Interstate Batteries SLA1097 Manual

SLA1097
Technical Specifications
Nominal Voltage 12V
Nominal Capacity 10Ah (20 Hr Rate to 1.75V/cell)
Chemistry
Physical Specifications
Length 151mm
Width 65mm
Height 111mm
Height w/Terminal 117mm
Weight (+/- 5%) 3.20Kg
Terminal Type F2
Case Material ABS
Charging Specifications
Charge Voltage Battery
Max. Charge Current 3.0A
Capacity Specifications
5 Second Discharge Current 150A
Self Discharge (to 80% capacity
Internal Resistance 22mΩ(25°C)
Temperature Specifications
Operating Temperature Capablity
Recommended parameters for optimal battery life and performance: Recommended parameters for optimal battery life and performance: Recommended parameters for optimal battery life and performance:
Charging: 32º F to 104º F (0º C to 50º C), Discharging: 5º F to 122º F (-15º to 50º C), Charging: 32º F to 104º F (0º C to 50º C), Discharging: 5º F to 122º F (-15º to 50º C), Charging: 32º F to 104º F (0º C to 50º C), Discharging: 5º F to 122º F (-15º to 50º C),
Storage: 50º to 77º F (10º C to 25º C) Storage: 50º to 77º F (10º C to 25º C) Storage: 50º to 77º F (10º C to 25º C)
Interstate Batteries
4301 121st Street Urbandale, IA 50323
Lead Acid -AGM
5.95in
2.56in
4.37in
6.57in
4.61lbs
Per Cell
Float 13.5V~13.8V 2.25V~2.30V
Cycle 14.4V~15.0V 2.40V~2.50V
3 Months 91%
6 Months 82%
12 Months 64%
-40º F (-40º C) to 140º F (60º C)
GENERAL PURPOSE
FEATURES:
• Used in several types of application
• Approved for all modes of transport
• More efficient connections between plates &
terminals
• VRLA technology to eliminate spills and over-
pressure
• Maintenance-free
866-884-4635
InterstateBatteries.com/all-battery-centers
6/19
