Two Door Manual Defrost
Refrigerators
Le Manuel de Deux Portes
Réfrigérateurs
Dégivrent le
El Manual de Dos Puertas
Refrigeradores
Descongela el
User Manual-
model # HDE10WNA, HDE11WNA
(Features may vary by model)
Guide de l'Utilisateur-
(Les caractéristiques peuvent
modèles HDE10WNA, HDE11WNA
varier en fonction du modèle)
Manual del Usuario-
(Las funciones pueden variar
para modelos de HDE10WNA, HDE11WNA
según el modelo)
Advertisement
Table of Contents
Related Manuals for Haier HDE10WNA - 02-01
Summary of Contents for Haier HDE10WNA - 02-01
-
Page 1: User Manual
HDE10/11WNAWW 10/22/01 11:54 AM Page 1 Two Door Manual Defrost Refrigerators Le Manuel de Deux Portes Réfrigérateurs Dégivrent le El Manual de Dos Puertas Refrigeradores Descongela el User Manual- model # HDE10WNA, HDE11WNA (Features may vary by model) Guide de l’Utilisateur- (Les caractéristiques peuvent... -
Page 2: Safety Precautions
When using this appliance, always exercise basic safety precautions, including the following: 1) Use this appliance only for its intended purpose as described in this use and care guide. 2) This refrigerator must be properly installed in accordance with the installation instructions before it is used. - Page 3 11:54 AM Page 3 English English 10) This refrigerator should not be recessed or built-in an enclosed cabinet. It is designed for freestanding installation only. 11) Do not operate your refrigerator in the presence of explosive fumes. For Future Reference Please...
-
Page 4: Table Of Contents
Refrigerator Door Shelves ..............12 Freezer Features ..................13 Defrosting Your Refrigerator..............14 Food Storage Information..............15 Normal Operating Sounds..............16 Proper Refrigerator Care and Cleaning ........17 Cleaning and Maintenance ..............17 Light Bulb Replacement ................18 Power Interruptions ................18 Vacation and Moving Car e ..............18 Troubleshooting ................19... -
Page 5: Parts And Features
3. Automatic Interior Light Compartments With Removable 4. Automatic Temperature Control Egg Holders 5. 3 Adjustable Full Width Wire Shelves 10.2 Half-Width Adjustable Door Bins 6. Clear Plastic Crisper Cover 11.2 Full Width Fixed Door Bins 7. 2 Clear Crispers... -
Page 6: Installing Your Refrigerator
After properly placing your refrigerator in its final position, you can level your refrigerator. • Leveling legs can be adjusted by turning them clockwise to raise your refrigerator or by turning them counterclockwise to lower your refrigerator. -
Page 7: Electrical Requirements
• Make sure there is a suitable power Outlet (115 volts, 15 amps outlet) with proper grounding to power the refrigerator. • Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet. This is a dangerous practice since it provides no effective grounding for the refrigerator and may result in shock hazard. -
Page 8: Door Alignment
2. Remove the top hinge cover. 3. Loosen the top hinge screws using a phillips head screwdriver. 4. Adjust the door or put a spacer in between and then tighten the screws. 5. Replace the top hinge cover. Hinge box cover fig. -
Page 9: Reversing The Door Swing
1. Fix refrigerator and freezer door by sticking adhesive tape on both sides to hold doors in place. 2. As shown in fig. 1, dismantle the hinge box cover on the upper part of freezer door with a phillips head screwdriver. Then remove the three screws from the hinge. - Page 10 # 5 Central hinge axle 3. As shown in fig. 5, install the central hinge and pad to the left side. 4. To install freezer door: make the left bottom hole of freezer door fall over the central hinge axle; raise upper hinge, so that hinge axle can be installed in the upper hole of the upper part of the freezer door;...
-
Page 11: Refrigerator Features And Use
To remove or adjust a full-width slide-out shelf: (see fig. # 6) 1. Gently tilt the shelf up and slide forward until the shelf has been completely removed. 2. To replace the shelf, select the desired setting and gently slide the shelf back until it rests in the locking position. -
Page 12: Crisper And Crisper Cover
1. Carefully grasp the crisper cover and slide out to remove. fig. # 8 2. To replace, slide the rear of the crisper cover into the right and left slots above the crisper area and gently slide back into place. -
Page 13: Refrigerator Door Shelves
To remove refrigerator door shelves: (see fig. # 9) 1. Remove all items stored on the shelf. 2. Gently push up each side until the shelf is clear of the door shelf brackets and then remove. To replace refrigerator door shelves: (see fig. # 9) 1. -
Page 14: Freezer Features
Page 14 English English To adjust the door shelf bottle huggers: (see fig #10) 1. Grasp the hugger firmly and slide right or left until it is snug against the items stored on the shelf. shelf bottle hugger fig. # 10... -
Page 15: Defrosting Your Refrigerator
• To defrost freezer, remove food and ice cube tray from the freezer section. Turn temperature control dial to OFF position. Defrosting may take a few hours. To speed up defrost time, keep the door open and place a bowl of warm water in the refrigerator. -
Page 16: Food Storage Information
• Eggs should be stored in an upright position in their original carton to maximize shelf life. • Fruit should be washed and dried then stored in a crisper set for low humidity. If you do not have humidity controlled crispers place the items in sealed plastic bags before storing in the crisper. -
Page 17: Normal Operating Sounds
Frozen Food • Proper freezer storage requires correct packaging. All foods must be in packages, which do not allow the flow of air or moisture in, or out. Improper storage will result in odor and taste transfer and will result in the drying out of the improperly packaged food. -
Page 18: Proper Refrigerator Care And Cleaning
Use sponge or soft cloth, dampened with the cleaning solution, to wipe down your refrigerator. • Rinse with clean warm water and dry with a soft cloth. • Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,concentrated detergents, solvents or metal scouring pads. -
Page 19: Light Bulb Replacement
6. Always replace with appliance type light bulb rated at 15 watts or lesser wattage. 7. Do not exceed the 15 watts rating at any time. 8. To replace cover, insert rear clips in first and gently push front clip in until the cover snaps into place. Power Interruptions •... -
Page 20: Troubleshooting
• Check if thermostat control is not in the “OFF” position. • Check if refrigerator is plugged in. • Check if there is power at the ac outlet, by checking the circuit breaker. Food temperature appears too warm • Frequent door openings. - Page 21 • Prolonged or frequent door openings. • Check door gaskets for proper seal. Refrigerator has an odor: • Interior needs cleaning. • Foods improperly wrapped or sealed are giving off odors. Refrigerator light does not work: • Check power supply. • Tighten bulb in socket.
-
Page 22: Warranty Information
What will be done? or consequential damages, so the above limitations may not apply to you. Some 1. We will repair or replace, at our dis- States do not allow limitations on how cretion any mechanical or electrical long an implied warranty lasts, so the part which proves to be defective in above limitations may not apply to you. - Page 23 IMPORTANTE No regrese este producto a la tienda Si tiene algún problema con este producto, por favor contacte el "Centro de Servicio al Consumidor de Haier" al 1-877-337-3639 (Válido solo en E.U.A). NECESITA UNA PRUEBA DE COMPRA FECHADA PARA EL SERVICIO DE LA GARANTIA...
