Introduction
1.1 Product Description
G/EPON 1GE+WiFi ONU is support Dual mode(EPON and GPON), It can also be applied
to a wide temperature environment, good WiFi coverage and also has a powerful firewall
function.
G/EPON 1GE+WiFi ONU meets telecom operators FTTO (office), FTTD (Desk),
FTTH(Home) broadband speed, SOHO broadband access, video surveillance and other
requirements and design a GPON/EPON Gigabit Ethernet products
mature Gigabit GPON/EPON technology, highly reliable and easy to maintain, with
guaranteed QOS for different service. And it is fully compliant with technical regulations such
as ITU-T G.984.x and IEEE802.3ah.
Dual mode
Routing ONU
1.2 Product categories
Product model
V2801RW
G/EPON 1GE+WiFi ONU Introduction_V1.1
Figure 1 G/EPON 1GE+WiFi ONU
Product specification Chipset
1 G/EPON+1GE+WiFi
Table 1
Product categories
Realtek
1
The box is based on the
.
Antenna 5dBi
SDRAM Memory
64MB
Access the world
Advertisement
Related Manuals for V-Sol V2801RW
Summary of Contents for V-Sol V2801RW
- Page 1 QOS for different service. And it is fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah. Antenna 5dBi Dual mode Routing ONU Figure 1 G/EPON 1GE+WiFi ONU 1.2 Product categories Product model Product specification Chipset SDRAM Memory V2801RW 1 G/EPON+1GE+WiFi Realtek 64MB Table 1 Product categories Access the world...
- Page 2 G/EPON 1GE+WiFi ONU Introduction_V1.1 1.3 Application Chart EPON/GPON OLT Figure 2 Application Chart 1.3 Technical parameters Technical item 1 G/EPON port(EPON PX20+ and GPON Class B+) Wavelength:Tx1310nm,Rx 1490nm SC/UPC connector PON interface Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm Transmission distance: 20KM 1 x 10/100/1000Mbps auto adaptive Ethernet interfaces.10/100/1000M LAN interface Full/Half, RJ45 connector...
- Page 3 G/EPON 1GE+WiFi ONU Introduction_V1.1 Power ≤6W consumption Dimension 120mm×78mm×30mm（L×W×H） Net weight 0.15Kg Table 2 Technical parameters 1.4 Panel lights Mark Status Description The device is powered up. Power POWER The device is powered down. Blink Device does not receive optical signals. Optical signal loss Device has received optical signal.
- Page 4 G/EPON 1GE+WiFi ONU Introduction_V1.1 1.7 Software Key Feature Software Key Feature Dual mode , Can access EPON/GPON OLTs(HUAWEI、ZTE、 EPON/GPON mode FiberHome). Software mode Routing mode. IEEE802.11b/g/n(TX power:17dBm/16dBm/15dBm) WiFi WiFi Authentication : WEP/WAP-PSK(TKIP)/WAP2-PSK(AES) Firewall DDOS, Filtering Based on ACL/MAC/URL. Layer2 802.1D&802.1ad bridge, 802.1p Cos, 802.1Q VLAN. Layer3 IPv4/IPv6, DHCP Client/Server , PPPoE, NAT , DMZ ,DDNS.
