NavePoint 400446407 Manual

2-Post Open Frame Rack
Thank you for purchasing a NavePoint product. NavePoint intends this manual to guide you through
a smooth installation of the product. NavePoint assumes that you are qualified in the servicing of
computer equipment and trained in recognizing any hazards that may occur in the installation of this
product. If you have any questions regarding the installation or use of your product, please call us at
888.505.1363.
Examine the package for any damaged or loose parts. If
anything is damaged or missing, contact NavePoint for
assistance. Do not attempt to install or use product if it
has been damaged.
The information contained in this document is subject to change
without notice.
NavePoint makes no warranty of any kind with regard to this
material, including, but not limited to the implied warranties of
merchantability and fitness for a particular purpose.
NavePoint shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
NavePoint assumes no responsibility for the use, application, or
reliability of the software or hardware that you install into the
product. Always install the heaviest equipment in the bottom.
It is highly recommended that installation of this product be
performed by a qualified and experienced installer. Improper
installation of this product could result in damage to the
product, other equipment, or personal injury. NavePoint cannot
be held responsible for damage to equipment or personal
injury resulting from improper use, installation or the misuse of
information presented in this document.
Part
A
B
C
Equipment Mounting
Hardware
28 12-24 (5/8") Sliver Screws
28 12-24 (5/8") Black Screws
Instructions for Products:
00301071 – 13U
00301102 – 25U
00301103 – 45U
Quantity
Base Bracket x2
Vertical Post x2
Top Bracket x2
www.NavePoint.com
customerservice@navepoint.com
© 2017 NavePoint, LLC
Rev. 201708
Important information-
Keep this information for further reference.
WARNING
Limitations of Liability: In no event will NavePoint, LLC. (or its officers, direc-
tors, employees or agents) be liable for any damages, whether direct or
indirect, special, punitive, incidental or consequential damages (including,
but not limited to, lost profits or revenue, loss of use, lost business opportu-
nities or loss of goodwill) or for the costs of procuring substitute products,
arising out of or in connection with the use of the product, whether such
liability arises from any claim based upon contract, warranty, tort (including
negligence), product liability or otherwise, whether or not seller has been
advised of the possibility of such loss or damage. In no event will seller's
total cumulative liability, from all causes of action and all theories of liabil-
ity, exceed the total amounts actually paid to seller by customer under the
order that gives rise to any liability hereunder.
Assembly Hardware
D 3/8-16 (1") Bolt x12
E 3/8-16 Hex Nut x12
F 3/8 Washer x24
Cable Hardware
G Cable Management Hooks
(13U-x4, 25U-x8, 45U-x14)
H Hook Mounting Screws
(13U-x4, 25U-x8, 45U-x14)
