where you can easily find it again. Once saved, locate the file on your computer and de- compress by right clicking it and choosing the 'expand' option. - Page 9 Click on USB Virtual COM with mouse’s right button and select Update Driver Software…...
- Page 10 Click on Browse for driver software and direct the downloaded software location. Windows Security will show warning message, click on Install anyway to continue the installation process.
- Page 11 Close the dialogue to finish the installation.
- Page 12 Now the IR Learner will be renamed as IRL Virtual Com Port in the Device Manager.
- Page 13 6.2.2 Using the IR Learner Application Now your PC/Laptop has install successful the IR Learner and you may start to use with the IR learner with IR Learning Tool by opening the IRL Tool from the download file. Double click on IRL Tool...
- Page 14 Select the Com Port according to IRL Virtual Com Port from the Device Manager and click on Connect. To start IR signal learning, click on IR Learning and press the remote control with the direct line-of-sight towards the IR Learner’s Receiver lens until the IR code has been learned and show Success from the IRL Tool.
- Page 15 Then click on IR Emitter with IR Learner’s Blaster in direct line-of-sight towards the remote device to confirm if the learning is correct (or activate).
- Page 16 This IR code/data then may be stored in another control system/ application for future usage or may be utilised in many other forms. (Copy the IR code from IR Data box).
- Page 17 Click on IRL Version to see the IRL Tool’s version update status. Type $HELP to list all the IRL commands and use the command through RS-232 to control the IR Learning Tool. To clear the message in message box simply click on Clear MSG.
-
Page 18: Connection Diagram
7. CONNECTION DIAGRAM Connect to a spare USB port 60° 60°... -
Page 19: Specifications
8. SPECIFICATIONS Input Port 1 x IR Output port 1 x IR 1 x USB IR Frequency 20~60kHz IR Input Signal Up to 1m Distance IR Blaster Out Distance Up to 10m ESD Protection Human Body model: ± 8kV (air-gap discharge) ±... -
Page 20: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM Infrared Personal Computer Universal Serial Bus... - Page 24 CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue, Shepperton, Middlesex, TW17 8BA Tel: +44 (0) 20 3137 9180 | Fax: +44 (0) 20 3137 6279 Email: sales@cypeurope.com www.cypeurope.com v1.00...
