INTRODUCTION
Thank you for choosing our product. The
DT600
Money
for
a
fast,
denomination &
counter.
the information stipulated in this manual in order
to make the best use of this product.
PLEASE TAKE NOTICE Should the equipment be altered
in any way or used in a manner for which it was not in-
tended at the time of delivery, the supplier of the equip-
ment accepts no responsibility for injury or damage to
personnel or equipment. If the conditions for use of the
equipment are changed, the supplier must be contac-
ted or the declaration of conformity will be invalidated.
2
Counter
accurate
multi-currency
We recommend reading thoroughly
All support provided from our North
American 24/7 Support Team
1-332-228-1098
upport@deteckusa.com
is
the
perfect solution
and
reliable
note
6
mixed-
value
all
Advertisement
Table of Contents
Related Manuals for Deteck DT600
Summary of Contents for Deteck DT600
- Page 1 INTRODUCTION Thank you for choosing our product. The DT600 Money Counter perfect solution fast, accurate reliable mixed- denomination & multi-currency note value counter. We recommend reading thoroughly the information stipulated in this manual in order to make the best use of this product.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS warning Keep the machine away from heavy humidity and high temperature as it may pre- vent it from working properly. Do not drop conductive objects into the machine to prevent internal short circuit. Do not use this machine in areas where it may be exposed to water or other liquids . Unplug this machine from the wall before opening the back cover for maintenance.
-
Page 3: Table Of Contents
content safety precautions instructions before the operation overview of the product 10 counterfeit detection fuNctions 11 technical parameters 12 operation 16 service menu 20 maintenance and troubleshoot 24 warrAnty... -
Page 4: Safety Precautions
safety precautions PLEASE READ CAREFULLY AND UNDERSTAND ALL THE SAFETY INSTRUCTIONS. This product should not be exposed to: • Shaky or vibrating surface. • High temperature including but not limited to strong sunlight, radiator or heater register. It should not be placed in a built-in installation unless properly ventilated. -
Page 5: Instructions Before The Operation
instructions before the operation Package contents: UNPACKING After unpacking the machine, please store the box and the packing material for fu- ture use. Failing to ship the machine back in its original machine box, Styrofoam and packing material will void the machine’s warranty. installation Please follow below step by step instructions: Place the machine on a solid flat surface before using. - Page 6 OVERVIEW OF THE PRODUCT MAIN PARTS COUNTING GUIDE Align notes HOPPER TFT DISPLAY Notes stage Shows counting results SIDE COVER FRONT PANEL Protection Operate the IMPELLER Run the notes STACKER TRAY NOTES BLOCK Protection BACK HANDLE Open to remove stuck notes and clean the machine software...
-
Page 7: Overview Of The Product
overview of the product MAIN display SPEED SET Counting functions DATE AND TIME COUNTING MODE COUNTING CURRENCY TOTAL PIECES Notes counted TOTAL VALUE Notes counted fuctions... - Page 8 Overview of the product front panel functional keys MODE This button is used to switch among CNT mode (count), SDC mode (Single Denomination Count) & MDC mode (Mixed Denomination Count) START This button is used to start counting when notes are placed on the Hopper. It also allows the user to switch from Auto (default) to Manual counting by pressing the Start button long enough (over 5 seconds) until it switches to Manual and then release the button.
-
Page 9: Counterfeit Detection Functions
Overview of the product Up Arrow This button is used to adjust speed levels upward. When BATCH is on, press this but- ton to increase the Batch number Press to confirm the selection. Use this button to print the results in the report interface Down Arrow This button is used to adjust speed levels downward. -
Page 10: Technical Parameters
TECHNICAL PARAMETERS dimensions (W x D x H): 1 x x ” (26x2 x package (W x D x H): 14x1 x1 ” (3 x net weight Approx. 1 lbs / . Kg Gross weight Approx. lbs / 6. Kg counting speed 800/1000 notes/min (MDC SDC and CNT MODE) 1200 notes/min (CNT MODE only) display... -
Page 11: Operation
operation Operation Modes Press the MODE Button sequentially to select the desired operating mode. You can find the selection on the top right of the display CNT mode This mode is used to derive the quantity of notes counted (PCs). It works on all notes even for currencies that are not programmed on this machi- ne. - Page 12 operation printing Plug the Printer cable in the machine printing interface (RS-232C Serial Port). Once connected, Turn On the machine, ensure the baud rate is correctly setup (check set- tings 1.4 section) and start the count. Press Report Button once. Press the OK Button to print the Total value and quantity of notes result.
- Page 13 operation Having the correct feeding ga adjusted will ensure a smooth counting as well as a trouble-free operation. Trial and error attempts are recommended before you make the final adjustment. • When the hopper is too tight, please loosen it by toggling the wheel to “ ”. It works for used (thicker) notes, adjust toward “+”...
- Page 14 operation In case notes are jammed inside the transporting mechanism, please follow below instructions: roceed to open the back compartment pushing down the lock lever located at the back at the same time you pull it toward you If you notice you can reach the note easily using your fingers, then proceed to remove it carefully.
-
Page 15: Service Menu
service menu In order to access the SET MENU, Press the OK button until you r prompted to input a password. The default password is ↓↓↓↓. You can use the arrows to select a sub-menu. Press OK button to confirm your selection and press BATCH button to return to the previous page. - Page 16 service menu...
- Page 17 service menu CIS CALIBRATION detection function. detection function. munication. The baud rate can he machine. We set to value=3 if the hat matches with your printer baud detection function (Width). detection function (Double Bill). ty in Auto Count when the notes sitivity of the sensor.
- Page 18 service menu...
-
Page 19: Maintenance And Troubleshoot
Maintenance and troubleshooting Following these periodic cleaning routines, will help to keep the machine in the optimum condition for ensuring a trouble-free operation as well as to extend the machine’s lifespan. DAILY ROUTINE: Perform the following steps on a daily basis: Turn Off the machine when not in use. - Page 20 Maintenance and troubleshooting...
- Page 21 Maintenance and troubleshooting Other Error code reference CAUTION: Make sure that the device is not in the vicinity of any magnetic fields or de- vices transmitting any signal since this may disrupt the integrated sensors. code ERROR MSG possible cause solution •...
- Page 22 Maintenance and troubleshooting solution code ERROR MSG possible cause • Check the note quality. If no • uspicious non RR R obvious visible issues are conformin si e has been found, count the note again. detected • Contact the Support Team •...
-
Page 23: Warranty
Warranty This DETECK product is warranted to be free of defects in materials and work- manship for one (1) year after the date of purchase. These warranties do not cover consumer caused damages such as misuse, abuse or repairs attempted by the consumer. This limited warranty gives you specific legal rights and you may also have other rights, which vary from state to state. - Page 24 DETECK product must be delivered in its original carton placed in a shipping or freight package offering an equal degree of protection. DETECK will not be responsible for any loss or damage incurred in connection with the return of this product.
