HRQ02/03WNA manual
2002.5.16
(HRQ02WNA)
User Manual-
(Features may vary per model)
Guide de l'Utilisateur-
(Les caractéristiques peuvent
varier en fonction du modéle)
Manual del Usuario-
(Las funciones pueden
variar según el modelo)
12:25AM
Page 2
Refrigerator
Réfrigérateur
Tout le Compact
Refrigerador
Todo el Compacto
Model #
Modèle
Para Modelo de
Compact All
HRQ02WNA
HRQ03WNA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Haier HRQ02WNA - 12-01
Summary of Contents for Haier HRQ02WNA - 12-01
-
Page 1: User Manual
Compact All Refrigerator Réfrigérateur Tout le Compact Refrigerador Todo el Compacto (HRQ02WNA) User Manual- Model # (Features may vary per model) HRQ02WNA Guide de l’Utilisateur- Modèle (Les caractéristiques peuvent varier en fonction du modéle) HRQ03WNA Manual del Usuario- Para Modelo de (Las funciones pueden variar según el modelo) -
Page 2: Safety Precautions
When using this appliance, always exercise basic safety precautions, including the following: 1) Use this appliance only for its intended purpose as described in this use and care guide. 2) This refrigerator must be properly installed in accordance with the installation instructions before it is used. - Page 3 Serial number Remember to record the model and serial number. They are on a label in Date of purchase back of the refrigerator. Staple your receipt to your manual. You will need it to obtain warranty service.
-
Page 4: Table Of Contents
Refrigerator Features And Use............10 General Features..................10 Refrigerator Interior Shelves ..............10 Using The Lock ..................11 Food Storage Information ..............12 Normal Operating Sounds..............12 Proper Refrigerator Care and Cleaning ........13 Cleaning and Maintenance ..............13 Power Interruptions ................14 Vacation and Moving Care ..............14 Troubleshooting................15 Warranty Information ..............16... -
Page 5: Parts And Features
HRQ02/03WNA manual 2002.5.16 12:25AM Page 6 English Parts And Features (HRQ02WNA) 1. Adjustable Temperature Control 3. Door Shelf (type varies per model) and Light 4. Lock and Key 2. Full Width Refrigerator Shelf (quantity varies per model) -
Page 6: Installing Your Refrigerator
2. Inspect and remove any remains of packing, tape or printed materials before powering on the refrigerator. Leveling Your Refrigerator • Your refrigerator has leveling legs which are located at the bottom of your refrigerator. After properly placing your refrigerator in its final position, you can level your refrigerator. -
Page 7: Electrical Requirements
• Make sure there is a suitable power Outlet (115 volts, 15 amps outlet) with proper grounding to power the refrigerator. • Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet. This is a dangerous practice since it provides no effective grounding for the refrigerator and may result in shock hazard. -
Page 8: Door Alignment
2. Remove the top hinge cover. 3. Loosen the top hinge screws using a phillips head screwdriver. 4. Adjust the door or put a spacer in between and then tighten the screws. 5. Replace the top hinge cover. fig. # 1... -
Page 9: Door Reversal
Insert and tighten the screws.(see fig. # 3) 8. Align the bottom hole on the left side of the door with the pin of the lower hinge and slide into place. - Page 10 Page 11 English 9. Align the pin of the top hinge with top hole on the left side of the door and push into place. Replace the screws in the upper hinge bracket but do not tighten all the way. (see fig. # 2) 10.
-
Page 11: Refrigerator Features And Use
(shelves will vary per model purchased) To remove or replace a full-width slide-out shelf: (see fig. # 4) 1. Gently tilt the shelf up and slide forward until the shelf has been completely removed. 2. To replace the shelf, gently slide the shelf back. -
Page 12: Using The Lock
• To replace burnt-out bulbs, remove the temperature control knob by pulling it out (see fig. # 7a). Carefully pull the plastic light cover to the left and remove. Unscrew the bulb and replace it with a new one (use bulbs of 15 watts or less). -
Page 13: Food Storage Information
Food Storage Information Fresh Food • When storing fresh food, which is not prepackaged, be sure to wrap or store food in airtight and moisture proof material unless otherwise noted. This will ensure proper shelf life and prevent the transfer of odors and tastes. -
Page 14: Proper Refrigerator Care And Cleaning
Use sponge or soft cloth, dampened with the cleaning solution, to wipe down your refrigerator. • Rinse with clean warm water and dry with a soft cloth. • Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,concentrated detergents, solvents or metal scouring pads. -
Page 15: Power Interruptions
DIAL to the OFF position and clean the refrigerator and door gaskets according to "General cleaning" section. Prop doors open, so air can circulate inside.When moving always move the refrigerator vertically. Do not move with the unit lying down. Possible damage to the sealed system could occur. -
Page 16: Troubleshooting
• Check if thermostat control is not in the “OFF” position. • Check if refrigerator is plugged in. • Check if there is power at the ac outlet, by checking the circuit breaker. Food temperature appears too warm • Frequent door openings. -
Page 17: Warranty Information
1. The mechanical and electrical parts, authorized dealer or service center. which serve as a functional, purpose Decorative trims or replaceable of this appliance for a period of 12 light bulbs. months. This includes all parts except Transportation and shipping. - Page 18 IMPORTANTE No regrese este producto a la tienda Si tiene algún problema con este producto, por favor contacte el "Centro de Servicio al Consumidor de Haier" al 1-877-337-3639 (Válido solo en E.U.A). NECESITA UNA PRUEBA DE COMPRA FECHADA PARA EL SERVICIO DE LA GARANTIA...
