Summary of Contents for BlueStar BSP36INDCKT

  • Page 1 USE & CARE MANUAL USE & CARE MANUAL Induction Cooktop 750164...
  • Page 2 BlueStar® Induction Cooktop Model BSP36INDCKT This appliance was designed for ease of installation and operation. However, we recommend that you read all section of this manual before your begin installation and use. Do not remove permanently affixed labels, warnings or data plates from your appliance. This may void the manufacturer’s warranty and/or hinder effective servicing and maintenance.
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS Read all instructions before using your appliance. Follow these important safety precautions to reduce the risk of fire, electric shock, personal injury or property damage. Do not remove permanent labels, warnings or data plates including the serial number from your appliance.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING OLLOW HESE UIDELINES FOR NDUCTION OOKING AILURE TO OMPLY ESULT IN ERSONAL NJURY OR AMAGE THE OOKTOP  Cooking Utensils – Only ferromagnetic pans are suitable for induction cooking. These can be of enameled steel, cast iron, or special stainless steel utensils for induction cooking.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING OLLOW HESE UIDELINES FOR NDUCTION OOKING AILURE TO OMPLY ESULT IN ERSONAL NJURY OR AMAGE THE OOKTOP Electromagnetic interference This induction cooktop generates and uses ISM frequency energy that heats cookware by using an electromagnetic field. It has been tested and complies with Part 18 of the FCC Rules for ISM equipment.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING  CAUTION - Do not store items of interest to children in cabinets above or the backguard behind the appliance. Children climbing on the appliance to reach items could be seriously injured.  DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS – Surface units may be hot even though they are dark in color.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS WARNING VENT OF AKE THE OLLOWING TEPS TO REVENT NJURY AND PREADING  Turn off the cooktop.  Turn off any ventilation units.  Do Not Use Water on Grease Fires – Smother fire or flame or use dry chemical or foam-type extinguisher.
  • Page 8 BlueStar® appliances are designed for discerning home chefs who demand restaurant-quality results in their own kitchens. As the owner of a new BlueStar® appliance you can look forward to years of culinary excellence. You will prepare meals with the speed and accuracy of a professional chef right in your own kitchen.
  • Page 9: Service Information

    NOTE: WARRANTY SERVICE MUST BE PERFORMED BY AN AUTHORIZED SERVICE AGENT. YOU MAY REQUEST WARRANTY SERVICE BY CALLING-800 449-8691. YOU MAY ALSO REQUEST SERVICE FROM AN AUTHORIZED BLUESTAR DEALER AT WWW.BLUESTARCOOKING.COM/SUPPORT...
  • Page 10: Getting Started

    GETTING STARTED We know you are excited to start using your new BlueStar® appliance. Before you begin, it is essential that you follow these steps for safe and optimal use.  Read this manual it its entirety and keep near your appliance.
  • Page 11: Use And Care

    USE AND CARE GUIDE TO THE INDUCTION COOKTOP 7” (180 mm) 8 2/3”x7 ” (220x180 mm) 1,850 W 2100 W 3,000 W Boost 3,700 W Boost 10 1/4” (260 mm) 2600 W 5,500 W Boost 8 2/3”x7 ” (220x180 mm) 7”...
  • Page 12 DISPLAY Each knob controls a cooking zone. Operation indicators are shown in the display area. Display area Display Designation Description Page Cooking level Selection of the cooking level. … No pan detected No pan or inadequate pan 14, 16 Booster Booster is activated Heat accelerator Automatic cooking...
  • Page 13: Before You Begin

    BEFORE YOU BEGIN Clean the Cooktop  Remove and properly discard all temporary labels and self-adhesives from the ceramic glass.  Clean your cooktop with a damp cloth, and then dry the surface thoroughly. WARNING Do not use detergent; this can create a blue-tinted color on the glass surface. Cookware Compatibility The cookware must be induction compatible.
  • Page 14 Cookware Flatness For optimal efficiency, cookware should have flat bottoms. Noise Certain pans can make noise when they are placed on an induction cooking zone. Some pans are noisier then other. When used at maximum power, the unit will become noisier. The pan will begin vibrating and the cooling fan will start.
  • Page 15: Operating The Induction Cooktop

    OPERATING THE INDUCTION COOKTOP On/Off 1. Place an induction-compatible pot or pan on a cooking zone. 2. To start, turn the knob corresponding with the desired zone clockwise to the right. 3. The corresponding zone will illuminate in the display area. 4.
  • Page 16 OPERATING THE INDUCTION COOKTOP Booster Function Booster [P] gives a boost to the selected heating zone. When this function is activated, the heating zones work for 10 minutes at an ultra-high speed. This is designed for heating large quantities of water very quickly. 1.
  • Page 17 OPERATING THE INDUCTION COOKTOP Heat Accelerator All the cooking zones are equipped with a heat accelerator function so you can get to temperature faster with the turn of a knob. The cooking zone starts at full power for a certain amount of time, and then automatically reduces its power until it reaches the pre-selected power level.
  • Page 18 OPERATING THE INDUCTION COOKTOP Keep Warm Function This function allows the cooking zones to reach and automatically maintain a temperature of 150° F (70°C) or 201°F (94°C) and prevents liquids from boiling over or burning the cookware. The Keep Warm at 150° F and Keep Warm at 201°...
  • Page 19 OPERATING THE INDUCTION COOKTOP Control Panel Lock The control panel can be locked to prevent operating or modifying the cooking zone settings. This setting can be used when cleaning the cooktop or for added safety. 1. To Lock the Cooktop - Turn the front left and rear left cooking zone knobs to the left (counter- clockwise) at the same time and hold for 3 seconds.
  • Page 20 OPERATING THE INDUCTION COOKTOP Residual Heat Indicator Although the cooking surface is not producing any heat, the hot bottoms of WARNING cookware will conduct heat to the glass. After cooking, the zones will remain hot. There are risks of burns and fire. ...
  • Page 21 CARE Follow these guidelines to prevent personal injury or damaging your ATTENTION induction cooktop:  Raw cookware like cast iron (not enameled cast iron) or damaged cookware may damage the ceramic glass.  Gritty or other abrasive materials may damage the ceramic glass. ...
  • Page 22 CLEANING WARNING Turn the Induction cooktop off and make sure it is cool before cleaning.  To avoid a risk of a burn, do not clean the cooktop when the glass is hot and the Residual Heat (H) indicator is lit. ...
  • Page 23: Troubleshooting

    TROUBLESHOOTING Check these helpful tips for any problems with your cooktop. If you need additional help call BlueStar® Customer Service at 800-449-8691. PROBLEM POSSIBLE CAUSE SOLUTION • The cooktop has a poor connection to the electrical network. • The safety fuse is cut off.
  • Page 24 PERFORMANCE CHECKLIST This checklist has been developed to assure proper installation of your appliance. To validate your warranty your installer must complete this form online before leaving your residence at www.bluestarcooking.com. Email this form within 15 days of installation, with a copy of your receipt to: serviceteam@bluestarcooking.com, or fill out the form on our website at www.bluestarcooking.com Customer Information (Please Print)
  • Page 25: Limited Warranty

    LIMITED WARRANTY BlueStar® Cooking Appliances, BlueStar® Ventilation Hoods and Prizer Hoods® Ventilation Hoods Who Is Providing The Warranty? conditions beyond Prizer-Painter’s control.  Damage or repairs caused by alteration for outdoor use. This Warranty is provided to you by Prizer-Painter Stove Works, Inc.
  • Page 26 light bulbs, and enameled parts. Cosmetic component flaws include invalid and will not be honored. visible chips, scratches, dents. All cosmetic component claims to Prizer-Painter must be made within the seven (7) day warranty period or they are void. To obtain Warranty service, where applicable, the Owner must call the factory (toll free: 1-800-449-8691) to report a warranty claim, .Floor Models Not Used For Demonstration: Floor models are and must, at that time, provide (1) the model number of the...
  • Page 27 ARBITRATION CLAUSE. IMPORTANT. PLEASE REVIEW THIS ARBITRATION CLAUSE. IT AFFECTS YOUR LEGAL RIGHTS. 1. Parties: This arbitration clause affects your rights against Prizer- 8. Rules of the Arbitration: If the amount in controversy is less Painter Stove Works, Inc. and any of its affiliates or employees or than $50,000, the arbitration will be decided by a single arbitrator.
