This unit has a separately sold alternative starting method that many find easier than pulling a rope. For more information, contact a local Craftsman outlet or go to www.craftsman.com Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A. Visit our website: www.craftsman.com...
RULES FOR SAFE OPERATION CALIFORNIA PROPOSITION 65 WARNING The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols, and their explanations, deserve your careful attention and understanding. The safety warnings do not by themselves WARNING eliminate any danger.
CRAFTSMAN FULL WARRANTY If this Craftsman product fails due to a defect in material or workmanship within two years from the date of purchase, return it to any Sears store, Parts & Repair Service Center, or other Craftsman outlet in the United States for free repair (or replacement if repair proves impossible).
KNOW YOUR UNIT APPLICATIONS As a trimmer: • Cutting grass and light weeds Muffler • Edging Spark Plug • Decorative trimming around trees, fences, etc. Other optional accessories may be used with this unit. Shaft Grip Starter Rope Grip On/Off Control D-Handle Fuel Cap...
ASSEMBLY INSTRUCTIONS OIL & FUEL INFORMATION OPERATING THE CONVERTIBLE™ COUPLER SYSTEM OIL AND FUEL MIXING INSTRUCTIONS Old and/or improperly mixed fuel are the main reasons for the unit not WARNING: Before using any attachment, read and understand running properly. Be sure to use fresh, clean unleaded fuel. Follow the the manual that came with the attachment.
STARTING/STOPPING INSTRUCTIONS STARTING/STOPPING INSTRUCTIONS STARTING INSTRUCTIONS WARNING: Operate this unit only in a well-ventilated outdoor Mix gas with oil. See Oil and Fuel Mixing Instructions. area. Carbon monoxide exhaust fumes can be lethal in a confined Fill the fuel tank with the fuel/oil mixture. area.
OPERATING INSTRUCTIONS MAINTENANCE & REPAIR INSTRUCTIONS Some line breakage will occur from: There are two methods to replace Bump Knob the trimming line: • Entanglement with foreign matter • Wind the inner reel with new line • Normal line fatigue •...
Page 8
MAINTENANCE & REPAIR INSTRUCTIONS 12. Insert the split ends of the AIR FILTER MAINTENANCE Air Filter line into the two holding slots Cleaning the Air Filter Cover (Fig. 20). Clean the air filter every 10 hours Index Teeth 13. Insert or slide the split ends of operation.
MAINTENANCE & REPAIR INSTRUCTIONS TRANSPORTING PLUG-IN POWER START AND POWER BIT START FEATURES • Allow the engine to cool before transporting. This unit is designed to be started with an optional Plug-In Power Start or Power Bit Start (items sold separately). If choosing to start the unit using •...
You’ll find the answer and more on managemyhome.com – for free! Find this and all your other product manuals online. Get answers from our team of home experts. Get a personalized maintenance plan for your home. Find information and tools to help with home projects. brought to you by Sears...
Fast help by phone – we call it Rapid Resolution - phone support from a Sears representative. Think of us as a “talking owner’s manual.” Once you purchase the Repair Protection Agreement, a simple phone call is all that it takes for you to schedule service. You can call anytime day or night, or schedule a service appointment online.
Page 13
Esta unidad tiene un método de comienza que se vende por separado y en muchos casos es mas facil que jalar una cuerda. Para más información, entre en contacto con un local Craftsman enchufe o vaya a www.craftsman.com Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A. Visite nuestro sitio web: www.craftsman.com 769-05286 P00...
Page 14
NORMAS PARA UNA OPERACION SEGURA PROPOSICIÓN 65 DE CALIFORNIA Los símbolos de seguridad se utilizan para llamar su atención sobre posibles peligros. Los símbolos de seguridad y sus explicaciones merecen toda su atención y comprensión. Los símbolos de seguridad no eliminan ningún peligro ADVERTENCIA por sí...
Page 15
NORMAS PARA UNA OPERACION SEGURA CUANDO ESTÉ OPERANDO • No opere el motor a más velocidad de la necesaria para cortar, recortar o recortar bordes. No haga funcionar el motor a alta velocidad cuando no • Nunca arranque ni opere la unidad dentro de un cuarto o edificio cerrado. esté...
Page 16
Si este producto de Craftsman Professional falla debido a un defecto en el material o en la mano de obra dentro de un período de tres años a partir de la fecha de compra, devuélvalo a cualquier tienda o Centro de Servicio de Piezas y Reparaciones Sears u otro establecimiento de Craftsman en los Estados Unidos para que sea reparado sin costo alguno (o ser reemplazado si resulta imposible repararlo).
Page 17
INSTRUCCIONES DE ENSAMBLE INSTRUCCIONES DE ENSAMBLE INSTALACIÓN Y AJUSTE DE LA MANIJA EN D CÓMO SACAR EL ACCESORIO DE CORTE U OTRO ACCESORIO Empuje la manija D hacia Gire la perilla en sentido Mango del eje Bastidor del eje Acoplador de Botón de desconexión abajo sobre el bastidor del eje antihorario para aflojarla (Fig.
Page 18
INFORMACION DEL ACEITE Y DEL COMBUSTIBLE INSTRUCCIONES DE ARRANQUE Y APAGADO CARGA DE COMBUSTIBLE EN LA UNIDAD NOTA: La unidad usa INCREDI- La Posición PULL™ lo cual reduce Soplador que empieza ADVERTENCIA: Equipado con Saque la tapa del combustible lentamente considerablemente el para evitar lesionarse con el rociado del combustible.
Page 19
INSTRUCCIONES DE OPERACION INSTRUCCIONES DE OPERACION RECORTE DECORATIVO COMO SOSTENER EL RECORTADOR El recorte decorativo se realiza ADVERTENCIA: Siempre ojo del desgaste, el oír, eliminando toda la vegetación de protección del pie y del cuerpo para reducir el riesgo de lesión al alrededor de los árboles, postes, funcionar esta unidad.
Page 20
INSTRUCCIONES DE MANTENIMIENTO Y REPARACION Verifique el desgaste de los 14. Mientras sostiene el carrete Bobina Ojalillos dientes de posición del interior y la bobina exterior, exterior carrete interior y bobina tome los extremos partidos y exterior (Fig. 16). Si es Resorte tire con firmeza para soltar la necesario, saque la rebaba o...
Page 21
INSTRUCCIONES DE MANTENIMIENTO Y REPARACION Espere que el motor se enfríe. Retire la bujía de encendido y coloque AJUSTE DEL CARBURADOR alrededor de 30 ml (1 onza) de cualquier aceite para motor de 2 ciclos de NOTA: Los ajustes realizados sin buena calidad dentro del cilindro.
Page 22
Busque este y todos sus demás manuales de productos en línea. Obtenga respuestas de nuestros expertos en productos para el hogar. Reciba un plan de mantenimiento personalizado para su hogar. Encuentre la información y las herramientas que le ayudarán en sus proyectos para su hogar. presentado por Sears...
Page 23
*La cobertura en Canadá varía en algunos artículos. Para obtener todos los detalles, llame a Sears en Canadá al 1-800-361-6665. SERVICIO DE INSTALACIÓN SEARS Para la instalación de electrodomésticos, abridores de puertas de garaje, calentadores de agua, y otros productos para el hogar por profesionales de Sears, en los Estados Unidos o Canadá, llame al 1-800-4-MY-HOME...
PARTS LIST REPLACEMENT PARTS - MODEL 316.791080 2-CYCLE GAS TRIMMER Item Part No. Description Item Part No. Description 753-06282 Rear Cover Assembly (includes 2 & 3) 791-181930 Tank Screw 791-181862 Starter Screw 753-05057 Fuel Cap 753-06244 Starter Assembly Guard (includes 2) 791-182366 U-Shaped Nut 753-06245...
Page 31
PARTS LIST REPLACEMENT PARTS - MODEL 316.791080 2-CYCLE GAS TRIMMER Item Part No. Description 753-04234 Throttle Housing Assembly (includes 2-4) 791-182405 Switch 753-04119 Throttle Trigger 791-182690 Throttle Trigger Spring 753-04344 Upper Shaft Housing Assembly 753-05461 D-Handle (includes 7) 791-181587 D-Handle Hardware Assembly 753-1190 Split Boom Coupler (includes 9-12) 791-182057...
Page 32
® Registered Trademark / ™ Trademark of KCD IP, LLC in the United States, or Sears Brands, LLC in other countries ® Marca Registrada / ™ Marca de Fábrica de KCD IP, LLC en Estados Unidos, o Sears Brands, LLC in otros países Marque de commerce / Marque déposée de Sears Brands, LLC...
