Summary of Contents for AEG ProLine CLGVI955P

  • Page 1 FSK94847P User Manual Dishwasher USER MANUAL...

  • Page 2: Table Of Contents

    14. ENVIRONMENTAL CONCERNS..............31 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3 ENGLISH responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 •...

  • Page 4: Safety Instructions

    The operating water pressure (minimum and • maximum) must be between 0.5 (0.05) / 10 (1) bar (MPa) Follow the maximum number of 14 place settings. • The appliance door should not be left in an open • position to avoid the tripping hazard.
  • Page 5 ENGLISH • Do not use multi-plug adapters and extension cables. • Make sure not to cause damage to the mains plug and to the mains cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre. •...

  • Page 6: Installation

    Refer to Safety chapters. 3.1 Building in min. 560 www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG/Electrolux 60 cm Sliding Door Dishwasher 1240 3.2 Safety caps If the furniture panel is not installed, open the appliance door carefully to avoid the risk of injury.
  • Page 7 ENGLISH functionality of the appliance and may cause an injury. If the plastic cover is damaged, contact the Authorized Service Centre to replace it with the new one. 5 mm...

  • Page 8: Product Description

    4. PRODUCT DESCRIPTION Ceiling spray arm Detergent dispenser Upper spray arm ComfortLift basket Lower spray arm Trigger handle Filters Lower basket handle Rating plate Upper basket Salt container Cutlery drawer Air vent Rinse aid dispenser 4.1 Internal light The lamp goes off when you close the door or switch the appliance off.
  • Page 9 ENGLISH Display AUTO Sense program button MY TIME program selection bar Option buttons (EXTRAS) 5.1 Display The ECOMETER indicates how the programme selection impacts energy The display shows the following and water consumption. The more bars information: are on, the lower the consumption is. •...

  • Page 10: Programme Selection

    6. PROGRAMME SELECTION 6.1 MY TIME The appliance senses the degree of soil and the amount of dishes in the baskets. MY TIME selection bar allows to select a It adjusts the temperature and quantity of suitable dishwashing cycle based on water as well as the wash duration.
  • Page 11 ENGLISH 6.4 Programmes overview Pro‐ Dishwasher Degree of Programme phases EXTRAS gramme load soil Quick Crockery, Fresh • Dishwashing 50 °C • ExtraPower cutlery • Intermediate rinse • GlassCare • Final rinse 45 °C • AirDry Crockery, Fresh, lightly • Dishwashing 60 °C •...

  • Page 12: Basic Settings

    Consumption values Water (l) Energy (kWh) Duration (min) 1)2) Programme Quick 11.0 0.620 11.8 0.970 1h 30min 11.9 1.110 2h 40min 11.9 1.210 11.0 0.746 AUTO Sense 12.1 1.220 Machine Care 10.6 0.710 1) The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values.
  • Page 13 ENGLISH Settings Values Description Display on floor ON (default) Activate or deactivate TimeBeam. Brightness 0 - 9 Adjust the brightness of the display. Language List of languages Set the preferred language. (default: English) Reset settings Reset the appliance to the factory settings. PNC number Number Check the PNC number of your appliance.
  • Page 14 The water softener should be adjusted in your area. Set the right level of the according to the hardness of the water in water softener to assure good washing your area. Your local water authority can results. advise you on the hardness of the water Water hardness German de‐...
  • Page 15 ENGLISH initiation has no impact on the cycle To deactivate the rinse aid dispenser and duration, unless it occurs in the middle of the notification, set the rinse aid level to a programme or at the end of a programme with a short drying phase. In 7.4 End sound such cases, the regeneration prolongs the total duration of a programme by...

  • Page 16: Before First Use

    TimeBeam displays the following CAUTION! information on the floor below the If children have access to appliance door: the appliance, we advise to • The programme duration when the deactivate AirDry. The programme begins. automatic opening of the • 0:00 and CLEAN when the door may pose a danger.

  • Page 17: Daily Use

    ENGLISH How to fill the salt container 8.2 How to fill the rinse aid dispenser Make sure that the ComfortLift basket is empty and locked in the raised position. 1. Turn the cap of the salt container counterclockwise and remove it. 2.
  • Page 18 8. Close the water tap when the programme is complete. 9.1 ComfortLift CAUTION! Do not sit on the rack or put excessive pressure on the locked basket. CAUTION! Do not exceed the max load Once the basket is unlocked, push capacity of 18 kg.
  • Page 19 ENGLISH For information about the By default, options must be detergent dosage, refer to activated every time before the manufacturer's you start a programme. instructions on the If the latest programme packaging of the product. selection is enabled, the Usually, 20 - 25 ml of gel saved options are activated detergent is adequate for automatically along with the...

  • Page 20: Hints And Tips

    9.7 Opening the door while The appliance returns to the programme selection. the appliance operates If you cancel the delay start, Opening the door while a programme is you have to select the running pauses the wash cycle. The programme again.
  • Page 21 ENGLISH • Make sure that items in the baskets • Always use the correct quantity of do not touch or cover each other. rinse aid. Insufficient dosage of rinse Only then can the water completely aid decreases the drying results. reach and wash the dishes.

  • Page 22: Care And Cleaning

    • Make sure that the spray arms can crack, warp, get discoloured or pitted. move freely before you start a • Do not wash in the appliance items programme. that can absorb water (sponges, 10.6 Unloading the baskets...
  • Page 23 ENGLISH Carefully follow the instructions on the packaging of the product. • For optimal cleaning results, start the programme Machine Care. 11.3 Removal of foreign objects Check the filters and the sump after each use of the dishwasher. Foreign objects (e.g.
  • Page 24 2. Wash the spray arm under running 7. Reassemble the filters (B) and (C). water. Use a thin pointed tool, e.g. a 8. Put back the filter (B) in the flat filter toothpick, to remove particles of soil (A). Turn it clockwise until it locks.
  • Page 25 ENGLISH 11.8 Cleaning the ceiling 2. To detach the spray arm from the basket, press the spray arm upwards spray arm and simultaneously turn it clockwise. We recommend to clean the ceiling spray arm regularly to prevent soil from clogging the holes. Clogged holes can cause unsatisfactory washing results.

  • Page 26: Troubleshooting

    5. To install the spray arm (C) back, insert the mounting element (B) in the spray arm and fix it in the delivery tube (A) by turning it clockwise. Make sure that the mounting element locks into place. 6. Install the cutlery drawer on the sliding rails and block the stoppers.
  • Page 27 ENGLISH Problem and alarm code Possible cause and solution The appliance does not • Make sure that the sink spigot is not clogged. drain the water. • Make sure that the interior filter system is not clogged. • Make sure that the drain hose has no kinks or bends. The display shows , Er‐...
  • Page 28 Problem and alarm code Possible cause and solution The remaining time in the • This is not a defect. The appliance is working correctly. display increases and skips nearly to the end of the pro‐ gramme duration. Small leak from the appli‐...
  • Page 29 ENGLISH 12.1 The dishwashing and drying results are not satisfactory Problem Possible cause and solution Poor washing results. • Refer to "Daily use", "Hints and tips" and the basket loading leaflet. • Use more intensive washing programme. • Activate the ExtraPower option to improve the washing results of a selected programme.

  • Page 30: Technical Information

    Problem Possible cause and solution Odours inside the appliance. • Refer to "Internal cleaning". • Start the Machine Care programme with a descaler or a cleaning product designed for dishwashers. Limescale deposits on the ta‐ • The level of salt is low, check the refill indicator.

  • Page 31: Environmental Concerns

    ENGLISH 13.1 Link to the EU EPREL EPREL database using the link https:// eprel.ec.europa.eu and the model name database and product number that you can find on the rating plate of the appliance. Refer to The QR code on the energy label the chapter "Product description".
  • Page 32 www.aeg.com/shop...

This manual is also suitable for:

Proline fsk94847pProline a9szgb01
