- Page 1 ELECTRIC CONVECTION OVENS OPERATOR MANUAL Model Number: GS1740 / GS1741 / GS1742 / GS1743 Please read and keep these instructions.
-
Page 2: Maintenance And Repairs
MAINTENANCE AND REPAIRS Contact Nemco/Global Solutions for service or required maintenance. Please record the model number, serial number, voltage and purchase date in the area below and have it ready when you call to ensure a faster service. -
Page 3: Electrical Specifications
Thermostat range for GS1740 & GS1741 is 150°F to 500°F, while for GS1742 & GS1743 it is 150°F to 550°F. Timer range is 0 to 120 minutes. Oven features a heat indicator light and power light. Oven holds either 3 or 4 standard size baking sheets. - Page 4 THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT.
-
Page 5: General Information
GENERAL INFORMATION This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. Before using your new equipment, read and understand all the instructions and labels associated with the unit prior to putting it into operation. -
Page 6: Before Using Your Oven
Before Using Your oven Before cooking anything in your oven for the first time, please follow these simple instructions: Using a small amount of detergent, wash the handle and racks with soapy water. (NOTE: Do not use a spray or abrasive polishing agent). Gently wipe down the interior walls with a damp cloth. While washing the unit, do not touch the electric heating element. -
Page 7: Using Your Oven
Using Your Oven To start your oven, you need to turn on the temperature dial to set your desired cooking temperature and turn on the timer dial to set the cooking time. CAUTION: During the baking process, make sure that no metal accessory comes in contact with the electric heating elements. -
Page 8: On/Off Switch
Switch power on/off by this switch (only applies to GS1743). MAINTENANCE Contact Nemco/Global Solutions the factory, for service or required maintenance. • Oven interiors should be wiped down daily and thoroughly cleaned weekly using warm water and mild detergent. DO NOT use caustic cleaners. - Page 9 Circuit Diagram for GS1740, GS1741 & GS1742...
