AS80KE11
WIRELESS KEYPAD
Installation Instructions
General Introduction
The Wireless Keypad is used to Arm/Disarm the system by using a four digit
access code authentication. Users may assign different PIN codes to identify
and allow control by members of the family. The Keypad also incorporates a
Panic function for emergency use and an anti-tamper protection feature that will
immediately initiate a Full Alarm condition when anyone attempts to open its
casing.
Product Layout
Setting/low battery LED
Key
Meaning of Key
0 - 9
Access code input
Arm
Part-arm 1
Part-arm 2
Disarm
Binding
Loosen and remove the locking screw
from the bottom of the Keypad.
1. Remove the wall mounting plate.
2. Prepare three AA 1.5V alkaline batteries. Do not insert them into the unit yet.
3. Log into the ELRO Smart Home Alarm account from a web browser.
4. Select "System", then "Add a Device".
5. Select "Keypad".
1
Wall mounting plate
Advertisement
Table of Contents
Related Manuals for ELRO AS80KE11
Summary of Contents for ELRO AS80KE11
- Page 1 Product Layout 2. Prepare three AA 1.5V alkaline batteries. Do not insert them into the unit yet. 3. Log into the ELRO Smart Home Alarm account from a web browser. Meaning of Key Setting/low battery LED 0 - 9...
-
Page 2: Manual Binding
6. The following screen will appear. This means the gateway is entering binding mode. 1. Repeat steps 5 to 8 of the Binding with ELRO Smart Home Alarm. 2. Press buttons 1-2-3-4-3, the keypad should enter binding mode. 3. This screen below will appear in 10 seconds if the process is successful. -
Page 3: Operation
In “Keypad codes”, enter the Username in the first box, and the desired 2. Panic access code in the second box (it will appear starred). Press simultaneously for 2 seconds. The keypad will emit the radio signal to the system and a full alarm condition will occur. -
Page 4: Maintenance
1. Undo and remove the fixing screw from the bottom edge of the Keypad and Enabling/Disabling the Panic function remove the wall mounting plate (Figure 2). If the keypad is mounted outside of your home, e.g. in apartment hallway or stairs, you may choose to disable the Panic function to prevent abuse by strangers triggering an alarm condition in your home. -
Page 5: Troubleshooting
Troubleshooting Specifications The troubleshooting table lists some possible causes and solutions. Please Battery Type AA 1.5V Alkaline battery x 3 contact your original retailer or nearest service center if the below solutions Operating Frequency 868MHz cannot solve your problem. Symptom Possible Cause Recommendation ** Specifications are subject to change and improvement without notice.
