Quick Start Guide
KVM Extender USB
Este guía esta disponible en español en la página de Tripp Lite:
Ce guide est disponible en français sur le site Web de Tripp Lite :
Русскоязычная версия настоящего краткого руководства представлена
на веб-сайте компании Tripp Lite по адресу: tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
Model: 0DT60001
tripplite.com/support
tripplite.com/support
by
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tripp Lite MINICOM 0DT60001
Summary of Contents for Tripp Lite MINICOM 0DT60001
- Page 1 Model: 0DT60001 Este guía esta disponible en español en la página de Tripp Lite: tripplite.com/support Ce guide est disponible en français sur le site Web de Tripp Lite : tripplite.com/support Русскоязычная версия настоящего краткого руководства представлена на веб-сайте компании Tripp Lite по адресу: tripplite.com...
-
Page 2: Important Safety Instructions
1. Important Safety Instructions • The device must only be opened by a qualified technician. • Disconnect device from AC mains before service operation! • Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended. - Page 3 4. KVM Extender USB Units 4.1 Transmitter Button / LEDs Button / LED Function Lock button Press to keep control of the connected computer at the Transmitter position. Control LED Blinks when Transmitter position has control of the Transmitter position computer. Note: In order to have control of the transmitter (local) PC peripherals (keyboard + mouse), the remote (receiver’s) local button must be pressed and the local LED on the receiver unit must be solid green.
-
Page 4: Pre-Installation Instructions
4. KVM Extender USB Units 4.2 Receiver Buttons / LEDs The Receiver can be located up to 500 ft. (150 m) away from the Transmitter. Button / LED Function Lock button Press to lock control of the Transmitter computer at the Receiver position. -
Page 5: Connecting The System
6. Connecting the System When using the system as an extender, connect the system as shown in Figure 6-1. The connections are explained below. VGA + USB Cable Extended User Cat5 Cable - Position 500 ft. (150 m) Receiver Transmitter Figure 6-1: KVM Extender USB as an extender 6.1 Connecting the Transmitter Connect a VGA + USB + PS/2 cable (Figure 6-2) to the Transmitter and a computer. - Page 6 7. Extender System with Optional Computer at Receiver Position You can connect a computer to the Receiver position. The Receiver position can then either control the local computer or the Transmitter position computer (Figure 7-1). Optional PC Extended User Cat5 Cable - Position 500 ft.
- Page 7 9. Operating the KVM Extender USB System The system works on a first-come, first-served basis – press the keyboard or move the mouse at either the Transmitter (where relevant) or Receiver position to take control of the Transmitter position computer. Transmitter Position: Press the Lock button to keep/gain control of the computer at the Transmitter position.
- Page 8 3-Year Limited Warranty TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
