- Page 1 COMPACT UNDERWATER VIEWING SYSTEM USER MANUAL www.MarCumTech.com...
-
Page 2: Specifications
Micro-SD card GETTING STARTED The Pursuit HD L has an on-screen display of the battery status found in the upper left side of the video image. Once the video image starts the battery status indicator will detail a series of green bars. Three full green bars will indicate a full charge. - Page 3 (see “Built-In DVR”) PURSUIT HD L MENU OPTIONS For ease of use, the menu system on the Pursuit HD L times out after a 5 second period of inactivity and defaults back to the camera image without any additional keystrokes required.
- Page 4 PURSUIT HD L FEATURES Camera Lights The Pursuit HD L is equipped with both LED and Infrared Lighting (IR) options. Each lighting option has multiple intensity levels. To turn on the LED lights, use the LED/UP button on the control panel.
-
Page 5: Dvr Operation
www.MarCumtech.com DVR OPERATION Accessing the micro-SD card To access the micro-SD card slot, open the rectangular rubber cap on the left side of the unit. The card can be inserted by placing it into the slot and pressing downwards until it clicks into place. To remove the micro-SD card, press down on the card. - Page 6 Make sure to remove the protective plastic film that covers the lens for packaging. Atop the Pursuit HD L camera is a positioning system (three tabs). Set the cable to the correct position to select your viewing angle (see “Camera Positions”).
-
Page 7: On-Screen Displays
CAMERA POSITIONS The native position of underwater cameras is horizontal. To achieve that viewing angle with the Pursuit HD L, rotate the ratcheting tensioner 90 degrees from the camera head, and attach to the cable hanger. Changing camera angles is made simple by rotating the camera while holding the ratcheted tensioner assembly. -
Page 8: Operating Positions
Mounted The Pursuit HD L features a ¼ 20 insert on the bottom edge of the Camera Screen (Mounts not included). The ¼”-20 insert is the most common mounting option for photo/video equipment that provide limitless mounting solutions from aftermarket suppliers. -
Page 9: Battery Warnings
– To best serve our customers, MarCum Technologies has set a standardized battery warranty policy. Battery warranty coverage requires a proof of purchase. Please see our website, www.marcumtech.com/support for full details on warranty coverage. Battery Warnings Do not immerse the battery in water or sea water. Keep the battery in a cool dry place when not in use. - Page 10 MarCum Technologies. It is the customer’s full responsibility to track their products sent out in the mail or other forms of delivery service. MarCum Technologies will not be liable for packages lost in route to us. Unless specified otherwise, do not include batteries or other accessories when returning the product for repair.
- Page 11 Daytime/Cell Phone # ____________________________________________________ Email Address ____________________________________________________ Which Marcum do you have? ____________________________________________________ Date of Purchase ____________________________________________________ Description of the issue ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ -------------------------------------------------- MarCum Technologies Attn: Service Department 3943 Quebec Avenue North Minneapolis, MN 55427 - 11 -...
- Page 12 MarCum Technologies 3943 Quebec Ave N Minneapolis, MN 55427 MarCum User Manuals are available for downloads from www.MarCumtech.com. 2021-0520 - 12 -...
