Secure Care KinderGUARD 500DE Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation Manual
Please contact your
Distributor /
Installer for service ...
Tel.: ___________________________
KinderGUARD 500DE,
Door GUARDIAN 500DE
And 500DE Systems
39 Chenell Drive
Concord, NH USA 03301-8501
Phone: (800) 451-7917 / (603)223-0745
Fax: (603) 227-0200
http://www.securecare.com
®
© 2004 Secure Care Products
, Inc.
CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE
FOR THE LATEST UPDATED MANUALS PLEASE VISIT AND LOG INTO THE DISTRIBUTOR PORTAL AT
WWW.SECURECARE.COM
Doc No: A01350690 REV Z ECO: 10262 Date: 08/10/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KinderGUARD 500DE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Secure Care KinderGUARD 500DE

Summary of Contents for Secure Care KinderGUARD 500DE

  • Page 1 Concord, NH USA 03301-8501 Phone: (800) 451-7917 / (603)223-0745 Fax: (603) 227-0200 http://www.securecare.com ® © 2004 Secure Care Products , Inc. CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE FOR THE LATEST UPDATED MANUALS PLEASE VISIT AND LOG INTO THE DISTRIBUTOR PORTAL AT WWW.SECURECARE.COM...

  • Page 2: Table Of Contents

    Table of Contents SECTION 1 IMPORTANT NOTICES PLEASE READ THIS MANUAL BEFORE BEGINNING THE INSTALLATION OF A SECURE CARE SYSTEM SECTION 2 SYSTEM BLOCK DIAGRAM SECTION 3 POWER AND GROUNDING REQUIREMENTS SECTION 4 TYPICAL SYSTEM INSTALLATION SECTION 5 SPECIFICATIONS Device Electrical Specifications...
  • Page 3 Surface Mount Enclosure (XIU, 500DE) Flush Mount Enclosure (XIU, 500DE) Flush Mount Enclosure (A02040901 LED Nurse Station Annunciator) Surface Mount Enclosure (A02040901 LED Nurse Station Annunciator) XIU to Secure Care Software Connections Single XIU Connection Interfacing Magnetic Locks Interfacing the Magnetic Solutions Lock...
  • Page 4 Software Version Elevator Mode Four Digit Escort Code Using the Month and Year SECTION 11 TESTING 500DE Recommended Weekly Testing Perimeter Control Perimeter Control with Locks 500DE Recommended Annual Servicing Battery Replacement SECTION 12 TROUBLESHOOTING SECTION 13 GENERAL PRODUCT WARRANTY STATEMENT 1.
  • Page 5 Table of Figures FIGURE 2-1 SYSTEM BLOCK DIAGRAM FIGURE 3-1 POWER SUPPLY CONNECTION FIGURE 6-1 FRONT VIEW OF DOOR GUARDIAN 500DE EXIT PANEL FIGURE 6-2 REAR VIEW OF 500DE EXIT PANEL FIGURE 6-3 REAR VIEW OF XIU FIGURE 6-4 REAR VIEW OF REMOTE KEYPAD FIGURE 6-5 REAR VIEW OF PUSH BUTTON FIGURE 9-1 SURFACE MOUNT ENCLOSURE FOR EXIT PANELS FIGURE 9-2 FLUSH MOUNT ENCLOSURE FOR EXIT PANELS...

  • Page 6: Section 1 Important Notices

    This installation manual is provided for reference by purchasers and installers of Secure Care Products, Inc.’s (“Secure Care’s”) systems. This manual is not intended as a catalog of warnings for the protection of anyone or as a substitute for obtaining professional training or assistance in the design of a facility’s security procedures and systems, or in the installation, set-up, testing, support, operation, maintenance, repair or use of Secure Care’s systems.
  • Page 7 Radio Frequency Interference (RFI); physical orientation and positioning of the equipment; and sources of Electro Static Discharge (ESD). Secure Care is not responsible for the effect of these types of factors on operation of its software, parts and products and disclaims all responsibility for any claim relative thereto.
  • Page 8 Internet. The only way to assure that software, parts or products are installed, set-up, tested, supported, maintained or repaired correctly or that a Secure Care system is functioning properly is to have it examined on site by a qualified service technician. In addition, Secure Care software, parts and products cannot be operated or used correctly by anyone who has not successfully completed Secure Care in-service training.

  • Page 9: Section 2 System Block Diagram

    SECTION 2 SYSTEM BLOCK DIAGRAM A01350691, Door Guardian 500 DE , Kinderguard 500 DE & 500DE Fig. 2 PERSONAL RS 232 one way to Secure Care Software COMPUTER WITH SECURE CARE SOFTWARE CENTRAL POWER SUPPLY (0PTIONAL REPLACEMENT FOR LOCAL 4 OR 8 CHANNEL...

  • Page 10: Section 3 Power And Grounding Requirements

    SECTION 3 POWER AND GROUNDING REQUIREMENTS If powered by a local wall mount power supply, each Exit Panel will require a 110/220/230VAC duplex outlet specific to regional or country options (minimum 2 Amp) within ten cable feet of the intended installation location. The use of emergency power circuits is highly recommended due to possible facility power failures.

  • Page 11: Figure 3-1 Power Supply Connection

    SECTION 3 SYSTEM COMPONENT DESCRIPTIONS 12VDC 8AMP POWER SUPPLY BATTERY INPUT AC CONN. VOLTAGE 8 FUSED OUTPUTS 12VDC BATTERY 12VDC BATTERY BATTERIES MUST BE WIRED BATTERIES MUST BE WIRED IN PARALLEL IN PARALLEL  REFER TO THE MANUFACTURER'S Risk of shock INSTALLATION MANUAL BEFORE ...

  • Page 12: Section 4 Typical System Installation

    Install all communication wires from each exit system to the system annunciator location (computer location). Secure Care strongly recommends that all wiring used to install Secure Care equipment be run at least 18 inches from all other wiring and not be installed inside metal conduit. It is also strongly recommended to not utilize cable trays used in networking installations and to secure the wires off of ceiling grids.

  • Page 13: Section 5 Specifications

    SECTION 5 SPECIFICATIONS This product meets UL 294 Standards Device Electrical Specifications XIU, Door GUARDIAN and KinderGUARD Exit Panels  Input Power: 12 - 15VDC  Relay Specifications: Max. 30VDC (only) 1 Amp  Battery Back Up: Rechargeable 9VDC Ni-MH battery ...

  • Page 14: Section 6 System Component Descriptions

    NOTE: Not all Exit Panels will have every feature set or all components populated. Refer to specific part number or Exit Panel model name for available feature sets. Door GUARDIAN 500DE pictured 500DE and KinderGUARD 500DE not depicted. Panel Information...

  • Page 15: Figure 6-2 Rear View Of 500De Exit Panel

    5. Controlled area network (CAN) connection 6. Remote Internal/External Keypad connection (seven pin) 7. Electromagnetic lock relays , one and two connections SECURE CARE PRODUCTS 8. Auxiliary relays (one and two 1) POWER connections) 2) MUTE 3) LOUD / SOFT 4) NOT USED 9.

  • Page 16: Xiu

    Back Up Battery Holder 5. 12 – 15VDC Power Input connection Auxiliary Relay Connection (Form C Relays that activate during a cutband alarm) SECURE CARE PRODUCTS 1 2 3 4 1) POWER 2) NOT USED 3) NOT USED 4) NOT USED...

  • Page 17: Remote Annunciation

    M L H SECURE CARE PRODUCTS Figure 6-4 Connection Between the A02030901/A02040901 and the 500DE Exit Panel Connection should be made using the Normally Open (NO) and Common © on the back of the 500DE Exit Panel.

  • Page 18: Indoor/Outdoor Remote Keypad Layout

    SECTION 6 SYSTEM COMPONENT DESCRIPTIONS Indoor/Outdoor Remote Keypad Layout LEGEND 1. Mounting screw holes 2. Seven pin connector for seven conductor ribbon cable Steel faceplate Figure 6-4 Rear View of Remote Keypad Indoor/Outdoor (N/O) Push Button Layout LEGEND 1. Mounting screw holes 2.

  • Page 19: Section 7 Standard Features

    SECTION 7 STANDARD FEATURES The access control system is designed to augment your policy regarding security of infants, small children, or long term care residents. The 500DE Exit Panel is normally armed. Any time the door is opened the alarm will sound unless the proper access code is entered into the keypad prior to opening the door.

  • Page 20: Section 8 Theory Of Operation

    ID. The XIU passes the input messages through to either an ID Nurse Station Console or a PC based Secure Care Software Graphical Annunciator. The XIU is equipped with two auxiliary relays (Form C relays) which activate during a cutband alarm.

  • Page 21: Section 9 Installation And Connections

    SECTION 9 INSTALLATION AND CONNECTIONS Basic Installation of Mounting Enclosures Surface Mount Enclosure (XIU, 500DE) The surface mount enclosure is designed to be mounted on the wall adjacent to the exit to be monitored. It mounts using the screws, anchors, and strain relief provided with the enclosure. Wiring may be routed through one or more of the three provided knockout locations or through surface mounted non-metallic conduit into the knockouts on the top of the enclosure.

  • Page 22: Flush Mount Enclosure (Xiu, 500De)

    SECTION 9 INSTALLATION AND CONNECTIONS Flush Mount Enclosure (XIU, 500DE) The flush mount enclosure is designed to be mounted in the wall adjacent to the exit to be monitored. It mounts using the screws, washers, retainers, and strain relief provided with the enclosure. Wiring may be routed through one or more of the four provided knockout locations on the back, sides, or top of the enclosure.

  • Page 23: Flush Mount Enclosure (A02040901 Led Nurse Station Annunciator)

    SECTION 9 INSTALLATION AND CONNECTIONS Flush Mount Enclosure (A02040901 LED Nurse Station Annunciator) This flush mount enclosure should be mounted in a convenient location for monitoring by facility staff. It mounts easily using the Madison clips provided. Knockouts for wire entry are available in all four sides and back of the enclosure. Use the strain relief cable clamp provided for wire entry.

  • Page 24: Surface Mount Enclosure (A02040901 Led Nurse Station Annunciator)

    SECTION 9 INSTALLATION AND CONNECTIONS SECTION 9 INSTALLATION AND CONNECTIONS Surface Mount Enclosure (A02040901 LED Nurse Station Annunciator) This surface mount enclosure should be mounted in a convenient location for monitoring by facility staff. It mounts easily using the Madison clips provided. Knockouts for wire entry are available in all four sides and back of the enclosure. Wiring may be routed through one or more of the six provided knockout locations or through surface mounted non-metallic conduit into the knockouts on the top or bottom of the enclosure.

  • Page 25: Xiu To Secure Care Software Connections

    Windows-based personal computers. Secure Care Software shows all activities on detailed floor maps of the facility. Device images on a floor map are mapped to the devices they represent so that Secure Care Software can manipulate the image in response to events and status changes involving the device.

  • Page 26: Single Xiu Connection

    Figure 9-5 XIU Controlling Cutband Receivers and Exit Panels Connected to One XIU NOTE: An improper connection on the single XIU application will result in the Secure Care Software displaying an XIU- cross communication error. This is a logged event and can be viewed through the Device Reader in our software.

  • Page 27: Interfacing Magnetic Locks

    SECTION 9 INSTALLATION AND CONNECTIONS Interfacing Magnetic Locks The 500DE Exit Panel can be interfaced with a magnetic lock. The connections to the locks should be made as shown in Fig. 9-7 The 500DE Exit Panel can also be interfaced to two locks. Green White Lock...

  • Page 28: Interfacing The Magnetic Solutions Lock

    SECTION 9 INSTALLATION AND CONNECTIONS Interfacing the Magnetic Solutions Lock The 500DE Exit Panel can be interfaced with a magnetic lock. The connections to the locks should be made as shown in Fig. 9-8. Orange Orange/white Green Green/White Lock ( + ) Blue/White Power Blue...

  • Page 29: Figure 9-8 500De Exit Panel To Two Magnetic Solutions Locks Connections

    SECTION 9 INSTALLATION AND CONNECTIONS The 500DE Exit Panel can also be interfaced to two Magnetic Solutions locks. Make connections as shown in Fig. 9-9. The two locks should be wired in series not in parallel. Orange Orange/white Green Green/White Blue/White ( + ) POWER...

  • Page 30: Interfacing The Push Button And Remote Keypad

    The 500DE Exit Panel can be interfaced with a normally open non-latching Push Button and or a SCP provided Remote Keypad. The connections should be made as shown in Fig. 9-10. SECURE CARE PRODUCTS Figure 9-9 Push Button and Remote Keypad to 500DE Exit Panel Connection...

  • Page 31: Delayed Egress And Fire Alarm Connections

    Connections are shown in Fig. 9-10. Note: In order to use this equipment with fire system, the end product must be listed to UL864 SECURE CARE PRODUCTS Figure 9-10 Delayed Egress and Fire Alarm Connections Doc No: A01350690 REV Z ECO: 10262 Date: 08/10/12...

  • Page 32: Section 10 Programming

    SECTION 10 PROGRAMMING Reset (Escort) Codes NOTE: The PM mode must be disabled to make any programming changes to the panel. (See Section 10 of this manual) NOTE: All Programming is stored in nonvolatile memory, which means that if the panel looses power the programming will remain in memory *309 *9876543214 NOTE: To reset the panel to factory settings enter...

  • Page 33: Escort Time

    SECTION 10 PROGRAMMING Escort Time Factory Default 30 Seconds Each Exit Panel has a time period for passing through a door without creating an alarm. To change the Escort code, follow the three listed steps without pausing for greater than one second between keystrokes. Enter currently programmed secondary code Enter *9876543215# Enter new three digit time in seconds (up to a maximum of 900 seconds but not less then 15 seconds) followed by #...

  • Page 34: Delayed Egress Activation Time

    REVERSIBLE and cannot be undone by initializing the panel. Make sure the Life Safety 101 features are correct and meet your local authorities requirements before locking the feature .To undo this feature the panel will have to be sent back to Secure Care Products, Inc. to be reprogrammed. To LOCK Life Safety Features:...

  • Page 35: Latching Delayed Egress

    SECTION 10 PROGRAMMING Latching Delayed Egress Each Exit Panel controlling an electromagnetic lock has a required time period for pressure applied to a door to release the locking feature as required by NFPA 101. This feature, when enabled, allows the door to remain unlocked once the delayed egress feature is activated until an authorized reset code is entered into the Exit Panel.

  • Page 36: Fire Alarm Input Selection

    SECTION 10 PROGRAMMING Fire Alarm Input Selection Fire Alarm Input Factory Default Normally Open To change to input of the Fire alarm relay enter the following: Normally Open fire alarm contact active Enter currently programmed secondary code Enter *9876543216#000 Two confirmation beeps = change accepted One confirmation beep = change not accepted Normally Closed fire alarm contact active Enter currently programmed secondary code...

  • Page 37: Toggle On / Toggle Off

    SECTION 10 PROGRAMMING Toggle On / Toggle Off System is armed or disarmed Factory Default Armed To toggle off enter *567 *3 holding until one beep is heard To toggle on enter *567 *3 holding until three beeps are heard Date Time Change To change just the day and time in Pm programming for day light savings.

  • Page 38: Software Version

    SECTION 10 PROGRAMMING To check current times for PM mode *567 * 9 8 7 6 5 4 3 2 1 and hold 1 for one beep: Press 0: enter next code for time / date setting beep out. 1 beep feedback 4096 current time 4097 unlock time Monday 4353 lock time Monday...

  • Page 39: Four Digit Escort Code Using The Month And Year

    SECTION 10 PROGRAMMING SECTION 10 PROGRAMMING Four Digit Escort Code Using the Month and Year Four Digit Escort Code Factory Default Disabled You are able to program a four digit escort code into the 500DE Exit Panel. You can enter *@@## where @@ is the month (digits 01 to 12), and ## is the last two digits of the year (digits 00 to 99).

  • Page 40: Section 11 Testing

    SECTION 11 TESTING 500DE Recommended Weekly Testing Perimeter Control Escort Feature Test Enter the reset code into the keypad on the 500DE Exit Panel. The red LED should turn off and the green LED should turn on. Open the door. No alarm condition should be activated. Close the door. Anti-Tailgate Feature Test Enter the reset code into the keypad on the 500DE Exit Panel.

  • Page 41: 500De Recommended Annual Servicing

    SECTION 11 TESTING Fire Alarm Release Feature Test Place the fire alarm system into the alarm mode and verify that all locks release. The 500DE Exit Panels should be in the fire alarm release alarm condition. 500DE Recommended Annual Servicing Battery Replacement The battery should be replaced annually with a rechargeable 9VDC battery only.

  • Page 42: Section 12 Troubleshooting

    SECTION 12 TROUBLESHOOTING Symptom 1: LED’s on the 500DE Exit Panel are off. Potential causes and corrective actions:  Power switch on the 500DE Exit Panel is in the OFF position.  Improper output voltage: Check the plug in the transformer for proper output voltage. ...
  • Page 43 SECTION 12 TROUBLESHOOTING SECTION 12 TROUBLESHOOTING Symptom 5: The 500DE Exit Panel goes into delayed egress alarm without pressure being applied to the door hardware. (continued)  Check the door for proper operation. If the door does not close properly or completely, the delayed egress switch may be activated.
  • Page 44 SECTION 12 TROUBLESHOOTING Symptom 10: The Remote Keypad is not operating. All other functions are operating properly. Potential causes and corrective actions:  Verify that the proper reset code is being entered into the Remote Keypad. The Remote Keypad must use the same reset code as the panel.

  • Page 45: Section 13 General Product Warranty Statement

    Product and promptly return this Product to the place where you obtained it for a full refund. If you have any difficulty obtaining a refund, please contact Secure Care at the telephone number provided in Section 2.B below.
  • Page 46 Interference (RFI); physical orientation and positioning of the equipment; and sources of Electro Static Discharge (“ESD”). Secure Care cannot be responsible for the effect of these types of factors on operation of its software, parts and products. D. This Product must be installed, set-up, tested, supported, operated, maintained, repaired and used only in accordance with all manuals and instructions (including the user, installation, technical and other manuals) issued by Secure Care (the “Product Manuals”).

  • Page 47: Limited Warranty

    Secure Care to an authorized Secure Care distributor, shall conform to the specifications which accompany this product for a period of one (1) year from the date of delivery of this product by Secure Care to a common carrier, f.o.b.

  • Page 48: Limitations Of Liability

    (without interest) paid to Secure Care for this product. B. In no event shall Secure Care be liable to anyone for any loss of data, loss of profits or loss of use of this product or...

  • Page 49: Severability

    A waiver on one or more occasions of any term or condition of this General Product Warranty Statement shall not constitute or be deemed to be a waiver of such term or condition on any other occasion. No delay or failure of Secure Care to exercise any right or remedy under this General Product Warranty Statement will operate as a waiver thereof;...

  • Page 50: Section 14 Compliance Information

    SECTION 14 COMPLIANCE INFORMATION FCC Compliance Statement This equipment has been tested to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 51 Doc No: A01350690 REV Z ECO: 10262 Date: 08/10/12...
  • Page 52 Doc No: A01350690 REV Z ECO: 10262 Date: 08/10/12...

  • Page 53: Appendix Aul Listing Requirements

    APPENDIX A UL LISTING REQUIREMENTS This system has passed all the requirements for UL listing. In order for the system to be listed, exits panels, UL listed wire, strain reliefs and knockout hole covers must be used. All the components shipped with the kits and boxes must be used in order for the system to keep its UL Listing.

  • Page 54: Appendix B 230 Vac Input Power Supply Connection

    APPENDIX B 230 VAC INPUT POWER SUPPLY CONNECTION  Risk of shock  Dry location use only  For indoor use only Power Supply Max 8 output SECURE CARE PRODUCTS SECURE CARE PRODUCTS 12VDC Max 8 output SECURE CARE PRODUCTS SECURE CARE PRODUCTS...

  • Page 55: Appendix C 4Amp Power Supply Connections

    +BAT- + DC - supply NOTE: Refer to Appendix B for OverSeas 230VA Power Supply Battery 1 Battery 2 Max 8 Per output SECURE CARE PRODUCTS SECURE CARE PRODUCTS 12VDC Max 8 Per output SECURE CARE PRODUCTS SECURE CARE PRODUCTS...

  • Page 56: Appendix D Old Pm Programming

    APPENDIX D OLD PM PROGRAMMING PM Mode Feature The PM Mode feature allows the user to select a single event, (one lock time and one unlock time) to automatically lock and unlock the door system for every day of the week. This will allow more control of unauthorized traffic through the protected door during those times.

  • Page 57: Appendix E California Fire Marshall Listing

    Health and Safety Code. See CSFM Listing No. (Listed below) for allowable values and/or conditions for use concerning material presented in this document. All of the following CSFM Listing Certificates are available by calling Secure Care Products at 1-800-451-7917 CSFM Listing Number...

This manual is also suitable for:

Door guardian 500de500de

Table of Contents
