- Page 1 English Quickstart Guide...
-
Page 2: Box Contents
Introduction Box Contents Gesture Beam 400 Quickstart Guide Power Cable Safety & Warranty Manual DMX Cable Important: Visit marqlighting.com to download the complete User Guide. Support For the latest information about this product (documentation, technical specifications, system requirements, compatibility information, etc.) and product registration, visit marqlighting.com. -
Page 3: Rear Panel
5. DMX In: Use a standard 3-pin DMX cable to connect this input (A) to your DMX controller or (B) to another fixture that will pass DMX data through it to this one. Gesture Beam 400 receives DMX data over this connection. Please see Setup >... -
Page 4: Power Information
Also, make sure the power outlet’s voltage is within the range stated on this product (on its housing or decal). Before cleaning or replacing the fuse, disconnect Gesture Beam 400 from its power source. Use a screwdriver or other tool to remove the compartment (do not pull it out by the tab only). Replace the fuse only with a new fuse with the same rating (250 V, 4 A). - Page 5 Linking When using multiple Gesture Beam 400 fixtures, you can link (“daisy-chain”) them so that each each fixture supplies power and/or sends DMX data to the next one. This helps reduce clutter in your cabling and save you setup time.
-
Page 6: Operation
Operation Menu Options Items marked with * are visible when Display Settings > Menu Detail is set to Advanced. Menu Submenu Settings/Values Description Address 001–512 DMX address setting Functions Personality 15-channel operation 8-channel operation Show When no DMX signal, enter Show Mode Offline Mode * Hold When no DMX signal, do nothing (hold) -
Page 7: Dmx Functions
Reset All * Factory Settings * DMX Functions You can control Gesture Beam 400 by linking it to a DMX controller. Please see the complete User Guide at marqlighting.com to learn how to do this. See below for charts of available functions. - Page 8 15-Channel Operation (continued) Channel Function Value Description Color Wheel 000–006 White 007–013 Red 014–020 Orange 021–027 Green 028–034 Light Blue 035–041 Purple 042–048 Yellow 049–055 Blue 056–063 Pink 064–127 Color indexing 128–189 Clockwise, fast (128) to slow (189) 190–193 Stop 194–255 Counterclockwise, slow (194) to fast (255) Gobo Wheel 000–007 Open/white...
- Page 9 15-Channel Operation (continued) Channel Function Value Description Prism Rotation 000–127 Indexed position, 0° (000) to 360° (127) 128–189 Counterclockwise prism rotation, fast (128) to slow (189) 190–193 Stop at current position 194–255 Clockwise prism rotation, slow (194) to fast (255) Movement Macros 000–007 No function...
- Page 10 8-Channel Operation Channel Function Value Description 000–255 Pan angle, 0° (000) to 540° (255) Tilt 000–255 Tilt angle, 0° (000) to 270° (255) 000–003 Closed Shutter 004–007 Open 008–076 Strobe, slow (008) to fast (076) 077–145 Pulse, slow (077) to fast (145) 146–215 Random strobe, slow (146) to fast (215) 216–255...
-
Page 11: Technical Specifications
Technical Specifications Specifications are subject to change without notice. Light Type Power 75 W 8 + white, split colors, scrolling Colors 8 + open, gobo shake & scrolling Gobos 0.93” (23.5 mm) outside 0.75” (19 mm) image 0.04” (1.1 mm) max thickness Illuminance 81,400 lux @ 3 m (9.8 ft.) 5°... - Page 12 Lumen Output Lumens: 96400 81400 33200 5° Distance (m): 0 (ft.): 0 16.4 Diameter (cm): 0 (in.): 0 11.8 Gobos Gobo 1 Gobo 2 Gobo 3 Gobo 4 Gobo 5 Gobo 6 Gobo 7 Gobo 8 marqlighting.com Manual Version 1.0...
