- Page 1 KETA POWER Manual...
-
Page 2: Table Of Contents
INDEX Generel information ..................... 3 Guarantee ........................3 Symbols used in manual ....................3 Safety instructions ......................4 Installation ........................5 Controls and display ....................8 How to use ........................10 Power Module ......................16 Care and maintenance ....................19 www.hudevad.com KetaPman.uk.03.024/0... -
Page 3: Generel Information
SYMBOLS USED IN MANUAL IMPORTANT! IMPORTANT! Danger for the safety of persons, pets and things. High temperatures. Risk of burns. IMPORTANT! Danger electric shock. Tips for efficient operation. IMPORTANT! Danger of damage to the appliance. DO NOT COVER THE APPLIANCE! www.hudevad.com KetaPman.uk.03.024/0... -
Page 4: Safety Instructions
Children should not play with the device. Cleaning and maintenance work conducted by the user must not be carried out by unsupervised children. WARNING: Attention should be particularly paid in the presence of children and vulnerable persons. www.hudevad.com KetaPman.uk.03.024/0... -
Page 5: Installation
If in doubt, contact a qualified professional or your local dealer. • During installation, make sure the power cable is disconnected from the power line. Drawing 5.1 1000 W 1800 W 1500 W 1000 W 1800 W 740 mm 1.020 mm 1.160 mm www.hudevad.com KetaPman.uk.03.024/0... - Page 6 H U D E V A D K E T A P O W E R M A N U A L KETA POWER Power No. of elements X (mm) Zb (mm) Z min (mm) 1000 1500 1500 FIXINGS NOT INCLUDED...
- Page 7 If the Pilot Wire is not connected to the programming unit, it must be terminated and insulated. Under no circumstances should the Pilot Wire be connected to the earth. Make sure the power cable cannot in any way come into contact with the surface of the applian- www.hudevad.com KetaPman.uk.03.024/0...
-
Page 8: Controls And Display
Open window Keypad lock Operating modes Standby Mode Chrono program time bar Clock / temperature OK / Window set point MODE Button Low battery Chrono temperature set STAND-BY Button IR Transmitter Days of week Drawing 8.2 Drawing 8.3 www.hudevad.com KetaPman.uk.03.024/0... - Page 9 Do not drop the remote control nor leave it exposed to direct sunlight. Do not spray water or other liquids onto the remote control. Do not place the remote control on top of the appliance or close to intense sources of heat. www.hudevad.com KetaPman.uk.03.024/0...
-
Page 10: How To Use
“Mode” selection key. The hour starts flashing. In the same way, adjust the hour by using the “+” and “-” keys and confirm with “Mode” selection key. Repeat the same procedu- re for the minutes. The year of start is 2019. www.hudevad.com KetaPman.uk.03.024/0... - Page 11 (e) Green Light Flashing: The chosen temperature set point is adequate, but it would be better to further decrease it. Heating off. (f ) Red Flashing : The chosen temperature set point is high, it would be better to decrease it. Heating off. www.hudevad.com KetaPman.uk.03.024/0...
- Page 12 The program code (P1, P2, P3 and P4) flashes. Press the “+” or “-” keys to set the program. Press the “Mode” key to confirm. The icon of the ASC function (see CHAPTER ASC) starts flashing. Press the key to activate the function or the “-” key to de-activate it. www.hudevad.com KetaPman.uk.03.024/0...
- Page 13 “Mode“ selection key. Repeat the same procedure for the hours. The minutes now start flashing. Use the “+” or “-” keys to set the minutes then press the key to con- firm and exit or press the “Mode” key to enter the P4 program setup www.hudevad.com KetaPman.uk.03.024/0...
- Page 14 If the appliance has detected an open window, the “Overdrive (2h)” function will not be active until the window is detected as closed or the “Open Window” function is cancelled (see chapter OPEN WINDOW), however the two-hour countdown continues. www.hudevad.com KetaPman.uk.03.024/0...
- Page 15 The default year, 2019, (from a change of batteries) or the previous set up year (from the pres- sing of key) blinks on the display. The year can be selected by the “+” or “-” keys, and confirmed by key www.hudevad.com KetaPman.uk.03.024/0...
-
Page 16: Power Module
COMFORT The “Comfort FROM POWER MODULE” temperature corresponds to 19°C. All “Pilot Wire” commands are disabled. The LED 1 is violet flashing. This function allows you to use the radiator even without a remote control. www.hudevad.com KetaPman.uk.03.024/0... - Page 17 It must be indicated with a LED 1 Red and LED 2 Violet and four signal acoustic. After the first start-up the equipment will turn on every day an hour earlier according to the following scheme. 22º 19º 22º 19º www.hudevad.com KetaPman.uk.03.024/0...
- Page 18 VIOLET BOOST FROM POWER MODULE 4H HEATING DARK GREEN V IOLET FLASHING BOOST FROM POWER MODULE 6H HEATING LIGHT GREEN V IOLET FLASHING BOOST FROM POWER MODULE 8H HEATING RED FLASHING V IOLET TEST RED FLASHING RED FLASHING www.hudevad.com KetaPman.uk.03.024/0...
-
Page 19: Care And Maintenance
The power line must be fitted at least with a 30 mA RCD (high sensitivity residual current protec- tion device). All the references about the “Pilot Wire“ (Fil Pilote) mode and related wiring present in the in- struction manual must be ignored, since operating mode is not available on this product. www.hudevad.com KetaPman.uk.03.024/0...
