Thermo ventilator

Advertisement

Quick Links

Warranty card attached
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before attempting to install, operate or service the Panasonic
product. Please carefully read "INSTALLATION INSTRUCTIONS" (P.2 ~ 4) of this instructions before
installation. Failure to comply with instructions could result in personal injury or property damage. Please
explain to users how to operate and maintain the product after installation, and this booklet should be
presented to users. Please carefully read "USE AND MAINTENANCE INSTRUCTIONS" (P.20 ~ 21) of this
instructions before operation. Please retain this booklet for future reference. Make sure that the correct
information is written on the warranty card, including the date of purchase and the name of the
distributor. Keep the warranty card in a safe place along with the instructions for future reference.
INSTALLATION AND
OPERATING INSTRUCTIONS
Thermo Ventilator
Model No.
CONTENTS
SAFETY INSTRUCTIONS..........................2
SUPPLIED ACCESSORIES.........................6
WORK BEFORE INSTALLATION...............8
HOW TO INSTALL............................8 ~ 13
TEST RUN.............................................13
CONTROLLER.......................................14
FUNCTION............................................15
DIRECTION FUNCTION.........................16
ON MAIN BODY...................................19
INSTRUCTIONS..............................20 ~ 21
MAINTENANCE..............................21 ~ 22
ANTIBACTERIAL FUNCTION..................22
TROUBLESHOOTING............................23
WIRING DIAGRAM...............................23
SPECIFICATIONS..................BACK COVER
FV-30BG3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FV-30BG3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Panasonic FV-30BG3

  • Page 1: Table Of Contents

    Warranty card attached Thank you for purchasing this Panasonic product. Please read these instructions carefully before attempting to install, operate or service the Panasonic product. Please carefully read “INSTALLATION INSTRUCTIONS” (P.2 ~ 4) of this instructions before installation. Failure to comply with instructions could result in personal injury or property damage. Please explain to users how to operate and maintain the product after installation, and this booklet should be presented to users.
  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS Please observe strictly Disconnect power supply before maintenance. This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the product by a person responsible for the safety.
  • Page 3 INSTALLATION INSTRUCTIONS WARNING This product must be installed by an The product may adversely affect the authorized person according to all safe operation of appliances burning codes and regulations as stated in the gas or other fuels (including those in local municipal building code and other other rooms) due to back flow of relevant statutory regulations.
  • Page 4 INSTALLATION INSTRUCTIONS CAUTION Do not reconstruct this product. The fixing means for attachment to the ceiling such as hooks or other Otherwise, it may cause damage to devices shall be fixed with a sufficient the product or personal injury. strength to withstand 5 times the Do fix this product tightly.
  • Page 5: Installation Requirements

    INSTALLATION REQUIREMENTS Please observe the following installation requirements. Failure to do so may cause aging or failure of the product. Do not form the duct as shown below: Adapter Do not install onto slanting ceiling. Do not install the product in places with high temperature.
  • Page 6: Supplied Accessories

    SUPPLIED ACCESSORIES Drawing Name and Purpose Machine screw (M4×8) Self-tapping screw ( 4×20) Self-drilling screw ( 4×45) Self-tapping screw ( 4×16, used to install the remote controller base) (placed on the backside of controller holder) Installation and operating instructions Adapter Louver assembly Remote controller R03 (AAA) Manganese battery...
  • Page 7: Part Names And Dimensions

    PART NAMES AND DIMENSIONS Unit: mm Part name Cord cover Main body Adapter Heater assembly 12.5 Baffle plate Filter assembly Mode button panel Louver assembly PCB cover Remote controller Controller holder...
  • Page 8: Work Before Installation

    WORK BEFORE INSTALLATION 1. Confirmation before installation Notice 1.Install this product over 200 mm apart from curtains or Unit: mm other flammable materials. (When the mounting hole is Wall adjacent to curtains or other flammable materials, ensure that more than 250 mm gap is required between the hole edge and wall.) Duct pipe 2.The distance between ceiling board where the...
  • Page 9 HOW TO INSTALL Place the mounting bracket into the Adjust the length of the bracket as the ceiling. spacing between joists, and install to joists by drilling the other 2 tapping screws which have been fixed on it. 4 Tapping screws (ST4.2x20) Install the adapter at the location you just...
  • Page 10 HOW TO INSTALL Adapter Install the adapter (make the fixing hole in the Duct pipe Wooden middle). Use one 4×20 self-tapping screw to frame fix the adapter to the ceiling. Fixing hole Ceiling board 150 mm Self-tapping screw 4×20 Connecting the duct pipe Refer to Section 4.Connecting Duct Pipe on P.11.
  • Page 11 HOW TO INSTALL 2 Connecting power cord WARNING Wiring sketch To avoid electric shock or fire, do not remove the Conductor PCB cover. Earth 44± 1 Please select 60227 IEC 53 ordinary polyvinyl chloride sheathed cord. Nominal cross-sectional area of conductors is 3×1.5 mm Power cord Unit: mm...
  • Page 12 HOW TO INSTALL 3.Installing louver assembly Insert a straight screwdriver into the Hang the louver assembly into the hook gap of the screw cap, and unclench on the main body. the screw cap outward. Hook on Louver assembly main body Fix the louver to the main body with Attach the unclenched screw caps again.
  • Page 13: Test Run

    HOW TO INSTALL Remote controller 5.Installing the remote controller Take out the remote controller from the holder. Pull up Controller holder Check the main body can receive the signal from the intended remote controller installation location. If remote controller can not receive the signal from this installation location, please choose another installation location, or operate the remote controller toward product after taking out it from the holder.
  • Page 14: Function Of Remote Controller

    FUNCTION OF REMOTE CONTROLLER STANDBY button STATUS button In the standby status, this product Confirm the current still requires power consumption running status. (When you of about 0.5 W. If the product will press the button once, the not be in use for a long time, the indicator of the current all-pole power switch should be running status will stay on...
  • Page 15: How To Use Ventilation Function

    HOW TO USE VENTILATION FUNCTION Used to ventilate the bathroom Press the button to start the air change mode. The indicators of VENT. and default setting time (15 MIN.) light on, then turn off automatically after 3 seconds. During operation, you can press to change the running time.
  • Page 16: How To Use Air Direction Function

    HOW TO USE AIR DIRECTION FUNCTION For adjusting air direction During running, you can press the button to adjust the air direction. The initial air direction setting of HEAT, DRY HOT and DRY COOL is AUTO mode. You can press the button change the mode between MANUAL and AUTO.
  • Page 17: How To Use Heating Function

    HOW TO USE HEATING FUNCTION Use when you feel cold in a bath Before taking a bath, start the heating function to warm the bathroom beforehand. Press the button to start the heating mode. The indicators of HEAT and default setting time (15 MIN.) light on, then turn off automatically after 3 seconds.
  • Page 18: How To Use Drying Function

    HOW TO USE DRYING FUNCTION Use when you need to dry the bathroom or clothes Press the button to start the DRY HOT mode. It will switch to the DRY COOL mode if you press this button again. (Initial settings) DRY HOT DRY COOL The indicators of COOL or HOT and default setting time...
  • Page 19: Mode Button Panel On Main Body

    During the hot startup When the running indicator blinks quickly, please disconnect the power supply, and contact Panasonic customer consultation service center or your distributor. Blinking fast: On for 0.5 seconds and off for 0.5 seconds Blinking slow: On for 1 second and off for 1 second...
  • Page 20: Use And Maintenance Instructions

    USE AND MAINTENANCE INSTRUCTIONS WARNING Do not disassemble this product for Once flammable gas leaks, do not repair or reconstruction. start any function of this product. Doing this may generate spark and Doing this may lead to fire and thus lead to explosion. electric shock.
  • Page 21: Maintenance

    USE AND MAINTENANCE INSTRUCTIONS WARNING If you will not use this product any more, Before touching the main body remove the product. of this product or cleaning this product, make sure that the This product may cause injuries “all-pole switch” connected to once it falls off.
  • Page 22: Antibacterial Function

    MAINTENANCE Cleaning the louver assembly and filter Shut off the all-pole switch. Wipe the front panel with a soft cloth. Remove the filter from the louver assembly. Use a vacuum cleaner to remove dust from the filter. Reinstall the filter assembly. Turn on the all-pole switch.
  • Page 23: Troubleshooting

    TROUBLESHOOTING Check the product according to the table below if a fault occurs. If an error still occurs, check that the all-pole switch connected to this product is disconnected, and contact Panasonic customer consultation service center or your distributor. Symptom...
  • Page 24: Specifications

    This product comply with the IPX2 requirement against the water drop test and its remote controller comply with the IPX4 requirement against the water shower test. Insulation class E The above specification may be changed without further notice. Web Site: http://www.panasonic.com Issue date: 12/2023 Panasonic Corporation 2023 P1223-0 30BG34200 18...
