Dunelm JACKSON DINING BENCH Instructions Manual page 3

Component parts supplied
Dimensions
Ref
1 132.5 x 35 x 4.5 cm
42 x 33 x 13.5 cm
2
Parts and Fittings
Fixtures and fittings
supplied (actual size)
Ref Dimensions Q'ty
A 8 x 25mm
19 x 1.5mm
B
12 x 1.5mm
C
Fixtures and fitting supplied
(not to scale)
Ref Dimensions
D N/A
Visual
mm 10 20
8
8
8
Visual
Q'ty
1
Q'ty
1
2
30 40 50 60 70 80 90 100
