Summary of Contents for BlueStar TOUCH
- Page 1 INSTALLATION MANUAL TOUCH Induction Cooktop 701123...
- Page 2 BlueStar® TOUCH Induction Cooktop Installation Manual Model BSP36INDTOUCH Fitting and Installing WARNING Do not change or alter the appliance. Do not use any extension cable to connect it. The appliance is not intended to be operated by means of external timer or separate remote control system.
- Page 3 Nameplate Location The appliance’s product identification tag is located underneath the appliance, as shown below. The serial number of your appliance can be found on that label. Write down this number and keep it with the Use & Care manual.
- Page 4 INSTALLATION SPECIFICATIONS – NON-FLUSH INSTALLATION Apply Gasket: The gasket supplied with the appliance avoids all contact of liquids with the cabinet. Installation must be done carefully, and reflect the below drawing. Stick the gasket (2) 3/64” from the external edge of the glass, after removing the protection sheet (3).
- Page 5 INSTALLATION SPECIFICATIONS – FLUSH INSTALLATION R=5/16” 13/64” 2” mini 19.25” 34.5” 21.2” 36.2” Ensure that there is a distance of 2” between the appliance and the wall or sides. Ideally the appliance should be installed with plenty of space on either side. There may be a wall at the rear and tall units or a wall at one side.
-
Page 6: Installation Instructions
The inlet hose must be positioned so that it does not touch any of the hot parts of the cooktop or oven. This appliance must only be connected to a network 230 VAC~ 50/60 Hz CAUTION! Always connect the ground wire. -
Page 7: Troubleshooting
• The sensitive touch keys are covered with grease or water. • An object is placed on a sensitive touch key. • The safety system (lock) is engaged. • The safety system automatically engages if the heat zone isn’t turned off. -
Page 8: Performance Checklist
PERFORMANCE CHECKLIST This checklist has been developed to assure proper installation of your appliance. To validate your warranty you must mail or submit online this form within 15 days of installation and a copy of your receipt to: Warranty Department, Prizer-Painter Stove Works Inc., 318 June Avenue Blandon, PA 19510 or www.bluestarcooking.com/support/product-registration/.
