Summary of Contents for Marq GESTURE SPOT 500

  • Page 1 English Quickstart Guide...
  • Page 2: Box Contents

    Introduction Box Contents Gesture Spot 500 Quickstart Guide Power Cable Safety & Warranty Manual DMX Cable Important: Visit marqlighting.com to download the complete User Guide. Support For the latest information about this product (documentation, technical specifications, system requirements, compatibility information, etc.) and product registration, visit marqlighting.com.
  • Page 3: Rear Panel

    5. DMX In: Use a standard 3-pin DMX cable to connect this input (A) to your DMX controller or (B) to another fixture that will pass DMX data through it to this one. Gesture Spot 500 receives DMX data over this connection. Please see Setup >...
  • Page 4: Power Information

    Also, make sure the power outlet’s voltage is within the range stated on this product (on its housing or decal). Before cleaning or replacing the fuse, disconnect Gesture Spot 500 from its power source. Use a screwdriver or other tool to remove the compartment (do not pull it out by the tab only). Replace the fuse only with a new fuse with the same rating (250 V, 4 A).
  • Page 5 Linking When using multiple Gesture Spot 500 fixtures, you can link (“daisy-chain”) them so that each each fixture supplies power and/or sends DMX data to the next one. This helps reduce clutter in your cabling and save you setup time.
  • Page 6: Operation

    Operation Menu Options Menu Submenu Settings/Values Description DMX Address 001–512 DMX address setting Function Channel Mode 15Ch 15-channel operation 8-channel operation No DMX Signal Keep When no DMX signal, do nothing (hold) Auto When no DMX signal, enter Run Mode Clear When no DMX signal, black out DMX Monitor...
  • Page 7: Dmx Functions

    Restore all default settings Reset All DMX Functions You can control Gesture Spot 500 by linking it to a DMX controller. Please see the complete User Guide at marqlighting.com to learn how to do this. See below for charts of available functions.
  • Page 8 15-Channel Operation (continued) Channel Function Value Description Color Wheel 000–006 White 007–013 Red 014–020 Orange 021–027 Green 028–034 Light Blue 035–041 Purple 042–048 Yellow 049–055 Blue 056–063 Pink 064–127 Color indexing 128–189 Clockwise, fast (128) to slow (189) 190–193 Stop 194–255 Counterclockwise, slow (194) to fast (255) Gobo Wheel 000–007 Open/white...
  • Page 9 15-Channel Operation (continued) Channel Function Value Description Prism Rotation 000–127 Indexed position, 0° (000) to 360° (127) 128–189 Counterclockwise prism rotation, fast (128) to slow (189) 190–193 Stop at current position 194–255 Clockwise prism rotation, slow (194) to fast (255) Macro Functions 000–007 No function...
  • Page 10 8-Channel Operation Channel Function Value Description 000–255 Pan angle, 0° (000) to 540° (255) Tilt 000–255 Tilt angle, 0° (000) to 270° (255) Shutter 000–003 Closed 004–007 Open 008–076 Strobe, slow (008) to fast (076) 077–145 Pulse, slow (077) to fast (145) 146–215 Random strobe, slow (146) to fast (215) 216–255...
  • Page 11: Technical Specifications

    Technical Specifications Specifications are subject to change without notice. Light Type Power 120 W 8 + white, split colors, scrolling Colors 7 + open, slot-and-lock replaceable with rotation, Gobos indexing, gobo shake & scrolling 0.93” (23.5 mm) outside 0.75” (19 mm) image 0.04”...
  • Page 12 Lumen Output Lumens: 89800 11200 4100 12.8° Distance (m): 0 (ft.): 0 16.4 Diameter (cm): 0 (in.): 0 10.2 27.6 43.7 Gobos These are the 7 gobos included with Gesture Spot 500. marqlighting.com Manual Version 1.2...
