- Page 1 MICROWAVE OVEN INSTRUCTION MANUAL Model: FM11BKA Read these instructions carefully before using your microwave oven. If you follow the instructions, your oven will provide you with many years of good service. SAVE THESE INSTRUCTIONS CAREFULLY (rev. xx/xx/xx MD)
- Page 2 Farberware is a registered trademark of Farberware Licensing Company, LLC Manufactured and sold pursuant to a license from Farberware Licensing Company, LLC © 2023 Farberware Licensing Company, LLC. All rights reserved.
-
Page 3: Table Of Contents
Table of Contents PRECAUTIONS ..............3 SPECIFICATIONS ..............3 SAFETY ................4 GROUNDING ..............5 UTENSILS ................7 SETTING UP YOUR OVEN ..........9 OPERATION ..............11 MAINTENANCE ..............16 WARRANTY INFORMATION ..........18... -
Page 4: Precautions
2. HINGEST AND LATCHES (broken or loosened) 3. DOOR SEALS AND SEALING SURFACES The oven should not be adjusted or repaired by anyone except properly qualified service personnel. SPECIFICATIONS Model: FM11BKA Rated Voltage: 120V~60Hz Rated Input Power(Microwave): 1500W Rated Output Power(Microwave):... -
Page 5: Safety
IMPORTANT SAFETY INSTRUCTIONS When usuing electrical appliances basic safety precautions should be followed, including the following: WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 2. -
Page 6: Grounding
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID. - Page 7 RADIO INTERFERENCE 1. Operation of the microwave oven may cause interference to you r radio, TV or similar equipment. 2. When there is interference, it may be reduced or eliminated by taking the following measures: 1. Clean door and sealing surface of the oven. 2.
-
Page 8: Utensils
UTENSILS CAUTION - Personal Injury Hazard Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches should be pierced before cooking. See the instructions on “Materials you can use in microwave oven.” or “Materials cannot be used in microwave oven.” There may be certain non-metallic utensils that are not safe to use for microwaving. - Page 9 MATERIALS YOU CAN USE IN MICROWAVE OVEN Utensils Remarks Browning Dish Follow manufacturer* instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or chipped dishes.
-
Page 10: Setting Up Your Oven
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish. Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal trim may cause arcing. - Page 11 Turntable Installation a. Never place the glass tray upside down. The glass tray should never be restricted. b. Both glass tray and turntable ring Hub (underside) assembly must always be used during cooking. c. All food and containers of food are always Glass tray placed on the glass tray for cooking.
-
Page 12: Operation
OPERATION 1. POWER LEVEL 10 power levels are available. Level Power 100% Display PL10 2. CLOCK SETTING 1. Press “CLOCK“ , “00:00” will display. 2. Press the number keys and enter the current time. For example, time is 12:10 now, please press “1,2,1,0”... - Page 13 4. MICROWAVE COOK 1. Press “TIME COOK ” once, the screen will display “00:00”. 2. Press number keys to input the cooking time; the maximum cooking time is 99 minutes and 99 seconds. 3. Press “POWER“ once, screen will display “PL10”. The default power is 100% power. Now you can press number keys to adjust the power level.
- Page 14 7. TIME DEFROST FUNCTION 1. Press “TIME DEFROST“ once, the screen will display “dEF2”. 2. Press number pads to input defrosting time. The effective time range is 0:01~99:99 3. The default microwave power is power level 3. If you want to change the power level, press “POWER“...
- Page 15 12. DINNER PLATE 1. Press “DINNER PLATE“ repeatedly until the number you wish appears in the display, “9.0”,”12.0”,”18.0” Oz will display in order. For example, press “DINNER PLATE” once, “9.0” appears. 2. Press “START/+ 30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five times and then turns ba ck to waiting state.
- Page 16 15. MULTI-STAGE COOKING At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is defrosting, then defrosting shall be placed at the first stage automatically. Note: Auto cooking cannot work in the multi-stage cooking. Example: If you want to cook with 80% microwave power for 5 minutes + 60% microwave power for 10 minutes.
-
Page 17: Maintenance
MAINTENANCE Troubleshooting Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center. Trouble Possible Cause Possible Remedy Oven will not start a. -
Page 19: Warranty Information
ONE YEAR LIMITED WARRANTY This warranty applies to products purchased and used in the U.S and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition. This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase.
