Summary of Contents for WATTBRICKS H2500Pro

  • Page 1 说明书制作要求 此页不印刷 V1.1 2024.05.08 更新版本,容量改为 2048Wh 杜建华 V1.2 2024.06.22 P15 页,更新邮箱为 support@wattbricks.com 李红杰 印刷内容:H2500Pro III 说明书 (WATTBRICKS) 美规 产品规格: 产品版本:H2500ProIIIM V1.0.01 物料编码:3.06.03.0398 —— 成品尺寸:142x210mm 展开尺寸:284x210mm 钉装:骑马钉 20P 材质:128g/157g 双铜纸...
  • Page 2 User Manual carefully before operation and keep it for future reference. Charging instructions Before using your new Power Station H2500Pro, plug it into a suitable power outlet until it is fully charged. Then you can start your exciting journey with it.
  • Page 3 WATTBRICKS is an American Company with US Based Customer Service. Please reach out to us at support@wattbricks.com so we can answer any questions or resolve any issues. Thank you for purchasing our products!
  • Page 4: Safety Instructions

    WARNING Please read the following instructions for safety before use. Improper use may result in fire, property damage or personal injury or death. DO NOT use the product with incompatible components or alter the product in any way. WARNING WARNING Improper use may result in fire, property Do not expose the product to any liquid or submerge in water.
  • Page 5: Product Introduction

    PRODUCT INTRODUCTION H2500Pro with high capacity and high safety battery pack. It is very convenient for emergency off-grid demand such as sudden power failure, snowstorm or hurricane, outdoor tourism, outdoor operation, RV power supply, etc. There is perfect performance with great power output up to 2500W, fast charging, high capacity and long cycle life.
  • Page 6: Table Of Contents

    CONTENTS SAFETY INSTRUCTIONS ······························· 01 PRODUCT INTRODUCTION ···························· 02 LOAD CAPACITY ····································· 02 PACKING LIST ······································· 02 PRODUCT FUNCTION DESCRIPTION ····················· 04 BUTTON INDICATOR ································· 05 LCD DISPLAY ······································· 06 LIST OF FAULT CODES ································ 07 FULL PARALLEL INTEGRATION ························· 07 CHARGING FUNCTION DESCRIPTION ····················...
  • Page 7: Product Function Description

    PRODUCT FUNCTION DESCRIPTION ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑮ ⑨ ⑭ ⑩⑪⑫ ⑬ ⑭ ① DC Output ⑨ Air Intake Vent with Cooling Fan ② Cigarette Lighter Socket Output ⑩ OLP Reset ③ USB-A Output ⑪ AC Input ④...
  • Page 8: Button Indicator

    BUTTON INDICATOR ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ Wireless Charge ⑮ Press "Power ON/OFF" Button to turn on the Wireless Charge. Press "Power ON/OFF" Button to shut down the output(s) when not in use. Button ⑯ Power ON/OFF Press button ⑮ to turn on or turn off the power. Button ⑰...
  • Page 9: Lcd Display

    LCD DISPLAY ① ② ③ ⑱ ⑰ ⑯ ⑮ ④ ⑭ ⑤ ⑬ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ① AC Input: When the AC charging cable is inserted, this label is displayed on the LCD. ② DC Input: When the DC DC/SOLAR PV charging cable is inserted, this label is displayed on the LCD. ③...
  • Page 10: List Of Fault Codes

    FULL PARALLEL INTEGRATION Double your power right of the box. No complicated or costly junction boxes - simple plug and play technology allows you to link two, H2500Pro's together easily. Parallel cable included! Step 1: turn off two AC outputs and then insert the paralleling line.
  • Page 11: Charging Function Description

    CHARGING FUNCTION DESCRIPTION Re-charging time From AC socket charging Around 1.5 hours From solar charging 800W 3.0-7.4 hours Depending on solar conditions From car port 12V 12.6-19.5 hours AC charging Use the AC charging cable we provided to charge the device. It takes around 1.5 hours to full capacity.
  • Page 12 12V car charger Use the car charger we provided to charge. It takes 12.6 to 19.5 hours to fully charge. When the LCD shows that the battery power is 100%, it means that the battery is fully charged. Car DC plug Car charger Caution: Do not charge the product with solar PV input and car port at the same time! Solar panel charging...
  • Page 13: Operating Instructions

    OPERATING INSTRUCTIONS Re-charging Use the original AC line to charge, the full charge time is about around 1.5 hours. When charging, the LCD screen will be lit, the LCD display will provide real-time display data of battery charging, and the device will display 100% when it is fully charged. It is recommended to fully charge the device every 3 months to maintain the life of the device.
  • Page 14 Equipment cleaning Please make sure that the device is disconnected from all input power and output devices. Wipe with a clean, dry, non-soft cotton cloth. Remove all any foreign objects, dirt or other obstructions on the vents on both sides. While cleaning foreign objects in the side vents, do not allow debris, dirt or other blockage to enters the equipment.
  • Page 15: Transport Instructions For Dangerous Goods

    PRODUCT MAINTENANCE Maintenance Check as needed. If the H2500Pro power station cannot working regularly, please charge and discharge it every 3 months under normal temperature to keep the service life. Regularly check all ports and wall chargers for any debris, dirt, damage, and corrosion.
  • Page 16: Fcc Note

    Disposal/recycling Do not put the device and its accessories in the trash can. Items must be properly handled in accordance with local laws and regulations. For additional information, please see www.epa.gov. Affirm Copyrighted equipment. We all rights reserved. All trademarks cited here are the property of their respective owners.
  • Page 17: Technical Specifications

    TECHNICAL SPECIFICATIONS GENERAL PARAMETERS Battery Type Lithium Iron Phosphate Rated Capacity 51.2V, 40Ah/2048Wh Net Weight ≈ 26kg Product Size 430mm*300mm*287mm Operating Temp 14 to 104 ℉ (-10 to 40℃ ) Charging Temp 32 to 104 ℉ (0 to 40℃ ) Storage Temp -4 to 113°...
  • Page 18: Warranty

    2) any product purchased through an online auction house. The warranty of H2500Pro does not apply to the battery cell unless the battery cell is fully charged by you within seven days after your purchase the product and at least every 6 months thereafter.
