Anywire ASLINKTERMINAL BL296 B-08F-4-20 Series Product Manual

AnyWireASLINK System Products Guide
ASLINKTERMINAL [ASLINK integrated terminal]
BL296□B-08F□-4-20
The Products Guide describes individual products. Refer to the Guide as necessary.
■Function List
Model
ASLINKTERMINAL NPN eight-point input/eight-point output
four-wire (isolated) PNP eight-point input/eight-point output
integrated small terminal NPN four-point input/four-point output (hybrid)
e-CON eight-point PNP four-point input/four-point output (hybrid)
■Notes on use ⇒ Setting of addresses and similar items requires "address writer ARW-04 (Ver.04-1.01 or
higher) or ARW-03 (Ver.2.10 or higher)." Please prepare it separately.
[Notes on Safety]
Precautions that must be observed in order to use this system safely are indicated as shown below.
You must observe these precautions.
A WARNING indicates a potentially hazardous
situation which, if not handled correctly, could
result in death or serious injury.
WARNING
○ System Safety
This system is intended for general industrial applications. It does not have functions for supporting applications requiring higher levels of
safety such as safety-related devices or accident prevention systems.
WARNING
○ Always turn off the system power before attempting to mount or replace.
○ Prolonged continuous ow of a rated load current or higher or a transit current due to load short-circuit or similar problem, in the hybrid unit
including the output unit and the output circuit may result in smoke generation or re. An external safety device such as a fuse must be
installed.
○ System power supply
Use a stabilized 24V DC power supply. Use of a non-stabilized power supply may cause problems with the system.
○ Separately route high-voltage and power cables
CAUTION
Although the AnyWireASLINK has a high noise margin, lay the transmission lines and I/O cables so as to keep them away from high-voltage
and power cables.
○ Connectors and terminals
・ Pay careful attention to the length and installation of cable wiring to ensure that connectors and cables are neither overloaded nor disconnected.
・ Make sure to prevent any metal objects from getting inside the connectors or the terminal blocks.
・ Short-circuits caused by metal objects or mis-wiring are likely to damage the device.
○ Do not impose any external loads on the units. Doing so may cause a failure.
○ Do not disconnect or reconnect between the transmission line and slave units when a transmission line is operating. A malfunction may occur.
○ Use the AnyWireASLINK within the range of the speci cations and conditions shown below.
[Warranty]
■ Warranty period
The warranty on the delivered Product shall continue to be effective for one (1) year after the delivery thereof to a location as designated by the original owner.
■ Scope of warranty
Should a defect occur in any part of the Product during the foregoing warranty period when it is used normally in accordance with the speci cations described
in this User's Manual, the Company shall replace or repair the defect free of charge, except when it arises as a result of:
[1] Misuse or abuse of the Product by the owner;
[2] Fault caused by cause other than the delivered Product;
[3] Unauthorized modi cation or repair of the Product by any party other than the Company;
[4] Any unusual force of nature, disaster, or other cause beyond the Company's control.
The term "warranty," as used herein, refers to the warranty applicable to the delivered product alone. The Company shall not be liable for any damages conse-
quential or incidental to a malfunction of the delivered product.
■ Repair at cost
After the expiration of the warranty period, any troubleshooting or repairs shall be done at the expense of the owner.
Even during the warranty term, any repairs and troubleshooting for defects arising from causes outside the scope of the warranty as speci ed above shall be
done at the owner's expense.
[Type]
BL296SB-08F-4-20 NPN input
BL296PB-08F-4-20 NPN output
BL296XB-08F-4-20 NPN input/NPN output
Speci cations Connection targets
General-purpose
sensors and
switches
General-purpose
output devices
Eight-point
Eight-point
Four-point/Four-point
-BL296*B08F*420 1/10-
Functions
Slave unit Sensing
I/O
voltage level
disconnection
drop drop
× ×
○
A CAUTION indicates a potentially hazardous situation
which, if not handled correctly, may result in personal
injury or property damage.
CAUTION
BL296SB-08FS-4-20 PNP input
BL296PB-08FS-4-20 PNP output
BL296XB-08FS-4-20 PNP input/PNP output
I/O
I/O
Small- Water
power supply
short-
voltage sized proof
circuit
drop
× ×
○ ○
Eight-point
Eight-point
Four-point/Four-point
