DC401W
DC /DC 400W POWER SUPPLY
Bicker Elektronik GmbH
Ludwig-Auer-Straße 23 | 86609 Donauwörth · Germany

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC401W and is the answer not in the manual?

Questions and answers

Summary of Contents for Bicker DC401W

  • Page 1 English DC401W DC /DC 400W POWER SUPPLY Bicker Elektronik GmbH Ludwig-Auer-Straße 23 | 86609 Donauwörth · Germany...
  • Page 2: Legend Of Used Symbols

    DC401W Legend of used symbols Symbol Description Attention! Important hazard warning. Do not dispose of in the domestic waste. Warning of electrical voltage. Revision Directory Date Change 18.04.2024 Initial version Revision 0-1 08.08.2024 Release version Revision 1-0 Revision 1-0...
  • Page 3: A Brief Specification

    DC401W A Brief specification DC401W 400 Watt DC/DC converter Ultra wide input range 6…36 V DC  ATX output voltage  +12 V / 27 A, +5 V / 7 A, +3.3 V / 7 A, –12 V / 0.3 A und 5 V...
  • Page 4: Table Of Contents

    DC401W Legend of used symbols ..............................2 Revision Directory ..................................2 Brief specification ....................3 Introduction and description ................5 B1 Description of the product and its functions ....................5 B2 Intended use .................................6 Safety instructions ....................7 Technical Data ....................... 8 D1 General Technical Data ............................8 D2 Derating ..................................
  • Page 5: B Introduction And Description

    The manual as well as all documents has to be read and followed strictly before installation. Otherwise warranty and guarantee can be cancelled partly or completely. Any liability on the part of Bicker Elektronik is excluded for possible existing errors as well as non-compliance with the instructions for use and installation.
  • Page 6: B2 Intended Use

    DC401W B2 Intended use During installation, it is recommended to thermally connect the DC401W to the housing of the application to ensure good heat transfer. The ambient temperature specified in the technical details is the air temperature directly at the components and must not be undercut (minimum value) or exceeded (maximum value).
  • Page 7: C Safety Instructions

    4. The assembly of the device and the electrical installation have to be state of the art. 5. The electrical, thermal and mechanical limit values have to be observed. 6. The DC401W wiring specifications - as described in this manual - have to be followed. Revision 1-0...
  • Page 8: D Technical Data

    DC401W D Technical Data D1 General Technical Data INPUT DATA Unless otherwise stated, all specifications apply to +25 °C ambient temperature, 6–36 V DC input voltage and nominal output current (I Input voltage Input voltage range 6–36 V DC Electric strength max.
  • Page 9 DC401W OUTPUT DATA Unless otherwise stated, all specifications apply to +25 °C ambient temperature, 6–36 V DC input voltage and nominal output current (I Output voltage 12 V, 5 V, 3.3 V, –12 V, 5 V Output voltage tolerance 12 V / –7 %, +5 %, 5 V / ±5 %, 3.3 V / ±5 %, –12 V / ±10 %, / ±5 %...
  • Page 10 DC401W CONNECTION DATA OUTPUT (J1, J3, J9) ! Valid for J1, J3, J9 ! Max. voltage / max. current per contact: 300 V / 7 A Connection method (J1) Lockable plug connector Part number (J1) Molex 0460152402 (or equivalent) Connection method (J3)
  • Page 11 DC401W ENVIRONMENTAL CONDITIONS Ambient temperature (operation) –20… +70 °C Ambient temperature (start up without load) –20 °C Ambient temperature –20… +70 °C (storage / transport) Max. permitted humidity Operating: 10…90 % RH, non-condensing Storage: 10…95 % RH, non-condensing Operating altitude ≤5000 m...
  • Page 12 DC401W INTERFERENCE IMMUNITY ACCORDING TO EN 61000 (INDUSTRY) Basic standard CE Fulfilled requirements according to EN 61000 (CE) (Interference immunity of industrial environment) Electrostatic discharge EN 61000-4-2 Contact discharge 4 kV Air discharge 8 kV Comment Criterion A Fast transients (Burst)
  • Page 13: D2 Derating

    DC401W D2 Derating Derating Curves Output Power at -20°C/25°C Output Power at 50°C Output Power at 60°C Output Power at 70°C 110% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% Input Voltage (V) * The line graphs show that the % of current drawn from each output voltage i.e. (5Vsb, 5V, 3.3V, 12V and -12V) The line graphs show that the % of current drawn from each output voltage i.e.
  • Page 14: D3 Efficiency

    DC401W D3 Efficiency is measured with Chroma Device. Input voltage vs. Efficiency Input Voltage (V) Power Derating Input Voltage (V) Output Power (W) 95,29 107,36 119,38 131,4 143,41 Revision 1-0...
  • Page 15: D4 Drawing

    Name / name Ersatz für / replacement for: E Name / Address / Support E-Mail / Phone number of the manufacturer Bicker Elektronik GmbH · Ludwig-Auer-Straße 23 · 86609 Donauwörth · Germany E-Mail: support@bicker.de · Tel.: +49 (0) 906 70595-0 Revision 1-0...
  • Page 16: F General Data

    Before commissioning, check all the connections for correctness! F2 Installation and cooling The DC401W is designed to operate without additional cooling when operated within specification. The power supply must be attached to the housing using the mounting holes provided.
  • Page 17: F3 Description Of Connectors

    Beschreibung / description Erster Winkel / first angle VDC input Plus (+) Maßstab / scale VDC input Minus (–) Ludwig-Auer-Straße 23 Bicker Artikelnummer / article number Blattgröße / Output 8 pole sheet size 86609 Donauwörth Deutschland / Germany Document created www.bicker.de Änderung / Modification...
  • Page 18: F4 Initial Operation

    DESCRIPTION 1x device DC401W F6 Accessory PSZ-1114: Cover Set DC401W MBZ-1024: ATX output cable F7 Reverse polarity / Overcurrent / Short circuit Reverse polarity: The device has active reverse polarity protection at the input if the input terminal is connected with reverse polarity while the device is still switched off (e.g.
  • Page 19: F8 Maintenance

    DC401W F8 Maintenance The DC401W contains no serviceable parts. In case of a malfunction the upstream power source has to be disconnected and cables have to be removed. Use a dry cloth for cleaning! F9 Disposal Electric and electronic devices must not be disposed with domestic waste! Please consider to each country’s own regulation about recycling and dispo-...
  • Page 20 Bicker Elektronik GmbH Ludwig-Auer-Straße 23 86609 Donauwörth · Germany Tel. +49 (0) 906 70595-0 Note: Subject to errors and technical modifications! +49 (0) 906 70595-55 Windows® is a registered trademark of the Microsoft Corp. E-Mail info@bicker.de www.bicker.de Status as at: 08.08.2024 – Revision 1-0...
