Interstate Batteries HSL0925 Manual

HSL0925
Technical Specifications
Nominal Voltage 6V
Nominal Capacity 9Ah (20 Hr Rate to 1.75V/cell)
Nominal Power 34W/Cell (15 min.)
Chemistry
Lead Acid -AGM
Physical Specifications
Length 151mm
Width 34mm
Height 93mm
Height w/Terminal 98mm
Weight (+/- 5%) 1.34Kg
Terminal Type F2
Case Material ABS
Charging Specifications
Charge Voltage Battery
Cycle 14.4V~15.0V
Max. Charge Current 2.25A
Capacity Specifications
5 Second Discharge Current 135A
Self Discharge (to 80% capacity
Internal Resistance 8mΩ(25°C)
Temperature Specifications
Operating Temperature Capablity
Recommended parameters for optimal battery life and performance: Recommended parameters for optimal battery life and performance: Recommended parameters for optimal battery life and performance:
Charging: 32º F to 104º F (0º C to 50º C), Discharging: 5º F to 122º F (-15º to 50º C), Charging: 32º F to 104º F (0º C to 50º C), Discharging: 5º F to 122º F (-15º to 50º C), Charging: 32º F to 104º F (0º C to 50º C), Discharging: 5º F to 122º F (-15º to 50º C),
Storage: 50º to 77º F (10º C to 25º C) Storage: 50º to 77º F (10º C to 25º C) Storage: 50º to 77º F (10º C to 25º C)
Interstate Batteries
4301 121st Street Urbandale, IA 50323
5.94in
1.34in
3.66in
3.86in
2.95lbs
Per Cell
Float 13.5V~13.8V
2.25V~2.30V
2.40V~2.50V
3 Months 91%
6 Months 82%
12 Months 64%
-40º F (-40º C) to 140º F (60º C)
HIGH RATE
FEATURES:
• Used almost exclusively in backup or cranking
systems
• Provide high percent of capacity in <1 hour
• More efficient connections between plates &
terminals
• Flexibility of mounting orientation
• VRLA technology to eliminate spills and over-
pressurization
• Maintenance-free
866-884-4635
InterstateBatteries.com/all-battery-centers
6/19
