Sonic Alert HomeAware HA360SA2.1 Quick Start Manual

HA360SA2.1 – Security Alert Signaler
The HA360SA2.1 Security Alert will alert you to several
different alerts when linked to the HA360 Main unit. The
Main unit receives a wireless signal from the HA360DC and
will flash a strobe, make a loud sound and vibrate a bed
shaker. Once the Main unit receives the signal it will also
send a signal to all HomeAware remote receivers.
The HA360SA2.1 has 5 different door alerts (DOOR, FTDOOR,
BKDOOR, DOOR3, DOOR4), a burglar help alert (HELP) and a
motion alert (MOTION). The HA360SA2.1 can connect to a
NOAA weather radio (STORM), a home security (SECURIT).
Every home security system is different, contact your
provider for setup.
Installing Batteries
The HA360SA2.1 Security Alert comes with two #357 silver
oxide long lasting batteries that need to be installed into the
bottom of the unit. Once installed the red light should light
when the button is pushed. If the light does not show, you
may have the batteries in backwards.
Linking the HA360SA2.1 to the Main Unit
This procedure will link your HA360SA2.1 Security Alert to
your HomeAware™ Main unit. The Main unit will also provide
an alert to all HomeAware™ remote receivers. It is best to do
the LINK procedure in the same room as close as possible to
the HomeAware™ Main unit.
To link the HA360SA2.1 to your HomeAware™ Main unit
follow the steps below.
1. Press SET UP button on the Main unit and the word LINK
will be shown on the display, press Enter. LINK will begin
blinking.
2. Remove the cover on the bottom of the HA360SA2.1 and
press and release the small black button. PICK DEVICE
will display on the screen, press the blue TONE button to
select the alert you want displayed and press ENTER.
Once you have made your selection DONE will flash on
screen.
Switch Positions on the Back of the HA360SA2.1
There are three switch positions on the back of the unit.
1. N.Closed
Normally closed* - Is a contact that flows current in its
normal state. Switching it on will open the contact,
causing it to not allow current flow.
2. N.Open
Normally open* - Is a contact that does not flow current
in its normal state. Switching it on will close the contact,
causing it to allow current flow.
3. Door Chime
Is for when the barrel port is connected to the solenoid
contacts of a door chime ringer. See note below.
NOTE: It is important that the switch not be on the open
or closed positions if the HA360SA2.1 is being connected
to the door chime ringer. That could damage the
HA360SA2.1 if left this way for a long period of time. The
HA360SA2.1 will continually to trigger if the doorbell
button is a model that lights or glows.
Please check the user guide of the device you are
connecting to the HA360SA2.1 for switch position. For
further information on all HomeAware products please
go to www.sonicalert.com
FCC Requirements
This device complies with part 15 of the FCC rules, and with
RSS-210 of Industry Canada. Operation is subject to the
following two conditions; (1) This device might not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC rules. These limits are designed to provide
responsible protect against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions manual, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not interfere in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment on and off, the user is
encouraged to try to correct the interference by one or more
of the following measures:
i. Reorient or relocate the receiving antenna.
ii. Increase the separation between the equipment and
receiver.
iii. Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
iv. Consult the dealer or and experienced radio /TV
technician for help
Modification not expressly approved by the manufacturer
could void the user's authority to operate the equipment
under FCC rules.
CANADIAN CERTIFICATION
This device complies with Industry Canada license exempt
RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device.
