- Page 1 Read This First Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use, be sure to read the Safety Information in this manual before using the machine.
-
Page 3: Disclaimer
Disclaimer To the maximum extent permitted by applicable laws, in no event will the manufacturer be liable for any damages whatsoever arising out of failures of this machine, losses of the registered data, or the use or non-use of this product and operation manuals provided with it. -
Page 4: About Operating Instructions
About Operating Instructions Operating Instructions explains how to operate and troubleshoot the machine after it is set up. It also lists the detailed specifications of the machine. You can download Operating Instructions from the RICOH home page. https://www.ricoh.com/... -
Page 5: Table Of Contents
TABLE OF CONTENTS Disclaimer ..........................1 About Operating Instructions....................2 1. Safety Information for this Machine Safety Symbols for This Machine ..................7 Safety Information ......................... 8 Safety During Operation ....................8 Safety Precautions to Be Followed ................... 8 Safety notice for remote control ................13 Battery safety notice .................... - Page 6 Component Names and Functions ..................38 Front Side ......................... 38 Back Side .......................... 39 RICOH Interactive Whiteboard A6510 ..............39 RICOH Interactive Whiteboard A7510 / A8610 ............40 Remote Control ........................ 41 Input/Output Terminals ....................42 Front Side ........................42 Back Side ........................
- Page 7 Power save mode ......................50 Standby mode ........................51 When Using the Machine for the First Time ................ 52 5. Appendix Installing the Batteries into the Remote Control ............... 53 Removing the Batteries from the Remote Control ............. 55...
-
Page 9: Safety Information For This Machine
1. Safety Information for this Machine This chapter describes the safety precautions. Safety Symbols for This Machine The meanings of the safety symbols for this machine are as follows: Caution Prohibition No disassembly Caution, risk of electric shock Refer to instruction manual (Please refer to page 13 "Battery safety notice"... -
Page 10: Safety Information
1. Safety Information for this Machine Safety Information Safety During Operation In this manual, the following important symbols are used: Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury. Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property. - Page 11 • At minimum, use a stand with a load capacity of 45 kg or more, and use a stand that matches with the display size of the machine. • RICOH Interactive Whiteboard A6510: 45 kg (99.2 lb.) • RICOH Interactive Whiteboard A7510: 60 kg (132.3 lb.)
- Page 12 1. Safety Information for this Machine • To prevent fire or electric shock, disconnect the plug and the power cord from the wall outlet at least once a year and check them. If any of the following conditions exist, do not use the plug and the power cord continuously, and consult your dealer or service representative.
- Page 13 Safety Information • Do not place the machine in a humid or dusty environment. Doing so can result in fire or electric shock. • Do not use in places with high temperature or humidity (vehicles, ships, airplanes, etc.). Failure to do so could result in malfunction. •...
- Page 14 1. Safety Information for this Machine • If you do not use the machine for a long period of time such as consecutive holidays, be sure to disconnect the power cord plug from the wall outlet for reasons of safety. •...
-
Page 15: Safety Notice For Remote Control
Safety Information Safety notice for remote control • Do not expose the remote control to water or moisture. Failure to do so could result in malfunction. Battery safety notice • Always ensure that the batteries are inserted with the positive and negative terminals in the correct direction. -
Page 16: Safety Labels Of This Machine
1. Safety Information for this Machine Safety Labels of This Machine This section explains the machine's safety information labels. Positions of WARNING labels This machine has labels for WARNING. For safety, please follow the instructions and handle the machine as indicated. Symbols for the Power Switch The meanings of the symbols for the switches on this machine are as follows: •... -
Page 17: Important Safety Instructions
Important Safety Instructions Important Safety Instructions 1. Read this manual carefully. 2. Keep this manual handy for future reference. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this machine near water. 6. Clean only with dry cloth. 7. -
Page 18: Notes On The Lcd Panel Of The Machine
1. Safety Information for this Machine Notes on the LCD Panel of the Machine • The Liquid Crystal Display (LCD) panel of this display has a very thin protective layer of glass which is liable to marking or scratching, and cracking if struck or pressured. The liquid crystal substrate is also liable to damage under excessive force or extreme temperatures. -
Page 19: Information For This Machine
Manufacturer: Ricoh Co., Ltd. 3-6 Nakamagome 1-chome, Ohta-ku, Tokyo. 143-8555, Japan Importer (CE marking, ProdSG): Ricoh Europe SCM B.V. Blankenweg 24, 4612 RC Bergen op Zoom, The Netherlands Importer (UKCA marking): Ricoh UK Limited 900 Pavilion Drive, Northampton, NN4 7RG... -
Page 20: Overseas Affiliates And Noise Emission Information
In accordance with TUV “GS Symbol” requirements, details of the EU office or representative company are given below. Overseas Affiliates Ricoh Europe SCM B.V. Blankenweg 24, 4612 RC Bergen op Zoom, The Netherlands Noise Emission Der höchste Schalldruckpegel beträgt 70 dB(A) oder weniger gemäß EN ISO 7779... -
Page 21: User Information On Electrical And Electronic Equipment
Laws and Regulations User Information on Electrical and Electronic Equipment Users in the countries where this symbol shown in this section has been specified in national law on collection and treatment of E-waste Our Products contain high quality components and are designed to facilitate recycling. Our products or product packaging are marked with the symbol below. -
Page 22: Notes To Usa Users Of Fcc Requirements
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Responsible party: Ricoh USA, Inc. -
Page 23: Using The Shield Cable
Laws and Regulations Address: 300 Eagleview Boulevard, Suite 200 Exton, PA 19341, U.S.A. Telephone number: 610-296-8000 Product Name: RICOH Interactive Whiteboard Model Number: • A6510 • A7510 • A8610 Using the shield cable Caution: Properly shielded and grounded cables and connectors must be used for connections to a host computer (and/or peripheral) in order to meet FCC emission limits. -
Page 24: Remarques À L'attention Des Utilisateurs Canadiens D'appareils Sans Fil
2. Information for This Machine device automatically discontinue transmission in case of either absence of information to transmit or operational failure. Remarques à l'attention des utilisateurs canadiens d'appareils sans fil L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. -
Page 25: Notes To Users In The State Of California (Notes To Users In Usa)
Laws and Regulations Notes to Users in the State of California (Notes to Users in USA) Perchlorate Material - special handling may apply. See: www.dtsc.ca.gov/hazardouswaste/perchlorate For Customers in USA Safety Standard for Button Cell or Coin Batteries and Consumer Products Containing Such Batteries This product contains a non-replaceable Button Cell or Coin Battery. - Page 26 2. Information for This Machine (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
-
Page 27: Environmental Regulations
Environmental Regulations Environmental Regulations ENERGY STAR Program ® ENERGY STAR Program Requirements for Imaging Equipment ® This company is a participant in the ENERGY STAR Program. This machine is compliant with the regulations specified by the ® ENERGY STAR Program. ®... - Page 28 2. Information for This Machine...
-
Page 29: Installing The Machine
• At minimum, use a stand with a load capacity of 45 kg or more, and use a stand that matches with the display size of the machine. • RICOH Interactive Whiteboard A6510: 45 kg (99.2 lb.) • RICOH Interactive Whiteboard A7510: 60 kg (132.3 lb.) -
Page 30: Installation Precautions
3. Installing the Machine Installation Precautions • Be sure to install the machine as close as possible to a wall outlet so that you can disconnect the power cord plug easily in an emergency. • Avoid taking the following actions close to or inside this machine because doing so can result in fire or electric shock: •... - Page 31 Installation Precautions • The following explains the warning messages on the plastic bag used in this product's packaging: • Do not leave the polythene materials (bags, etc.) supplied with this machine close to babies and small children. Suffocation can result if polythene materials are brought into contact with the mouth or nose.
-
Page 32: Stand Mounting Precautions
• If you are using RICOH Interactive Whiteboard A8610 at least five people are required to mount or remove the machine from the stand, or move the machine. -
Page 33: Wall Mounting Precautions
• If you are using RICOH Interactive Whiteboard A6510 / A7510, at least three people are required to mount or remove a bracket, or move the machine. • If you are using RICOH Interactive Whiteboard A8610 at least five people are required to mount or remove a bracket, or move the machine. - Page 34 3. Installing the Machine • Contact your local dealer for details about the recommended wall-mounting bracket for the machine.
-
Page 35: Environmental Specifications
Environmental Specifications Environmental Specifications The following table lists the environmental specifications for the machine: Environment Specifications Temperature 0-40°C (32-104°F) Humidity 10-80% (without condensation) Maximum 5,000 m (16,404 feet) altitude Power AC 100-240 V, 50/60 Hz • The machine is designed for indoor use. •... -
Page 36: Installation Space Requirements
3. Installing the Machine Installation Space Requirements Secure a sufficient amount of clearance around the machine to allow for cable routing and better airflow. • When using multiple machines in close proximity, the touch pens may not operate correctly. In such cases, either place some distance between the machines or arrange them so they are parallel to each other. -
Page 37: Rear
Installation Space Requirements 1. Left: 10 cm (3.9 inches) or more 2. Top: 30 cm (11.8 inches) or more 3. Right: 10 cm (3.9 inches) or more 4. Under: 10 cm (3.9 inches) or more Rear To maintain adequate ventilation, maintain at least 20 mm (0.8 inches) of clear space between the back cover of the display and the wall. - Page 38 3. Installing the Machine...
-
Page 39: Preparations For Using The Machine
4. Preparations for Using the Machine Checking the Accessories If anything is missing or damaged, contact your sales representative or service representative. • Read This First • Quick Guide • Power cord • USB cable • HDMI cable • Remote control •... -
Page 40: Component Names And Functions
4. Preparations for Using the Machine Component Names and Functions Front Side 1. Pen attachment position Attaches the supplied pens 2. Input/Output terminals For details, see page 42 "Input/Output Terminals". 3. Built-in speaker Outputs the audio input from the machine or the connected device 4. -
Page 41: Back Side
Used to display the system setting screen 11. Volume buttons Used to adjust the volume Back Side RICOH Interactive Whiteboard A6510 1. AC IN Connects to a power outlet via the supplied power cord 2. Main power switch Turns on or off the main power •... -
Page 42: Ricoh Interactive Whiteboard A7510 / A8610
4. Preparations for Using the Machine 4. Input/Output terminals For details, see page 42 "Input/Output Terminals". RICOH Interactive Whiteboard A7510 / A8610 1. AC IN Connects to a power outlet via the supplied power cord 2. Built-in speaker Outputs the audio input from the machine or the connected device 3. -
Page 43: Remote Control
Component Names and Functions Remote Control 1. Power button Used to switch to power save mode or standby mode, or to return to power on 2. Select button Used to operate the screen and the settings 3. Sidebar menu button Displays/hides the sidebar menu 4. -
Page 44: Input/Output Terminals
4. Preparations for Using the Machine 10. Writing button Enters a mode in which you can write to the currently displayed content 11. Screenshot button Takes a screenshot of the screen that is displayed 12. Mute button Turns on or off the mute function. Used to temporarily disable audio input on the machine. -
Page 45: Back Side
4. PUBLIC-USB3.0 (USB 3.0 Type-A) Connects the machine to the external device so that they can communicate Back Side This section uses RICOH Interactive Whiteboard A6510 as an example. 1. LAN (Ethernet interface) Connects the Ethernet cable to connect the machine to the network... - Page 46 4. Preparations for Using the Machine 5. HDMI (HDMI input) Connects to a HDMI compatible device 6. USB3.0 (USB 3.0 Type-A) Connects the machine to the external device so that they can communicate 7. RS-232 (RS-232 input) Receives control signals from a computer or another display 8.
-
Page 47: Connecting The Touch Module
Connecting the Touch Module Connecting the Touch Module Connect the port on the machine that supported the touch module to the USB port of a computer, by using the USB cable. The touch module of the machine supports easy Plug-and-Play operation. There is no need to install additional drivers on the computer. - Page 48 4. Preparations for Using the Machine • Do not touch the display while connecting the machine to a computer or turning the machine on. • When connecting cables to HDMI and TOUCH-USB on the back side of the machine, use the supplied cable clamp to secure the HDMI cable and USB cable.
-
Page 49: Connecting Power
Connecting Power Connecting Power • The supplied power cord or cords are for use with this machine only. They cannot be used for appliances other than this machine. Also, do not use power cords other than the power cord or cords supplied with this machine. Doing so can result in fire or electric shock. - Page 50 1. Plug one end of the power cord into the AC IN on the machine and the other end into an appropriate power outlet. If the outlet is switched, turn on the switch. The following illustration uses RICOH Interactive Whiteboard A6510 as an example.
- Page 51 Connecting Power • When connecting the power cord to AC IN on the back side of the machine, use the supplied cable clamp to secure the power cord.
-
Page 52: Turning On The Power
1. Press the main power switch on the back side of the machine. • RICOH Interactive Whiteboard A6510 • RICOH Interactive Whiteboard A7510 / A8610 When you turn on the main power switch, the machine will start up. When the machine starts up, the indicator on the front side of the machine will light up, and the home screen will appear. -
Page 53: Standby Mode
Turning ON the Power 1. Press the power button on the front side of the machine or on the remote control. • Front side of the machine • Remote control 2. To return from power save mode, press the power button again. Standby mode 1. -
Page 54: When Using The Machine For The First Time
4. Preparations for Using the Machine When Using the Machine for the First Time When using the machine for the first time, the settings screen will appear after you turn ON the power. Follow the instructions displayed on the screen to complete the settings. 1. -
Page 55: Appendix
5. Appendix This chapter describes how to load batteries into the remote control. Installing the Batteries into the Remote Control • When batteries fail to function, replace them immediately. • There may be local restrictions on the disposal or recycling of batteries. Consult your local regulations or waste disposal provider. - Page 56 5. Appendix 3. Refit the battery cover.
-
Page 57: Removing The Batteries From The Remote Control
Removing the Batteries from the Remote Control Removing the Batteries from the Remote Control 1. Open the remote control battery cover. 2. Remove the batteries. 3. Refit the battery cover. - Page 58 MEMO...
- Page 60 FCC statement: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
