Safavieh Outdoor Chester PAT-7322 Manual

NOTICE
*Please make sure that you heve all parts indicited and they are in good condition before you
begin assembly of this item. Refer to part list and hardware list below for guidence.
*This item should be assembled on a soft surface to prevent scratching the finish during
assembly.
*This item may require periodic tightenning.
*If you are having difficulty, our friendly Customer Care team is always here to help. Please
email customersupport@safavieh.com.
PREPARATION
* Before beginnning assembly of product, make sure all parts are present. Compare parts with
part contents list and hardware contents list.
* If any part is missing or damged,do not attempt to assemble the product.
* Estimated Assembly Time: 10 minutes.
*Tools Required for Assembly (included): Allen Key
CARE AND MAINTENANCE
Insert Care and Maintenance here
Part List and Hardware List
PIECE DESCRIPTION
A Frame
B Frame Seat
Frame 1
C
Leg Side Frame 2
D
E Cross Frame Leg
CSH1
Seat Cushion
CSH2 Back Cushion
QUANTITY
1X
1X
1X HW1
HW2
1X
HW3
2X
Model# PAT-7322
Product Dimensions:59.1" W x 37.0" D x 27.4" H
WARNING
400
Allen Bolt: M6x0.5x40 mm
Allen Bolt: M6x0.5x30 mm
Allen key
8X
M6x40
4X
M6x30
2X
LG4
