Page 3: Table Of Contents
Speaker Placement ............................19 Mounting the Airmotiv E2+ ........................... 21 Switch Settings on the Airmotiv E2+ ......................22 Mounting the Airmotiv A1 ..........................23 Care and Maintenance ............................ 24 Emotiva Audio Corporation Five-Year Limited Warranty ..............25 Notes ..................................28 Page 1... - Page 4 AIRMOTIV SPEAKERS Page 2...
-
Page 5: Introduction
Airmotiv speakers include removable, magnetically-attached, grilles. All of the speakers in our new Airmotiv series are carefully timbre-matched, so you can feel free to mix and match whichever models are most appropriate to your particular installation requirements. -
Page 6: About This Manual
AIRMOTIV SPEAKERS About This Manual This manual will provide you with all the information you need to achieve great performance, accurate sound, and many years of reliable service from your Airmotiv speakers. We suggest that you read through the entire manual; we kept things as short and direct as possible. -
Page 7: Features
Airmotiv speakers will deliver clean, uncolored, properly balanced sound with very low distortion and outstanding rendition of even the finest details. All of the speakers in the Airmotiv series were carefully timbre matched to work well together, and to deliver a cohesive audio image in any stereo or surround sound installation. -
Page 8: Unpacking
Unpacking Your Airmotiv loudspeakers were carefully packed and should reach you in perfect condition. If you notice any shipping damage or other issues when you unpack them, please contact Emotiva immediately. Gently remove your Airmotiv loudspeakers from the packing carton and remove all wrappings and shipping material. -
Page 9: Emotiva Airmotiv Speakers
AIRMOTIV T1+ AIRMOTIV T2+ The Airmotiv series of loudspeakers is designed to deliver superb performance in any audiophile stereo or home theater sound system. The Airmotiv series includes three different tower loudspeakers, two different center channel models, and two different surrounds, each with slightly different capabilities, as well as a bookshelf monitor model, so we’re sure you’ll be able to... - Page 10 AIRMOTIV SPEAKERS Page 8...
-
Page 11: Airmotiv T0
AIRMOTIV SPEAKERS Airmotiv T0 The Airmotiv T0 is a two way, floor standing, tower loudspeaker, featuring a 32 mm Airmotiv folded ribbon tweeter, and a pair of 5-1/4 inch woven fiber drivers. The dual 5-1/4 inch drivers share the same 2500 Hz electrical crossover frequency, but the upper one is optimized for the critical midrange frequencies, while the lower one is optimized for low frequency response. -
Page 12: Airmotiv T1
AIRMOTIV SPEAKERS Airmotiv T1+ The Airmotiv T1+ is a three way, floor standing, tower loudspeaker, featuring a 32 mm Airmotiv folded ribbon tweeter, a 5-1/4 inch woven fiber midrange, and dual 6 inch woven fiber woofers. The Airmotiv T1+ can be used in an audiophile stereo setup, or as a main front speaker in a home theater installation, or you could use Airmotiv T1+’s all around in a high end home theater installation. -
Page 13: Airmotiv T2
AIRMOTIV SPEAKERS Airmotiv T2+ The Airmotiv T2+ is a three way, floor standing, tower loudspeaker, featuring a 32 mm Airmotiv folded ribbon tweeter, a 5-1/4 inch woven fiber midrange, and dual 8 inch woven fiber woofers. The Airmotiv T2+ can be used in an audiophile stereo setup, or as a main front speaker in a home theater installation, or you could use a full set of Airmotiv T2+’s as the basis of a really high end home theater installation. -
Page 14: Airmotiv B1
AIRMOTIV SPEAKERS Airmotiv B1+ The Airmotiv B1+ is a two way, bookshelf monitor loudspeaker, featuring a 32 mm Airmotiv folded ribbon tweeter and a 5-1/4 inch woven fiber woofer. The Airmotiv B1+ is ideal for use in a small, high-quality two-channel system, and also works well as a home theater speaker in systems where you prefer not to use wall-mounted speakers. -
Page 15: Airmotiv C1
AIRMOTIV SPEAKERS Airmotiv C1+ The Airmotiv C1+ is a three way center channel loudspeaker, featuring a 32 mm Airmotiv folded ribbon tweeter, a 3 inch woven fiber midrange, and dual 5-1/4 inch woven fiber woofers. The Airmotiv C1+ is designed to be used as a center channel speaker in high end home theater installations. -
Page 16: Airmotiv C2
AIRMOTIV SPEAKERS Airmotiv C2+ The Airmotiv C2+ is a three way center channel loudspeaker, featuring a 32 mm Airmotiv folded ribbon tweeter, dual 3 inch woven fiber midrange drivers, and dual 6 inch woven fiber woofers. The Airmotiv C2+ is designed to be used as a center channel speaker in high end home theater installations. -
Page 17: Airmotiv A1 Airspace
AIRMOTIV SPEAKERS Airmotiv A1 AirSpace™ The Airmotiv A1 AirSpace™ is a two way loudspeaker, featuring a 32 mm Airmotiv folded ribbon tweeter and a 4 inch woven fiber woofer, which can be used as a wall mounted direct firing surround sound or height channel speaker, or a ceiling bounce height channel speaker, with any standard or immersive surround sound system. -
Page 18: Airmotiv E2
AIRMOTIV SPEAKERS Airmotiv E2+ The Airmotiv E2+ is a very flexible two way, wall mounted surround sound loudspeaker, featuring dual 32 mm Airmotiv folded ribbon tweeters and a 5-1/4 inch woven fiber woofer. The Airmotiv E2+ can be configured in a variety of ways, enabling you to optimize the surround sound experience to your particular system and room. -
Page 19: Quick Start
AIRMOTIV SPEAKERS Quick Start To get the most from your Emotiva Airmotiv speakers, we urge you to read the entire manual. If you just can’t wait to hear how great your Airmotiv speakers sound, this section will cover the basics you need to get started. -
Page 20: Connections
• Emotiva offers very high quality pre-made speaker cables at reasonable prices (you will find them in the Interconnects section of our website at www.emotiva.com) Several of the Airmotiv speakers provide separate speaker terminals for the woofer and midrange/tweeter sections which allow them to be bi-wired or bi-amped. If you plan to bi-amp or bi-wire your Airmotiv speakers, be sure to remove the jumpers between the two sets of speaker terminals on the rear of the speaker before connecting your amplifier(s). -
Page 21: Speaker Placement
AIRMOTIV SPEAKERS Speaker Placement Speaker placement is often a compromise between optimum performance, personal preference, and site requirements. The optimum location for stereo speakers will depend on the speakers and the acoustics of your listening room. Many surround sound standards have specific recommendations about the optimum position for each speaker, and the different surround sound systems recommend slightly different locations. - Page 22 AIRMOTIV SPEAKERS • If possible, try to make the room acoustically symmetrical from side to side; doing so will usually significantly improve imaging. (If you have something reflective, like a large window, on one side, have a large picture or bare wall on the other. If you have a large absorptive couch on one side wall, balance it with a tapestry on the opposite wall.) •...
-
Page 23: Mounting The Airmotiv E2
AIRMOTIV SPEAKERS Mounting the Airmotiv E2+ Airmotiv E2+ surround speakers are each supplied with a custom heavy duty steel mounting bracket. Affixed to the rear panel of each Airmotiv E2+ are four mounting screws with raised head-studs, each surrounded on the rear surface of the speaker by a rubber pad. The mounting bracket should be secured to your wall using the appropriate mounting hardware for your wall construction. -
Page 24: Switch Settings On The Airmotiv E2
AIRMOTIV SPEAKERS Switch Settings on the Airmotiv E2+ The Airmotiv E2+ surround sound speaker is extremely flexible. Each of the tweeters on the Airmotiv E2+ may be individually configured to be in-phase or out-of-phase with the midrange/woofer using the two small switches on the rear of the speaker. These switches ONLY affect the phase of the tweeters. -
Page 25: Mounting The Airmotiv A1
AIRMOTIV SPEAKERS Mounting the Airmotiv A1 AirSpace™ The Airmotiv A1 AirSpace™ speaker can be used in two different configurations, and can be used as a surround or height speaker, with either a standard surround sound system or one of the new immersive surround sound formats. -
Page 26: Care And Maintenance
AIRMOTIV SPEAKERS Care and Maintenance Periodic Maintenance Your Airmotiv loudspeakers require no periodic maintenance or calibration. Cleaning the Cabinet and Baffle • The cabinets of the Airmotiv loudspeakers should normally be cleaned with a rag dampened with plain water. DO NOT spray water directly onto or into the speaker and DO NOT use abrasive or chemical cleaners. -
Page 27: Emotiva Audio Corporation Five-Year Limited Warranty
The original owner must make a claim within the Term of the Warranty. A claim shall not be valid (and Emotiva has no obligation related to the claim) if it is not made within the Term and if it is not made in strict compliance with the requirements of the “How do you get service?”... - Page 28 If your Product was not adequately packaged, we will refuse receipt and the damaged package will be returned to you at your cost. If you do not have the original Emotiva Audio packaging, please check with our sales department to purchase replacement-shipping cartons.
- Page 29 If you purchased your Emotiva Product outside of the USA and wish to have it serviced at the factory, all freight charges are your responsibility. If you do not have an authorized distributor or repair center in your country, your Product must come back to the Emotiva USA factory for warranty service.
-
Page 30: Notes
AIRMOTIV SPEAKERS Notes All information contained in this manual is accurate to the best of our knowledge at the time of publication. In keeping with our policy of ongoing product improvement, we reserve the right to make changes to the design and features of our products without prior notice. User Manual Revision 1.5 June 2019 Page 28...
