Thank you for purchasing this Panasonic product.
Please read these instructions carefully before attempting to install, operate or service the
Panasonic product. Please carefully read "INSTALLATION INSTRUCTIONS" (P.2 4) of this
instructions before installation. Failure to comply with instructions could result in personal
injury or property damage. Please explain to users how to operate and maintain the product
after installation, and this booklet should be presented to users. Please carefully read "USE
AND MAINTENANCE INSTRUCTIONS" (P.16 17) of this instructions before operation.
Please retain this booklet for future reference. Make sure that the correct information is
written on the warranty card, including the date of purchase and the name of the distributor.
Keep the warranty card in a safe place along with the instructions for future reference.
INSTALLATION AND
OPERATING INSTRUCTIONS
Thermo Ventilator
Model No.
CONTENTS
~


FV-30BY1
BACK COVER
BACK COVER
~
2
2 4
~
4 5
~
5
6
6
7 12
~
12
13
13
14
15
16 17
~
18
19
